AISI 52100 / 100Cr6 Steel Bearing Plate Sheets Thickness 8-100mm SUJ2 Gcr15

Large Image : AISI 52100 / 100Cr6 Steel Bearing Plate Sheets Thickness 8-100mm SUJ2 Gcr15

Product Details:

Place of Origin:	China
Brand Name:	TSINGSHAN
Certification:	ISO MTC
Model Number:	AISI 52100 / 100Cr6 GCr15

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Price:	USD1.45/KG
Packaging Details:	Wooden Box
Delivery Time:	7 Days
Payment Terms:	L/C, T/T
Supply Ability:	50000KGS

Contact Now

AISI 52100 / 100Cr6 Steel Bearing Plate Sheets Thickness 8-100mm SUJ2 Gcr15

Description

Products:	Alloy Steel Plate	Condition:	Hot Rolled
Technique:	Hot Rolled Forged	Product Type:	Steel Plate
Particle:	Customizable	Shipping Port:	Shanghai
Length:	96 Inches	Edge:	Mill Edge, Slit Edge
Size:	4*8ft	Shape:	Plate
Application:	Pressure Vessels, Boilers, Heat Exchangers	Regular Size:	48ft/ 410ft/ 1500*3000mm
Thinckness:	1mm-30m	Thickness:	1/4 Inch
Surface:	Polished
Highlight:	AISI 52100 steel bearing plate , 100Cr6 steel bearing plate , Thickness 8-100mm steel bearing plate

AISI 52100 / 100Cr6 Steel Sheets With A Thickness of 8-100mm Gcr15 Bearing Steel Plate

GCr15 Bearing Steel Introduction

GCr15 steel is one of the most commonly used Chinese bearing steels, it’s a high carbon chromium bearing steel with high hardenability, high & uniform hardness after heat treatment, high contact fatigue strength, good dimensional stability and corrosion resistance. The cold deformation plasticity is medium, the machinability is general, the weldability is poor, and it is sensitive to the formation of white spots, and there is a first type of temper brittleness.

Datasheet & Specification

GCr15 Steel Chemical Composition

	Chemical Composition %
Steel Grade	C	Si	Mn	Cr	Mo ≤	Ni ≤	Cu ≤	P ≤	S ≤	Ca ≤	O ≤	Ti ≤	Al ≤	As ≤	As+Sn+Sb ≤	Pb ≤
GCr15	0.95-1.05	0.15-0.35	0.25-0.45	1.40-1.65	0.10	0.25	0.25	0.025	0.02	–	0.0012	0.005	0.05	0.04	0.075	0.002

GCr15 Bearing Steel Mechanical Properties

GCr15 Material Hardness

Spheroidizing annealing hardness: 179-207 HBW
Softening annealing hardness: ≤245 HBW

Bending of GCr15 bearing steel

Hot rolled round steel: ≤3mm/meter; Total bending: ≤0.3% x length
Hot rolled annealing round steel: ≤3mm/meter; Total bending: ≤0.3% x length
Calcined round steel: ≤5mm/meter; Total bending: ≤0.5% x length
Cold drawn round steel (Φ≤25mm): ≤2mm/meter; Total bending: ≤0.2% x length
Cold drawn round steel (Φ>25mm): ≤1.5mm/meter; Total bending: ≤0.15% x length

GCr15 bearing steel is used to manufacture various bearing sleeves with wall thickness ≤12mm and outer diameter ≤250mm, steel balls with diameters of 25.4-50.8mm; also used for other rolling elements with wide range of sizes, such as tapered rollers, cylindrical rollers, spherical rollers, needle rollers, etc.; also used in the manufacture of molds, precision gauges and other mechanical parts that require high wear resistance, high elastic limit and high contact fatigue strength.

Equivalent

GCr15 steel equivalent to US AISI SAE ASTM, European EN, Germany DIN, Japanese JIS, British BSI, France NF and ISO standard.

You may also be interested in GCr15 vs 52100, 100Cr6 and SUJ2 steel.

GCr15 Equivalent (For reference)
China		USA		European		Japan		ISO
Standard	Grade	Standard	Grade	Standard	Grade	Standard	Grade	Standard	Grade
GB/T 18254	GCr15	AISI SAE, ASTM A295/A295m	52100	EN ISO 683-17	100Cr6 (1.3505)	JIS G4805	SUJ2	ISO 683-17	100Gr6

Notes: DIN 17230 is covered by DIN EN ISO 683-17, NF A35-565 is covered by NF EN ISO 683-17.
