NM500 Wear Resistant Steel Plate 500 HBW Abrasion Resistant AR500 Sheet 6mm - 60mm Thickness

NM500 Wear Resistant Steel Plate — 500 HBW Abrasion Resistant Steel for High Impact Wear

NM500 is a through-hardened, quenched and tempered wear resistant steel plate with a nominal Brinell hardness of 500 HBW. It is produced to GB/T 24186 and is widely specified as a replacement for ordinary structural plate in areas exposed to severe sliding abrasion, impact and gouging. The balanced chemistry and controlled rolling schedule deliver a hard wear surface together with good toughness, so the plate resists cracking even in thick sections and low temperature service.

Key Features

• 500 HBW nominal hardness — 470 to 530 HBW tested on the plate surface, giving 3 to 5 times the wear life of Q235 mild steel.
• Quenched and tempered through thickness — hardness penetration maintained in thick sections, no soft core.
• Good impact toughness — Charpy V-notch energy of 24 J minimum at -20 °C makes it suitable for cold climate mining operations.
• Excellent weldability — low carbon equivalent of 0.65 max allows fabrication with standard low hydrogen consumables.
• Flat and accurate — plate flatness controlled by roller levelling, ready for CNC cutting without additional straightening.
• Cut to size service — plasma, laser and water jet cutting to your drawing, burr-free edges and bevelled preparations available.

Specifications

Chemical Composition (ladle analysis, %)

Mechanical Properties

Typical Applications

Dump truck bodies and liners, excavator and loader buckets, crusher hoppers and chute liners, conveyor skirt boards, screen decks, bulldozer blades, dredger cutter heads, cement and aggregate handling equipment, steel plant scrap boxes and recycling machinery.

Processing and Packing

• Cutting, drilling, bending and welding services available in house.
• Each plate protected with a removable anti-rust coating; bundled with steel straps and separated by wooden spacers.
• Standard export seaworthy packing, container or break bulk, suitable for long ocean transit.
• Mill test certificate, packing list and certificate of origin supplied with shipment.

Tell us the thickness, width and length you need, together with the wear area of your equipment, and our technical team will recommend the most economical NM500 specification and cutting plan for your project. Samples are available for evaluation.
