Product Details:
|
| Features: | High Temperature Resistance, Corrosion Resistance, Durable, Easy To Install, Low Maintenance, Etc. | Price Term: | FOB, CFR, CIF |
|---|---|---|---|
| Keywords: | Stainless Steel Welded Tube | Pipe: | Steel Tube |
| Third Party Inspection: | BV,SGS,ASP | Standard: | ASTM A312, ASTM A358, ASTM A249, ASTM A269, ASTM A270, ASTM A554, ASTM A688, ASTM A789, ASTM A790, DIN17455, DIN17457, EN10216, EN10217, JIS G3459, JIS G3463, GOST9941-81, GOST9940-81 |
| Surface: | Mirror Polish, Satin Polish, NO.4 Polish | Types: | Stainless Steel Welded Pipe |
| Surface Finish: | Polished, Satin, Brushed | Section Shape: | Round |
| Wall Thickness: | 0.5mm - 30mm | Application: | Chemical, Petrochemical, Oil & Gas, Food & Beverage, Pharmaceutical, Water Treatment, Construction, Etc. |
| Ndt Test: | RT, UT, ET, HT, PT | Alloy Or Not: | Non-Alloy |
| Steel Color: | Silver / Original / White | ||
| Highlight: | Annealed stainless welded pipe,304 stainless welded pipe,316l stainless welded pipe |
||
"The pursuit of quality is our persistence"
We chose austenitic stainless steels from BAOSTEEL or TISCO as raw materials. Because these raw materials have high-quality properties, the effects after surface treatment will be more diversified. Pickling, polishing, mirror polishing, satin brushing, powder coating, you can choose the effect you want according to actual needs, we will try our best to help you complete.
"Stainless steel sanitary pipes with a outer diameter of 25.40mm to 101.6mm meters can meet 80% of the market requirements"
The outer diameter range of the stainless steel food grade tubes that our company has currently made is 15.88 mm to 2000 mm, if you need a bigger one, we can also complete it.
"The products we do the most are round pipes , rectangular pipes and square pipes. In this respect, our production line and workmanship are very mature."
If you need a profiled tube, please consult us with engineering drawings with parameters. Our engineers will analyze the technical difficulties and discuss cooperation plans with you.
| Material | Stainless Steel 304/304L/316L |
| Shape | Round / Square / Rectangle |
| Production Standards | ASTM A270 , AS 1528.1 , EN 10357 , DIN 11850 ,ISO 2037 , JIS G3447, KS D 3585 and so on. |
| Outer Diameter | 16mm - 2000mm ; |
| Thickness | 0.8mm - 20 mm ; |
| Length | 6 Meters - 18.3 Meters ; As customers' request ; |
| Tolerance | According to the Standard , +/-10% Commonly ; |
| Surface Treatment | 180#, 320#, 400# Satin / Hairline, Bright Anneal, Pickle,400#, 500#, 600# or 800# Mirror finish |
| Application | Suitable For Industries With High Hygiene Requirements Such As Beer, Beverage, Milk, Pharmaceuticals, Etc. |
| Test | Flaring test ; Flattening test ; Bending Test ; Hydraulic Test ; Eddy Current test |
| Design | OEM / ODM / Customized |
| Certificate | ISO9001 ; ISO14001; ISO 18001; TUV ; |
| AS 1528.1 | |||||
| Size OD | Tolerance of OD | Wall Thickness | Tolerance on Wall Thickness | Tolerances on Length | Weight KG/M |
| 12.70 | +/- 0.1 | 1.20 | +/- 10.0% | +3, -0 | 0.344 |
| 15.88 | +/- 0.1 | 1.20 | +/- 10.0% | +3, -0 | 0.439 |
| 19.05 | +/- 0.1 | 1.20 | +/- 10.0% | +3, -0 | 0.534 |
| 25.40 | +/- 0.1 | 1.20 | +/- 10.0% | +3, -0 | 0.723 |
| 25.40 | +/- 0.1 | 1.60 | +/- 10.0% | +3, -0 | 0.949 |
| 38.10 | +/- 0.1 | 1.20 | +/- 10.0% | +3, -0 | 1.103 |
| 50.80 | +/- 0.1 | 1.60 | +/- 10.0% | +3, -0 | 1.455 |
| 50.80 | +/- 0.1 | 1.20 | +/- 10.0% | +3, -0 | 1.483 |
| 63.50 | +/- 0.1 | 1.60 | +/- 10.0% | +3, -0 | 1.961 |
| 76.20 | +/- 0.1 | 1.60 | +/- 10.0% | +3, -0 | 2.467 |
| 101.60 | +/- 0.1 | 1.60 | +/- 10.0% | +3, -0 | 2.973 |
| 3A ASTM A270 | |||||
| Size OD | Tolerance of OD | Wall Thickness | Tolerance on Wall Thickness | Tolerances on Length | Weight KG/M |
| 3/4 " (19.1 mm) | +/-0.005" (0.13 mm) | 0.065" (1.65 mm) / 0.049" (1.25 mm) | +/- 10.0% | +1/8" (3.18 mm) | 0.7218 |
| 1" (25.4 mm) | +/-0.005" (0.13 mm) | 0.065" (1.65 mm) / 0.049" (1.25 mm) | +/- 10.0% | +1/8" (3.18 mm) | 0.9824 |
| 1-1/4" (31.8 mm) | +/-0.008" (0.20 mm) | 0.065" (1.65 mm) | +/- 10.0% | +1/8" (3.18 mm) | 1.2412 |
| 1-1/2" (38.1 mm) | +/-0.008" (0.20 mm) | 0.065" (1.65 mm) / 0.049" (1.25 mm) | +/- 10.0% | +1/8" (3.18 mm) | 1.5078 |
| 2" (50.8 mm) | +/-0.008" (0.20 mm) | 0.065" (1.65 mm) / 0.049" (1.25 mm) | +/- 10.0% | +1/8" (3.18 mm) | 2.0031 |
| 2-1/2" (63.5 mm) | +/-0.010" (0.25 mm) | 0.065" (1.65 mm) | +/- 10.0% | +1/8" (3.18 mm) | 2.5585 |
| 3" (76.2 mm) | +/-0.010" (0.25 mm) | 0.065" (1.65 mm) | +/- 10.0% | +1/8" (3.18 mm) | 3.0797 |
| 4" (101.6 mm) | +/-0.015" (0.38 mm) | 0.065" (1.65 mm) / 0.083" (2.11 mm) | +/- 10.0% | +1/8" (3.18 mm) | 5.2628 |
| ISO 2037 | |||||
| Size OD | Tolerance of OD | Wall Thickness | Tolerance on Wall Thickness | Tolerances on Length | Weight KG/M |
| 21.30 | +/- 0.13 | 1.00 | +/-10.0% | +3.18 -0 | 0.506 |
| 25.00 | +/- 0.13 | 1.20 | +/-10.0% | +3.18 -0 | 0.712 |
| 25.00 | +/- 0.13 | 1.60 | +/-10.0% | +3.18 -0 | 0.933 |
| 33.70 | +/-0.20 | 1.20 | +/-10.0% | +3.18 -0 | 0.972 |
| 33.70 | +/-0.20 | 1.60 | +/-10.0% | +3.18 -0 | 1.280 |
| 38.00 | +/-0.20 | 1.20 | +/-10.0% | +3.18 -0 | 1.100 |
| 38.00 | +/-0.20 | 1.60 | +/-10.0% | +3.18 -0 | 1.451 |
| 40.00 | +/-0.20 | 1.20 | +/-10.0% | +3.18 -0 | 1.160 |
| 40.00 | +/-0.20 | 1.60 | +/-10.0% | +3.18 -0 | 1.531 |
| 51.00 | +/-0.20 | 1.20 | +/-10.0% | +3.18 -0 | 1.490 |
| 51.00 | +/-0.20 | 1.60 | +/-10.0% | +3.18 -0 | 1.970 |
| 63.50 | +/-0.25 | 1.60 | +/-10.0% | +3.18 -0 | 2.467 |
| 70.00 | +/-0.25 | 1.60 | +/-10.0% | +3.18 -0 | 2.730 |
| 76.10 | +/-0.25 | 1.60 | +/-10.0% | +3.18 -0 | 2.970 |
| 88.90 | +/-0.25 | 2.00 | +/-10.0% | +3.18 -0 | 4.330 |
| 101.60 | +/-0.38 | 2.00 | +/-10.0% | +3.18 -0 | 4.983 |
Q: What are your company's main products ?
A: Our main products are stainless steel, carbon steel, galvanized steel, aluminium steel, ppgi steel products, including sheets, pipes, coils, strips, bars and channels.
Q: What are the advantages of your company ?
A: We guarantee that the quantity and specification of products are in full compliance with the standards of customer orders. We support any kinds of test. In addition, We also have more professional service and competitive price.
Q: Can we visit your factory?
A: Warmly welcome. Once we have your schedule, we will arrange the professional sales team to follow up your case.
Q: Can you provide sample?
A: Yes, for regular sizes sample is free but buyer need to pay freight cost.
