Product Details:
|
| Application: | Industry,boiler,Chemical | Standard: | DIN,ASTM,JIS,AISI |
|---|---|---|---|
| Steel Grade: | 300 Series,304 304L 316 316L 310S 321 | Type: | Seamless,Welded |
| Welding Line Type: | Seamless,ERW | Thickness: | 1mm-20mm |
| Length: | 3000mm~6000mm,Customer Request | Shape: | Round.square.Rectangle,Round Pipe Tube |
| Outer Diameter: | 6-630mm | Technique: | Cold Drawn,Seamless/Welded |
| High Light: | ERW Seamless Wealed Pipe,ASTM A312 Stainless Steel Seamless Tube,UNS S31635 Stainless Steel Tube |
||
| ASTM A213 TP316Ti Stainless Steel Seamless Pipes Specification | ASTM A269, ASTM A213, ASTM A312, ASME SA269, ASME SA213, ASME SA312 |
| ASTM A213 TP316Ti Stainless Steel Seamless Pipes Grades | 202, 304, 304L, 304H, 304LN, 309S, 310S, 316, 316L, 316H, 316Ti, 316LN, 317L, 321, 321H, 347, 347H, 904L, SMO 254, ALLOY 254, 6MO, 6MOLY, UNS S31254 ETC. |
| ASTM A213 TP316Ti Stainless Steel Seamless Pipes Type | Seamless / Welded / ERW / EFW / Cold Draw / Hot Finish / Cold Finish |
| ASTM A213 TP316Ti Stainless Steel Seamless Pipes Outer Diameter Size | Seamless - 1/2" NB TO 18" NB Welded / ERW- 1" NB TO 16" NB EFW - 8" NB TO 110" NB |
| ASTM A213 TP316Ti Stainless Steel Seamless Pipes Wall Thickness | Schedule 10 to Schedule 160 (3 mm to 100 mm Thickness) |
| ASTM A213 TP316Ti Stainless Steel Seamless Pipes Length | 01 Meter to 12.5 Meters, Single Random Length, Double Random Length And Customize Size. |
| ASTM A213 TP316Ti Stainless Steel Seamless Pipes Ends | Plain Ends / Beveled Ends |
| ASTM A213 TP316Ti Stainless Steel Seamless Pipes Delivery Conditions | As Rolled, Formed, Stress Relieved, Annealed, Hardened, Tempered, Cold Draw |
| ASTM A213 TP316Ti Stainless Steel Seamless Pipes Coating | Electropolish, Mechanical Polish, Satin Finish, Passivated |
| ASTM A213 TP316Ti Stainless Steel Seamless Pipes Other Testing | Product Analysis, Transverse Tension Test, Flattening Test, Etching Test, Radiograph HIC Examination, Stabilizing Heat Treatment, Intergranular Corrosion Test, Weld Decay Test, Magnetic Particle Detection, Grain Size Test, NACE 0175, Dual Grade, PWHT (POST WELD HEAT TREATMENT), Flare Test, Bend Test, Hardness Test, Tensile Test etc |
| ASTM A213 TP316Ti Stainless Steel Seamless Pipes Dimension | All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM And ASME |
| ASTM A213 TP316Ti Stainless Steel Seamless Pipes Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment / Annealed / Bright Annealed |
| ASTM A213 TP316Ti Stainless Steel Seamless Pipes Packaging | Loose / Bundle / Wooden Pallet / Wooden box-a / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
| ASTM A213 TP316Ti Stainless Steel Seamless Pipes Shipment & Transportation | By Road - Truck / Train, By Sea - Break-bulk Conventional Vessel / FCL (Full Container Load) / LCL (Less Container Load) / 20 Feet Container / 40 Feet Container / 45 Feet Container / High Cube Container / Open Top Container, By Air - Freighter Civil Passenger and Cargo Planes |
| ASTM A213 TP316Ti Stainless Steel Seamless Pipes Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC |
The chemical composition of grade 316Ti Stainless Steel is outlined in the following table
| Element | Min | Max |
| C | - | 0.08 |
| Si | - | 0.75 |
| Mn | - | 2 |
| P | - | 0.45 |
| S | - | 0.03 |
| Cr | 16 | 18 |
| Mo | 2 | 3 |
| N | - | 0.1 |
| Fe | Balance | |
| Ni | 10 | 14 |
| Ti | 5x%(C+N) | |
The Mechanical Properties of grade 316Ti Stainless Steel are displayed in the following table.
| Temper | Annealed | |
|---|---|---|
| Tensile Rm | 75 | ksi (min) |
| Tensile Rm | 515 | MPa (min) |
| R.p. 0.2% Yield | 30 | ksi (min) |
| R.p. 0.2% Yield | 205 | MPa (min) |
| Elongation (2” or 4D gl) | 35 | % (min) |
Physical properties of 316Ti grade stainless steel in the annealed condition
| Specific Heat (0-100°C) | 500 | J.kg-1.°K-1 |
| Thermal Conductivity | 14.6 | W.m -1.°K-1 |
| Thermal Expansion | 16.5 | mm/m/°C |
| Modulus Elasticity | 193 | GPa |
| Electrical Resistivity | 7.4 | μohm/cm |
| Density | 7.99 | g/cm3 |
The grade 316H steel can be made into plates, sheets, and coils to be used in the following:
