Product Details:
|
| Width: | 600-2500mm | Grade: | Asme Sa516 Grade 70 |
|---|---|---|---|
| Application: | Boiler Plate | Technique: | Hot Rolled |
| Type: | Steel Plate | Standard: | ASTM |
| Length: | 1000-12000mm | Special Use: | Pressure Vessel Boiler |
| Thickness: | 6-400mm | Product Name: | Boiler Quality Pressure Vessel Steel Plate |
| Shape: | Flat Steel Plate | Coil Weight: | 3-8 Tons |
| High Light: | low carbon steel plate,high carbon steel plate |
||
The specifications and standards of ASTM A516 Grade 70 and ASME SA516 Grade 70 carbon steel plate are outlined in table 1.
Table 1. Equivalent Specifications and Standards of ASTM A516 Grade 70 / ASME SA516 Grade 70
| Standard | Description |
| ASTM/ASME | A/SA516 - Grade 70 |
| DIN Standard | - |
| British Standard | BS1501-224-490A/B |
| European Norm | EN10028 P355GH |
The chemical composition of ASTM A516 Grade 70 and ASME SA516 Grade 70 carbon steel plate are listed in table 2.
Table 2. Typical Chemical Composition of ASTM A516 Grade 70 / ASME SA516 Grade 70
| Composition | Percentage % | Composition | Percentage % |
| C | 0.10/ 0.22 | Cu | 0.3 |
| Si | 0.6 | Ni | 0.3 |
| Mn | 1/ 1.7 | Mo | 0.08 |
| P | 0.03 | Nb | 0.01 |
| S | 0.03 | Ti | 0.03 |
| Al | 0.02 | V | 0.02 |
| Cr | 0.3 |
The mechanical properties of ASTM A516 Grade 70 and ASME SA516 Grade 70 carbon steel plate are outlined in table 3.
Table 3. Typical Mechanical Values of ASTM A516 Grade 70 / ASME SA516 Grade 70
| Properties | Value |
| Tensile Strength (N/mm2) | 510/ 650 |
| Yield stress/ min (N/mm2) | 335 |
