Product Details:
|
| Application: | Construction,Industry,boiler,Chemical | Standard: | DIN,ASTM,JIS,AISI |
|---|---|---|---|
| Type: | Seamless | Welding Line Type: | Seamless |
| Thickness: | 0.5 ~ 60mm | Length: | 3000mm~6000mm,Customer Request |
| Shape: | Round Pipe Tube | Outer Diameter: | 6-630mm |
| Technique: | Cold Drawn | Surface: | Annealing,pickling |
| High Light: | 904L Stainless Steel Pipe,Welded Stainless Steel Seamless Pipe,60mm 304 Stainless Steel Seamless Pipe |
||
904L has high nickel composition with low carbon content, copper alloy adding improve its resistance to corrosion, the “L” in 904L stands for low carbon, it is typical Super Austenitic stainless steel, equivalent grades are DIN 1.4539 and UNS N08904, 904L has better properties than other austenitic stainless steels.
| Grade | Ni | Cr | Mo | Cu | C | Mn | Si | P | S | Fe |
|---|---|---|---|---|---|---|---|---|---|---|
| 904L | 23 – 28 | 19 – 23 | 4 -5 | 1 – 2 | 0.02 | 2 | 1 | 0.045 | 0.035 | Balance |
| Grade | Tensile Strength, Min | Yeild Strength, Min | Elognation | Hardness |
|---|---|---|---|---|
| 904L | 490 Mpa | 215 Mpa | 35% | 90 HRB Max |
| Grade | Density (Kg/M3) |
Elastic Modulus (GPa) |
Mean Co-Eff Of Thermal Expansion (Μm/M/°C) |
Thermal Conductivity (W/M.K) |
Specific Heat 0-100°C (J/Kg.K) |
Elec Resistivity (NΩ.M) |
|||
|---|---|---|---|---|---|---|---|---|---|
| 0-100°C | 0-315°C | 0-538°C | At 20°C | At 500°C | |||||
| 904L | 7900 | 190 | 15 | – | – | 11.5 | – | 500 | 952 |
SMLS Pipe 904L A312 45 mm x 5 mm UNS N08904 Stainless Steel Seamless Tube
