|Standard:||ASTM, AISI, DIN, EN, GB, JIS||Dimensions:||5.5mm-500mm|
|Type:||Round||Special Use:||Valve Steels|
|Length:||Customers' Requirements||Surface:||Pickled Bright Polished Satin|
stainless steel round rod,
steel round bar stock
High Hardness 17-4PH 17-7PH SS Hardened Steel Rod Bright Finish For Shaft And Bearing
|Name||stainless steel round bar||grade||17-4ph 17-7ph|
|Surface||bright||Diameter||12 - 350mm|
|Length||6 meters or as required||Brand||BAOSTEEL|
|1. Product:||17-4PH 17-7PH stainless steel round bar|
|2. Steel type:||630 stainless steel / same as 17-4PH|
|631 stainless steel / same as 17-7ph|
|Other stainless steel in 200 series 300 series and 400 series|
|3. Standard:||ASTM A564|
|4. Diameter:||From Ø1/4'' to Ø16'' ( Diameter: 6mm~400mm )|
|Such as Ø1'', Ø2'', Ø2.5'', Ø3'', Ø3.5'', Ø4'', Ø4.5'', Ø4.5'', Ø5'',Ø6'', Ø7'', Ø8''|
|5. Length:||1~ 8meters|
|7. Diameter tolerance:||H9, H11, H13, K9, K11, K13 etc…as per clients' request etc|
|8. Length tolerance:||0/+50mm|
|9. Finishing:||Solution treated + age hardening heat treated ( H900, H1100, H1150 etc )|
|10. Feature of 631:||High Tensile strength, high hardness after heat treated.|
|11. Mechanical property:||T.S. (Rm): 1015Mpa, Y.S. (Rp0.2): 906Mpa, EL (A5):17.1%, Z:60.3%, Hardness(HRC): 34.5|
|12. Application:||* Shipbuilding industry, marine shaft, propeller shaft, rudder shaft, boat shaft, vessel shaft,|
|* pump shaft, machine-made industry, valve parts, paper mill equipment.|
|13. Delivery time||Generally within 25 days, as per the q'ty.|
|14. Certificate:||ISO, BV, TUV, SGS, mill test certificate|
|15. Package:||Good quality & fumigated wooden box, can better protect the bars. ( See pictures below )|
Grade 17-4ph stainless steels are martensitic stainless steels that are precipitation hardened to achieve excellent mechanical properties. These steel achieve high strength and hardness following heat treatment. The heat and corrosion resistance of grade 630 are similar to that of grade 304 steels. This grades is also commonly referred to as grade 17-4PH.
Composition ranges for grade 630 stainless steels
Stainless Steel Chemical Composition
|Grade and Main chemical composition%|
Application of stainless steel Round bar
