Grade 1020 Structure 20# 45# 1045 Carbon Smls Steel Pipe

Grade 1020 Seamless Steel Pipe for Structure SMLS Pipe 20# 45# 1045 Carbon Steel Pipe

Cabon steel grade SAE 1020 is a low hardness and low tensile strength alloy. The Brinell hardness of the SAE 1020 Steel Tube ranges between 119 – 235, whereas its tensile strength is between 410 MPa to 790 MPa. Though it lacks some of the characteristics of a conventional carbon steel grade, the SAE 1020 Steel Tube exhibits other important characteristics such as high strength, high machinability, high ductility as well as good weldability. A low carbon content in its chemistry makes the pipe resistant to flame hardening or to induction hardening.

As with all carbon steel alloys, the chemical makeup of the AISI 1020 Pipe majorly constitutes of carbon and iron with elements like manganese, phosphorus and sulfur in very trace amounts. To determine the chemistry of the percentage of elements, the ASTM A519 Tube is subjected to heat analysis. A benefit of using low alloyed steel grades such as the AISI 1020 Carbon Steel Seamless Tubings is that the absence of elements makes them unresponsive to averse situations like nitriding. If the alloy is subjected to carburizing, it is possible to achieve a hardness value of more than Rc65. Although the core strength of A519 cold drawn seamless tubing remains the same as in the supplied condition. This being said, the use of a nitriding treatment on the material could contribute to certain advantages over a conventional carburizing process.

Generally, hot-finished or cold-finished, the carbon steel 1020 is largely used in all automated sectors to enhance properties like weldability or machinability. The specified ASTM A519 Grade 1020 Steel Pipe is well suited for mechanical applications and is often coated with a layer of oil to improve its corrosion resistance properties. The alloy used for A519 cd seamless tube is either strand cast or they could be cast in an ingot.

Specification of our seamless steel pipe

• Dimensions : ASTM, ASME and API
• Size : 10 mm OD to 76 mm OD
• Wall Thickness : 1 mm to 8 mm
• Length : Single Random, Double Random & Required Length
• Schedules : SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules
• Form : Round, Square, Rectangular, Hydraulic Etc
• End : Plain End, Beveled End, Treaded
• End Protection : Plastic Caps

Pipe Process of ASME SA519 1020 Steel tube / ASTM A519 1020 Alloy Steel Seamless tubes:

Round Billet → Material Inspection → Grinding → Cut to Length → Heating → Piercing → Bite mandrel → Hot Rolled → Get Rid of Mandrel → Heat Treatmen t → Size Reducing → Cooling → Straightening → Semi Manufactured Product → Corp End Cutting off → UT/ET TEST or Hydrostatic Test → Marking → Packing → Warehousing

Application of ASME SA519 1020 Steel tube / ASTM A519 1020 Alloy Steel Seamless tubes :
Our ASTM A519 GR. 1020 Boiler Piping is also used in numerous industries such as drainage system, water supplying, oil and gas projects, and many others. The presented ASME SA 519 GR.1020 Boiler Tubes are as well extensively used in a number of industries and house hold channels. These ASME SA 519 GR.1020 Boiler Pipes are being used in transmission line, framing, reinforcement, bracket and trimming. With respect to our rich industry knowledge and experience, we are dedicated in providing ASTM A519 GR. 1020 Boiler Tubes to our admired customers.

Chemical Composition (%) of ASME SA519 1020 Steel tube / ASTM A519 1020 Alloy Steel Seamless tubes :

Other Types of ASME SA 519 / ASTM A519 GR.1020 Pipes and Tubes
