Product Details:
|
| Width: | 600-2500mm | Grade: | S500MC |
|---|---|---|---|
| Application: | Container Plate | Technique: | Hot Rolled,Cold Rolled |
| Type: | Steel Plate | Standard: | ASTM,AISI,JIS,DIN |
| Length: | 1000-12000mm | Surface Treatment: | Black,hot Finished |
| Special Use: | High-strength Steel Plate | Thickness: | 2.0-60mm |
| Shape: | Flat Steel Plate | ||
| High Light: | seamless Carbon Flat Steel Plate,2.0mm Carbon Automotive Steel Sheet,Cold Rolled Seamless carbon Steel plate |
||
| Grade : | S500MC | |
| Number: | 1.0984 | |
| Classification: | Steel | |
| Standard: |
|
|
| Equivalent grades: |
Chemical composition % of steel S500MC (1.0984): EN 10149-2-1996
| The sum of Nb, V and Ti shall be max 0.22 % If agreed at the time of the enquiry and order the sulfur content shall be max 0.01 % (ladle analysis) |
| C | Si | Mn | P | S | V | Nb | Ti | Al |
| max 0.12 | max 0.5 | max 1.7 | max 0.025 | max 0.015 | max 0.2 | max 0.09 | max 0.15 | min 0.015 |
| Rm - Tensile strength (MPa) | 550-700 |
| ReH - Minimum yield strength (MPa) | 500 |
| Nominal thickness (mm): | to 3 |
| A - Min. elongation Lo = 80 mm (%) | 12 |
| Nominal thickness (mm): | from 3 |
| A - Min. elongation Lo = 5,65 √ So (%) | 14 |
| EU EN |
USA - |
Germany DIN,WNr |
France AFNOR |
Italy UNI |
Sweden SS |
Inter ISO |
|||||||
| S500MC |
|
|
|
|
|
|
