Product Details:
|
| Certification: | API,ISO9001-2000 | Alloy Or Not: | Is Alloy |
|---|---|---|---|
| Technique: | Hot Rolled | Application: | Structure Pipe |
| Special Pipe: | Alloy Structure Steel Pipe | Section Shape: | Round |
| Outer Diameter(round): | 13.7 - 1016 Mm | Length: | 5.8-12m |
| Shape: | Round Shape | ||
| High Light: | heavy steel pipe,structural steel pipes |
||
Quick Detail:
Products:ASTM A335 A335M
Seamless ferritic alloy-steel pipe for high-temperature service
Standard:ASTM A335
Grade:P1, P2, P5, P9, P11, P12, P21, P22, P91, P92
OD. Range:12.7 mm – 114.3 mm
Wall thickness: 0.8 mm-15 mm
Length: Max length 25000mm
Description:
1, Product name
ASTM A335 alloy steel pipe
2, Standard
asme SA213,astm a213, asme SA335, astm a335, A369, A209, A250, G3462, G3467, DIN17175, BS3059-2
3, Material
SA213: T2, T5, T9, T11, T12, T22, T91, T92
SA335: P1, P2, P5, P9, P11, P12, P21, P22, P91, P92
DIN17175: 15Mo3, 13CrMo44, 10CrMo910, 12CrMo195
BS3059: 360, 440, 460, 620
JIS G3458: STPA12, STPA20, STPA22, STPA23, STPA24, STPA25, STPA26
JIS G3462: STPA12, STBA13, STBA20, STBA22, STBA23, STBA24, STBA25, STBA26
4, Outside diameter: 12.7 mm~114.3 mm
5, Wall Thickness: 0.8 mm~15 mm
6, Length: 6m-25m, also can be manufactured by customers' requirements
7, Type: Seamless
8, Type of ends: Plain ends or bevel ends
9, Coating for protection: Can be required according to customers' requirement
Chemical properties (%):
| Material | C | Si | Mn | P | S | Mo | Cr |
| % | % | % | % | max | % | max | |
| A 335 Grade P1 | 0,10 - 0,20 | 0,10 - 0,50 | 0,30 - 0,80 | 0,025 | 0,025 | 0,44-0,65 | |
| A 335 Grade P5 | max. 0,15 | max. 0,50 | 0,30 - 0,60 | 0,025 | 0,025 | 0,45-0,65 | 4,00-6,00 |
| A 335 Grade P11 | 0,05 - 0,15 | 0,50 - 1,00 | 0,30 - 0,60 | 0,025 | 0,025 | 0,44-0,65 |
1,00-1,50 |
| A 335 Grade P12 | 0,05 - 0,15 | max. 0,50 | 0,30 - 0,61 | 0,025 | 0,025 | 0,44-0,65 | 0,80-1,25 |
| A 335 Grade P22 | 0,05 - 0,15 | max. 0,50 | 0,30 - 0,60 | 0,025 | 0,025 | 0,87-1,13 | 1,90-2,60 |
Mechanical properties:
| Material | Tensile N/mm2 | Strength Min. N/mm2 | Yield % min. |
| A 335 Grade P1 | min. 380 | 205 | 30 |
| A 335 Grade P5 | min. 415 | 205 | 30 |
| A 335 Grade P11 | min. 415 | 205 | 30 |
| A 335 Grade P12 | min. 415 | 205 | 30 |
| A 335 Grade P22 | min. 415 | 205 | 30 |
Related Products:
| Standard | Material |
| ASTM A213 | T11/T12/T22 |
| ASTM A210 | A1/C |
| ASTM 192 | / |
| ASTM 179 | / |
| ASTM A335 | P5/P11/P12/P22/P91 |
| DIN 17175 | ST35.8/ST45.8/15Mo3/13CrMo44/10CrMo910 |
| ASTM A 312 | ASTM A312/A213 201,304,304L,316,316L,310,310S,317L/321H /347H/ 31803 |
Applications:
ASTM A335 Seamless Ferritic Alloy-Steel Pipe for High Temperature Service
Competitive Advantage:
we are Asia Leading Steel Pipe & Tube Manufacturer with more than 250,000Tons/Year, >60% shipped to more than 35 Countries.We aims at manufacturing quality pipes & tubes with reasonable and competitive price, good quality for our global customers.
