ASME- SA789 UNS- S32760 Stainless Steel Seamless Tube / SS Round Pipe

ASME- SA789 UNS- S32760 Stainless Steel Seamless Tube / SS Round Pipe
ASME- SA789 UNS- S32760 Stainless Steel Seamless Tube / SS Round Pipe ASME- SA789 UNS- S32760 Stainless Steel Seamless Tube / SS Round Pipe

Large Image :  ASME- SA789 UNS- S32760 Stainless Steel Seamless Tube / SS Round Pipe

Product Details:
Place of Origin: China
Brand Name: MITTEL
Certification: SGS ISO
Model Number: 32760
Payment & Shipping Terms:
Minimum Order Quantity: 1 ton
Price: 8 USD/KG
Packaging Details: Export Packing
Delivery Time: 7 Days
Payment Terms: L/C, T/T
Supply Ability: 200 Tons

ASME- SA789 UNS- S32760 Stainless Steel Seamless Tube / SS Round Pipe

Description
OD: 6-630MM Thickness: 0.5-60mm
Length: 2000-12000mm Type: Cold Rolled
High Light:

ss seamless pipes

,

astm stainless steel pipe

Super Duplex AccordingTo ASME- SA789 UNS- S32760 Seamless Round Tube



UNS 31803 (F51), UNS 32205 (F60) Alloy 2205, UNS S32550 (F61), UNS S 32750 (F53), Alloy 2507 and UNS 32760 (F55)

Standards: ASTM/ASME A789/SA789, A790/SA790,A450,A530

Material: UNS S31803(Cr22Ni5Mo3/1.4462)/2205,UNS S32750(1.4410),UNS S31500(Cr18NiMo3Si2),

UNS32760(1.4501)





Chemical Composition



Grade

C

max

Si

max

Mn

max

P

max

S

max

Cr Ni Mo N
UNS S32750 0.030 0.8 1.2 0.030 0.015 24.0-26.0 6.0-8.0 3.0-5.0 0.24-0.32
UNS S31803 0.030 1.0 2.0 0.020 0.020 21.0-23.0 4.5-6.5 2.5-3.5 0.08-0.20
UNS S31500 0.030 1.0 1.2-2.0 0.030 0.030 18.0-19.0 4.5-5.5 2.5-3.5 0.05-0.10





Physical Properties



Grade Y.S.MPa min T.S.Mpa min Elongation % Hardness HRC
UNS S32750 550 800 15 20
UNS S31803 450 620 25 20
UNS S31500 440 630 30 20





Duplex Stainless Steel Pipe Application:



Chemical processing, Transport and Storage.

Oil and gas exploration and offshore rigs.

Oil and gas refining.

Marine environments.

Pollution control equipment.

Pulp and paper manufacturing

Chemical process Plant



Standard: ASTM/ASME A/SA789, A/SA790, A/SA928, DIN17456/17458, EN10216-5. After negotiation, we can supply

pipe with customers'requirement.

Material Grade:

UNS EN DIN C % Cr% Ni% Mo% N% Other %
S31803 1.4462 X2CrNiMoN22-5-3 0.030max 21.0-23.0 4.5-6.5 2.5-3.5 0.08-0.20 /
S32205 1.4462 X2CrNiMoN22-5-3 0.030max 22.0-23.0 4.5-6.5 3.0-3.5 0.14-0.20 /
S32101 1.4162   0.040max 21.0-22.0 1.35-1.70 0.10-0.80 0.20-0.25 Cu 0.10-0.80
S32304     0.030max 21.5-24.5 3.0-5.5 0.05-0.60 0.15-0.20 Cu 0.05-0.60
S32750 1.4410 X2CrNiMoN25-7-4 0.030max 24.0-26.0 6.0-8.0 3.0-5.0 0.24-0.32 Cu 0.50max
S32760     0.050max 24.0-26.0 6.0-8.0 3.0-4.0 0.20-0.30 Cu 0.50-1.00





Mechanical Property:



UNS Tensile Strength
Min, Mpa
Yield Strength
Min, Mpa
Elongation in 2 in Or 50mm Min, % Hardness Max,
HRC
S31803 620 450 25 30
S32205 655 485 25 30
S32101 700 530 30 30
S32304 690 450 25 30
S32750 800 550 15 32
S32760 750 550 25 32



Size Range:



Stainless Steel Seamless Tube ASTM A789/A789M: OD: Φ12.7mm-Φ203mm; WT:0.5mm-6.35mm
Stainless Steel Welded Tube ASTM A789/A789M: OD: Φ12.7mm-Φ203mm; WT:0.5mm-4.0mm



Duplex Stainless Steel have a structure that contains both ferrite and austenite. Duplex alloys have higher strength and better stress corrosion cracking resistance than most austenitic alloys and greater toughness than ferritic alloys, especially at low temperatures. The corrosion resistance of duplex alloys depends primarily on their composition, especially the amount of chromium, molybdenum, and nitrogen they contain.



Duplex Steel Pipes , Super Duplex Pipes, A789, A790 , A928 S31803(SAF2205) S32750 (SAF2507) S32760



Duplex Steel Pipes , Super Duplex Pipes, A789, A790 , A928 S31803(SAF2205) S32750 (SAF2507) S32760 Duplex Steel Pipes , Super Duplex Pipes, A789, A790 , A928 S31803(SAF2205) S32750 (SAF2507) S32760 Duplex Steel Pipes , Super Duplex Pipes, A789, A790 , A928 S31803(SAF2205) S32750 (SAF2507) S32760
UNS S31803 Pipe&Tube UNS S32205 Pipe&Tube UNS S32750 Pipe&Tube U Bend Duplex Tube



Standard: ASTM/ASME A/SA789, A/SA790, A/SA928, DIN17456/17458, EN10216-5. After negotiation, we can supply pipe with customers'requirement.

Material Grade:UNS S31803,S32205,S32101,S32304,S32750,S32760,1.4462,1.4410etc.

Size Range:



Stainless Steel Seamless Tube ASTM A789/A789M: OD: Φ12.7mm-Φ203mm; WT:0.5mm-6.35mm
Stainless Steel Seamless Pipe ASTM A790/A790M: OD: Φ6mm-Φ325mm; WT:0.5mm-30mm
Stainless Steel Welded Tube ASTM A789/A789M: OD: Φ12.7mm-Φ203mm; WT:0.5mm-4.0mm



Stainless Steel Welded Pipe

ASTM A790/A790M: OD: Φ10mm-Φ2000mm; WT:0.5mm-40mm

(OD≤630mm for single seam; OD>Φ630mm For circumferential seam)

ASTM A928/A928M: OD: Φ10mm-Φ406mm; WT:0.5mm-10mm.







ASME- SA789 UNS- S32760 Stainless Steel Seamless Tube / SS Round Pipe 4ASME- SA789 UNS- S32760 Stainless Steel Seamless Tube / SS Round Pipe 5
