Product Details:
|
Commodity: | Stainless Steel Strips & Coils | Thickness: | 0.01mm-8.0mm |
---|---|---|---|
Width: | 1.0 - 1219mm Customs As Request | Standard: | JIS, AISI, ASTM, GB, DIN, EN |
Type: | Coil & Strip | Brand Name: | Baosteel, Tisco, Lisco, Posco |
Surface Finish: | NO.1, 2B , BA , NO.4, 8k, HL | Inner Package: | Waterproof Paper |
Outer Package: | Ooden Box, Woven Bag With Bundles | Application: | Construction, Machine Building |
High Light: | 0.03mm astm stainless steel strip,SUS304L astm stainless steel strip,1219mm stainless steel roll |
304L stainless steel strip is 300 series stainless steel that is one of the most widely used metal strips due to its corrosion resistance and nice fabrication.
Both 304 and 304L stainless steel strips can be used for many similar applications and the differences are minor, but they really do exist.
304L stainless steel strip has lower carbon contents than 304 stainless steel strip.
304L stainless steel strip is widely used in automotive structures, chemical industry, food processing industry, marine environment industry, springs, welded parts and heat exchangers industry.
304L stainless steel strip can be also used in heavy industrial applications, especially in high-corrosion environments.
The chemical components of grade 304L stainless steel strip is summarized in the following table:
Grade | Standard | C | Si | Mn | P | S | Cr | Ni | Mo |
304L | ASTM A240 | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.030 | 18.00-20.00 | 9.00-12.00 | – |
Grade | Standard | Yield Strength Rp0.2 (N/mm²) |
Tensile Strength Rm (N/mm²) |
Elongation % |
Hardness (HV) |
Hardness (HRB) |
---|---|---|---|---|---|---|
201 | ASTM A240 | ≥ 275 | ≥ 520 | ≥ 35 | ≤ 260 | ≤ 101 |
202 | ASTM A240 | ≥ 275 | ≥ 520 | ≥ 40 | ≤ 218 | ≤ 95 |
301 | ASTM A240 | ≥ 205 | ≥ 520 | ≥ 40 | ≤ 200 | ≤ 90 |
304 | ASTM A240 | ≥ 205 | ≥ 515 | ≥ 40 | ≤ 210 | ≤ 92 |
304L | ASTM A240 | ≥ 205 | ≥ 520 | ≥ 40 | ≤ 200 | ≤ 90 |
316L | ASTM A240 | ≥ 177 | ≥ 480 | ≥ 40 | ≤ 200 | ≤ 90 |
316Ti | ASTM A240 | ≥ 205 | ≥ 520 | ≥ 40 | ≤ 200 | ≤ 90 |
317L | ASTM A240 | ≥ 205 | ≥ 515 | ≥ 40 | ≤ 218 | ≤ 95 |
309S | ASTM A240 | ≥ 205 | ≥ 515 | ≥ 40 | ≤ 218 | ≤ 95 |
310S | ASTM A240 | ≥ 205 | ≥ 520 | ≥ 40 | ≤ 200 | ≤ 90 |
Thickness(mm) | Width<125mm | 125mm≤Width<250mm | 250mm≤Width<600mm |
---|---|---|---|
≥0.03-0.10 | ±0.06T | ±0.10T | ±0.10T |
≥0.10-0.15 | ±0.01 | ±0.015 | ±0.020 |
≥0.15-0.20 | ±0.015 | ±0.020 | ±0.025 |
≥0.20-0.25 | ±0.015 | ±0.020 | ±0.025 |
≥0.25-0.30 | ±0.018 | ±0.025 | ±0.030 |
≥0.30-0.40 | ±0.020 | ±0.025 | ±0.030 |
≥0.40-0.50 | ±0.025 | ±0.030 | ±0.040 |
≥0.50-0.60 | ±0.030 | ±0.030 | ±0.040 |
≥0.60-0.80 | ±0.030 | ±0.040 | ±0.040 |
≥0.80-1.00 | ±0.030 | ±0.040 | ±0.050 |
Our company have professional team who can adopt developed packaging technology to assure no any damages of products during transportation.
