A105 Forged Solid Steel Round Bar OD 130MM ASME A105 Boiler

A105 Forged Solid Steel Round Bar OD 130MM ASME A105 Boiler
A105 Forged Solid Steel Round Bar OD 130MM ASME A105 Boiler
A105 Forged Solid Steel Round Bar OD 130MM ASME A105 Boiler A105 Forged Solid Steel Round Bar OD 130MM ASME A105 Boiler A105 Forged Solid Steel Round Bar OD 130MM ASME A105 Boiler A105 Forged Solid Steel Round Bar OD 130MM ASME A105 Boiler

Large Image :  A105 Forged Solid Steel Round Bar OD 130MM ASME A105 Boiler

Product Details:
Place of Origin: China
Brand Name: MITTEL TISCO BAO STEEL
Certification: SGS ISO MTC
Model Number: A105
Payment & Shipping Terms:
Minimum Order Quantity: 10KGS
Price: 0.65 USD/KG
Packaging Details: Wooden Box
Delivery Time: 7 Days
Payment Terms: L/C, T/T
Supply Ability: 50000KGS

A105 Forged Solid Steel Round Bar OD 130MM ASME A105 Boiler

Description
Alloy Or Not: Is Alloy Technique: Hot Rolled,Forged,Cold Drawn
Application: Structural Steel Bar Type: Alloy Steel Bar,Carbon Steel Bar
Standard: ASTM,DIN,AISI,JIS Shape: Round
Length: 1--12m Surface Treatment: Black/Peeling/Polishing/Machined
Diameter: 12mm-650mm
High Light:

Forged Solid Steel Round Boiler Bar

,

OD 130MM Steel Round Bar

,

ASME A105 Steel Round Bar

A105 Forged Solid Rounds OD 130MM ASME A105 Boiler Steel Round Bar

A 105 is an ASTM steel forging specification mainly used for carbon steel forged piping components. This type of carbon steel forging alloy involved is a low carbon, manganese and silicon containing steel similar to AISI 1330, but with lower manganese content.

Chemical Composition of ASTM A105

Carbon: ≤0.35
Manganese: 0.60-1.05
Phosphorus: ≤0.35
Sulfur: ≤0.40
Silicon: 0.10-0.35
Copper: ≤0.40
Nickel: ≤0.40
Chromium: ≤0.30
Molybdenum: ≤0.12
Vanadium: ≤0.08

Mechanical Properties of ASTM A105

Tensile Strength min. Yield Strength min. Elongation min. Reduction of Area, min. Hardness
MPa ksi MPa ksi % % HBW
485 70 250 36 22 30 137-187



Forging

ASTM A105 carbon steel can be forged at temperatures in the range of 2200 to 1700 F followed by quenching and tempering or normalizing. The actual hot forging temperatures in closed die forging process will be decided by a number of factors, such as complexity of the forged part.

The proper temperature of forging can only be checked at the beginning of forging, higher temperature will probably cause surface defects, such as mill scales, which will bring uneven surface. And lower temperature will be not conducive to the plastic deformation of C1045 carbon steel forged part.

A105 forgings are limited to a maximum weight of 4540 kg [10000 lb]. As stated in our quality manual, welding repair of defects in ASTM A105 flanges or fittings is absolutely prohibited by Metals-Piping(although it is permissible by the standard).



Heat Treatment

Heat treatment is not required except for ASTM A 105 carbon steel forging. However, there are some exceptions that will require heat treatment to improve its mechanical properties for better application.

The typical heat treatment conducted for A105 carbon steel forgings includes annealing(A), normalizing(A), normalizing and tempering(NT), quenching and tempering(QT). Especially, normalizing at approximate 950°C for 2.5 hours is often required by many clients to eliminate possible internal stress in the forgings. These materials are usually marked as “ASTM A105N”.



Machinability

Machinability of A105 carbon steel forging is good as for any of the low alloy steels.



Applications

This ASTM specification covers carbon steel forgings for piping applications such as flanges and fittings (45°eblow, 90° eblow, tee, coulping, etc)



A105 Forged Solid Steel Round Bar OD 130MM ASME A105 Boiler 0A105 Forged Solid Steel Round Bar OD 130MM ASME A105 Boiler 1A105 Forged Solid Steel Round Bar OD 130MM ASME A105 Boiler 2
