Product Details:
|
Application: | Construction,Industry,boiler,Chemical | Standard: | DIN,ASTM,JIS,AISI |
---|---|---|---|
Steel Grade: | 300 Series,304 304L 316 316L 310S 321 | Type: | Seamless |
Welding Line Type: | Seamless | Thickness: | 1-95mm |
Length: | 3000mm~6000mm | Shape: | Round.square.Rectangle |
Outer Diameter: | 6-762mm | Technique: | Cold Rolled Hot Rolled,Cold Drawn |
Product Name: | Seamless Stainless Steel Pipes Square Tube Ss316l | Surface: | Annealing,pickling,polishing |
Material: | Stainless Steel | Grade: | 304L 316 316L 310s 321 321H 347 347H |
Finish: | Polished,pickled | Color: | Customerized |
Highlight: | seamless stainless steel tube,ss seamless pipes |
EN10216-5 S30403 / S31603 Plain End Stainless Steel Seamless Pipe In Chemistry And Building
C max | Si max | Mn max | P max | S max | Cr | Ni | N max | |
TP304L | 0.035 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0-20.0 | 8.0-12.0 | -- |
1.4306 | 0.030 | 1.00 | 2.00 | 0.045 | 0.030 | 18.0-20.0 | 10.0-12.0 | 0.11 |
Surface Finish | Annealed, Pickled etc | |||||||
Packing | Bundles/plywood cases | |||||||
Applications | For fluid & gas transport; structure & machining; petrochemical; environmental protection; electricity etc | |||||||
Other standards |
ASTM A270/270M ASTM B667 EN10216-5 JIS G3463 |
Material Grade :
American Standard | Austenitic Steel: TP304,TP304L,TP304H, TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L… Duplex Steel : S32101,S32205,S31803,S32304,S32750, S32760 Others:TP405,TP409, TP410, TP430, TP439,... |
Europen Standard | 1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438, 1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
Industry & Advantage | Application | a) For fluid & gas transport |
b) Structure & machining etc | ||
Advantages | a) Advanced technology of cold draw machine | |
b) Advanced annealing machine | ||
c) Better mechanical property | ||
d) More precise dimension | ||
e) Perfect inspection method and inspection equipment etc |
1 . Our company has been dedicated to producing seamless stainless steel pipe since 2003 , owning complete producing technology and abundant managing experience .
2 . The raw material such as mother tube , round bar we use is from Chinese biggest and well-known steel mill : Walsin , Yongxing etc .
3 . We have advanced NDT equipments for the tests such as Eddy Current test, Ultrasonic test , Hydraulic test and so on .
4 . We have ISO 9001 and PED certificate , and the Third Party Inspection Certificates such as TUV , BV , Lloyd’s , SGS , etc , also can be provided according to customers’ requirements .
MITTEL is a leading manufacturer who is specialized in seamless stainless steel pipes , bright annealed tubes , seamless coiled tubing etc . MITTEL has the most advanced producing and testing equipment . We can totally satisfy your requirement .
Seamless stainless steel pipes final surface are pickling . According to standard very strictly , tubes which produced by us always have correct OD and WT tolerance.
MITTEL has produced seamless stainless steel pipes for 10 years . And our products have been sent to all over the world , such as Europe , America , Turkey etc . FORD , the second chemical group in the world and other companies in the world have used them to .
