Product Details:
|
| Grade: | 9Cr18 / 9Cr18Mo | Equivalent Standard: | AISI 440C / DIN 1.4125 |
|---|---|---|---|
| Carbon Content: | 0.90-1.00% | Chromium Content: | 17.0-19.0% |
| Hardness: | HRC 56-59 (quenched And Tempered) | Diameter Range: | 3-300 Mm |
| Length: | 3000-6000 Mm Or Cut To Order | Surface Finish: | Black / Bright / Peeled / Polished |
| Delivery Condition: | Annealed Or Quenched And Tempered | Executive Standard: | GB/T 1220, ASTM A276 |
| Highlight: | 9Cr18 Martensitic Stainless Steel,High Carbon Bearing Grade Bar,440C Equivalent Wear Resistant |
||
When an application demands a combination of high hardness, outstanding wear resistance, and good corrosion resistance, 9Cr18 martensitic stainless steel round bar is a proven choice. Equivalent to AISI 440C and DIN 1.4125, this high-carbon martensitic grade is a hardened stainless steel widely used for bearings, valves, cutlery, and precision mechanical components that must stay sharp, strong, and rust-resistant in service.
9Cr18 is a high-carbon, chromium-bearing martensitic stainless steel with a carbon content of approximately 0.90–1.00% and chromium of 17–19%. This chemistry allows the material to be through-hardened by heat treatment to reach a working hardness of roughly HRC 56–59, delivering excellent wear resistance and edge retention. The addition of molybdenum in 9Cr18Mo improves hardenability and corrosion resistance further. Supplied in the annealed condition for easy machining, the bar is subsequently hardened and tempered by the customer or by our heat-treatment service.
| Grade | C | Si | Mn | P | S | Cr | Mo |
|---|---|---|---|---|---|---|---|
| 9Cr18 | 0.90–1.00 | ≤ 0.80 | ≤ 0.80 | ≤ 0.035 | ≤ 0.030 | 17.0–19.0 | − |
| 9Cr18Mo | 0.90–1.00 | ≤ 0.80 | ≤ 0.80 | ≤ 0.035 | ≤ 0.030 | 16.0–18.0 | 0.40–0.70 |
| Condition | Property | Value |
|---|---|---|
| Annealed | Hardness | ≤ 255 HB |
| Quenched & Tempered | Hardness | HRC 56–59 |
| Quenched & Tempered | Tensile Strength | ≥ 1900 MPa |
We supply 9Cr18 and 9Cr18Mo martensitic stainless steel round bars with strict chemistry and hardness control, full traceability, and mill test certificates. With a wide size range, flexible cutting, and reliable worldwide delivery, we support bearing, valve, cutlery, and precision engineering projects with consistent, high-performance material. Contact our team today for specifications, availability, and a competitive quotation.
![]()
![]()
![]()
