Product Details:
|
| Standard: | ASTM, AISI, DIN, EN, GB, JIS | Place Of Origin: | Jiangsu, China (Mainland) |
|---|---|---|---|
| Special Use: | Valve Steels | Material: | Stainless Steel |
| Shape: | Round | Surface: | Black, Bright, Grinding |
| Highlight: | 303 Stainless Steel Round Bar,304 Stainless Steel Round Bar,316L Stainless Steel Round Bar |
||
Specifications of Stainless Steel Round Bright Bar 303 304 316L 321 316Ti 431 :
|
Stainless Steel Materials
|
Stainless Steel Bright Round Bar |
| Stainless Grades | 303F/303Cu/304/304L/304F/316/316L/316F/2520/310/2507/416/630/17-4/431 |
| Standard | ASTM,AISI,DIN,EN,GB,JIS |
| Production Standard | ASTM A276, ASTM A582, ASTM A484 |
| Round Bar | Dia: 6mm - 250mm |
| Polish: HR annealed & pickled, HR &Round turned, centerless ground & polish, cold drawn& polished, Soomth tured & polished | |
| Hex Bar | AF: 8mm - 75mm |
| Polish: Cold drawn bright, Annealed, Shot blasting, Sand blasting | |
| Square Bar | AF: 3*10mm - 75*120mm |
| Polish: Cold drawn bright, Annealed, Shot blasting, Sand blasting | |
| Flat Bar | T*W: 8*8mm - 75*95mm |
| Polish: Cold drawn bright, Annealed, Shot blasting, Sand blasting | |
| Inspections | MTC (chemical composition, Mechanical Property), SGS, The Third Party |
| Tolerance | H9, H11, L12 |
| Roundness | +/-0.02mm |
| Roughness | 240 Grits |
| Staightness | 0.01mm/1Meter |
| Stainless steel bar long | As clients's requirements |
| Application | Precision machined components, Screw machined products, CNC turning/mill products, Shaft, Automotive components, Medical and Aerospace and electronic components |
| Production capacity | 200 Tons/ Month |
| Samples | Available, 2 days |
| MOQ | 500KGS (can be mixed sizes) |
| Delivery time | A.7 days if this goods is stock goods. |
| B.20 days if this goods will be produced after order |
|
Material No.
|
EN Designation
|
AISI/SAE
|
UNS
|
|
1.4571
|
X6CrNiMoTi17-12-2
|
316Ti
|
S31635
|
|
Chemical Composition of Stainless Steel 316Ti Round Bar
|
||||||||
|
C≤%
|
Si≤%
|
Mn≤%
|
P≤%
|
S≤%
|
Cr %
|
Mo %
|
Ni≤%
|
Ti≤%
|
|
0.08
|
1.00
|
2.00
|
0.045
|
0.015
|
16.5-18.5
|
2.00-2.50
|
10.5-13.5
|
5*C
|
|
Mechanical Properties 20℃ of Stainless Steel 316Ti Round Bar
|
||||
|
Hardness HB 30
≤ HB |
0.2% Yield Strength Rp
≥N/mm2 |
Tensile Strength Rm
N/mm2 |
Elongation A5
≥% |
Modulus of Elasticity
kN/ mm2 |
|
215
|
200
|
500-700
|
40/30
|
200
|
|
Physical Properties 20℃ of Stainless Steel 316Ti Round Bar
|
|||
|
Density
g/cm3 |
Specific Heat Capacity J/kg K
|
Thermal Conductivity W/m K
|
Electrical Resistivity Ω mm2/m
|
|
8
|
500
|
15
|
0.75
|
