Alloy Round Bar Dia 55-400 Mm Mat DIN 1.8519 31CrMoV9 3-6 Meters Tool Mold Steel

Large Image : Alloy Round Bar Dia 55-400 Mm Mat DIN 1.8519 31CrMoV9 3-6 Meters Tool Mold Steel

Product Details:

Place of Origin:	China
Brand Name:	TSING SHAN
Certification:	ISO SGS MTC
Model Number:	DIN 1.8519 31CrMoV9

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Price:	0.65-1.65 USD/KG
Packaging Details:	Export Packing
Delivery Time:	7 Days
Payment Terms:	L/C, T/T
Supply Ability:	50000KGS

Contact Now

Alloy Round Bar Dia 55-400 Mm Mat DIN 1.8519 31CrMoV9 3-6 Meters Tool Mold Steel

Description

Application:	Construction, Manufacturing, Automotive	Tech:	Hot Rolled
Product:	Steel Round Bar	Tolerance:	Standard
Heat Treatment:	Available	Length:	Customizable
Corrosion Resistance:	High	Surface:	Black Or Right
Specification:	According To Customer Requirements	Dimensions:	16-600mm
Alloy:	Custom Made	Transmodel No:	DIN 1.8519 31CrMoV9
Highlight:	DIN 1.8519 Round Bar , 3-6 Meters Round Bar , 31CrMoV9 Round Bar

Alloy Round Bar Dia 55-400 mm Mat DIN 1.8519 31CrMoV9 3-6 Meters Tool Mold Steel

About products
31CrMoV9 is a nitriding steel which has at least 2.3%Cr,0.15%Mo,0.1%V as strengthening alloy elements.
Due to its high wear resistance,it is mainly used in the automotive industry and general components mechanical engineering.
30CrMoV9 is difficult to weld and therefore should not be used in weld constructions.It can attain surface hardness of 800 HV
after nitriding.31CrMov9 is directly involved the nitriding steel 30CrMoV9 (DIN1.7707).

Chemical Composition(%)

C	Mn	P	S	Si	V	Cr	Mo
0.27-0.34	0.40-0.70	≤ 0.025	≤ 0.035	≤ 0.4	0.1-0.2	2.3-2.7	0.15-0.25

Physical Property
Density ,g/cm3: 7.85
Specific heat capacity, J/(kg.K):460
Thermal conductivity ,W/(m.K):42
Electric resistivity,Ohm.mm2 /m:0.19
Modulus of elasticity ,Gpa: 210
Mechanical Property

Diameter d mm	16-40	40-100	100-160	160-250
Yield Strength Mpa	≥900	≥800	≥700	≥650
Tensile Strength Mpa	1100-1300	1000-1200	900-1100	850-1050
Elongation, %	≥9	≥10	≥11	≥12
impact,J	≥25	≥30	≥35	≥40
Hardness,HB	331-380	298-359	271-331	253-319

Forging
Heat the temperature between 1050ºC-1150ºC,hold suitable time for the steel to be thoroughly heated.Reheat the steel once
temperature below 850°C. Crack is easily occured when improper cooling way after forged,so it should be cooled as slowly
as possible in the furnace or in sand after forged.
Heat Treatment
Soft Annealing
Heat to 650-720ºC, cool slowly in the furnace. This will produce a maximum Brinell hardness of 248.
Hardening
Harden from a temperature of 870-930ºC, followed by oil/polymer or water quenching.
Tempering
Tempering temperature: 580-700ºC.
Nitriding
Gas/plasma nitriding temperature (gas, salt bath): 570-580ºC
Gas/plasma nitriding temperature (powder, plasma): 580ºC
Surface hardness after nitriding: 800 HV

Hold time,h	Hardness,HV
30	750	540	430	410	400	380	380
90	830	750	640	530	430	410	410
120	790	730	660	600	540	460	400
180	800	760	700	640	580	550	420
Depth,mm	0.15	0.25	0.35	0.45	0.55	0.65	1

Application
31CrMoV9 nitriding steel is used in mechanics automotive and general mechanics, which must be nitrided for very high wear forces,
for example, gears, rods or axes.Structural parts of medium and large cross sections and high surface hardness, e.g., valve and
gate valves, cylinders for combustion engines, superheated steam valves and fittings.
