Product Details:
|
| Place Of Origin: | Jiangsu, China (Mainland) | Standard: | ASTM, AISI, DIN, EN, GB, JIS |
|---|---|---|---|
| Material: | Stainless Steel | MOQ: | 1 TON |
| Packing: | Standard Seaworthy Package | Steel Grade: | 304 304L 316 316L 310S 321 |
| Type: | Seamless | Welding Line Type: | Seamless |
| Length: | 3000mm~6000mm | Outer Diameter: | 6-762mm |
| High Light: | 316LMOD seamless stainless steel pipe,EN 1.4435 seamless stainless steel pipe,3000mm seamless stainless steel tube |
||
Stainless Steel 316L MOD Material 724L, 1.4435, 316L MOD Stainless Steel Pipe
We could produce 316LMOD forging parts,316LMOD forged rings, 316LMOD Rolled Rings,316LMOD forging flanges, 316LMOD forging round bars, 316LMOD forged disks, 316LMOD forging bushings,316LMOD forging discs,316LMOD forged tubes, 316LMOD forging sleeves,316LMOD forging tube sheets, 316LMOD forging shafts,316LMOD forging pipes as per the requirement of the client
316LMOD is 316L modified stainless steel with extra-low silicon content and substantial higher molybdenum contents
We could delivery 316LMOD forging material as per the standard of A-182
We use EAF+VOD-ESR melting methods to melt the material of 316LMOD
As per heat treatment of 316LMOD forged parts, it can be Heat from 1050 to 1150oC and water quench. This treatment ensures that all carbides are in solution.
The chemical composition of 316LMOD is as follows:
| Grade | The Element Max (%) | ||||||||
| C | Mn | P | S | Si | Cr | Ni | |||
| 316LMOD | 0.03 | 2.00 | 0.045 | 0.22 | 1.00 | 17.0-18.5 | 13.0-15.0 | ||
| Mo | |||||||||
| 2.00-3.00 | |||||||||
The mechanical property of 316LMOD is as follows:
| Tensile Strength | Min 77KSI | Min 530MPA |
| Yield Strength | Min 41KSI | MIN 280MPA |
| Elongation | Min 55% |
316LMOD is designed for improved corrosion resistance properties in Ureacarbonate environments.
Due to special mechanical properties of 316LMOD forging parts, there are many wide uses as followings:
316LMOD forging rings and 316LMOD forging shafts that is used in used in the Furnace parts. Oil burner parts. Carburising boxes.
316LMOD forged shafts,316LMOD forging pipes, 316LMOD forged tubes ,forged tube sheets, forged flanges that are used separator and heat exchanger parts, in the paper industry, oil and gas production, compressor parts, seawater desalination plants
316LMOD forging shafts,316LMOD forging flanges ,316LMOD forged rings,316LMOD forging pipes that is used in Food Processing – equipment and storage,Petroleum Refining – polythionic acid service.
316LMOD forged bushing,316LMOD forged sleeves,316LMOD forged disks,316LMOD forged discs that is used in Offshore and onshore industry, such as subsea and deepwater offshore oil production systems, industrial air compressors, power generators and nitrogen generators
316LMOD open die forging parts, forged pieces,forging nozzles ,forged crankshaft that is used in Heat Treatment baskets and jigs. Heat exchangers. Welding filler wire and electrodes.
316LMOD forged valve stems, forged valve parts, forged valve seat ring,forged valve blocks,forged bodies that are used in ball valves, check valves, strainers ,globe valve, gate valve,Plug valve and so on
316LMOD forging rings, 316LMOD forging spindles, 316LMOD forging bars,316LMOD forging gears that are used in power transmission, turbine,gas compressor,gear boxes and so on
316LMOD forged products,316LMOD forged nozzles,316LMOD forging eccentric shaft that are used on Waste Treatment – thermal oxidizers,Pharmaceutical Production
316LMOD forged wheels, forged manifold,forged rolls that are used in shipping building,heavy machinery.Paper and Pulp Industries,Pharmaceutical & Biochemistry
Our 316LMOD forging pipes will be Ultrasonic testing as per standard, EN10228-3,Sep1921,ASTM A388 and so on
We could supply 316LMOD super allloy forging parts certificate as per the standard of EN10204-3.1 or EN10204-3.2 of third party
Except 316LMOD forgings, we could also supply 316L Modified forgings material,724L forged materail, ,1.4435 forged parts.316L Mod forged parts
Please send us the size
