Z275 Hot dip Galvanized Steel Coils , Skin Pass , Astm A653 CSB Galvanized Steel Sheet

Z275 Hot dip Galvanized Steel Coils , Skin Pass , Astm A653 CSB Galvanized Steel Sheet
Z275 Hot dip Galvanized Steel Coils , Skin Pass , Astm A653 CSB Galvanized Steel Sheet Z275 Hot dip Galvanized Steel Coils , Skin Pass , Astm A653 CSB Galvanized Steel Sheet

Large Image :  Z275 Hot dip Galvanized Steel Coils , Skin Pass , Astm A653 CSB Galvanized Steel Sheet

Product Details:
Place of Origin: China
Brand Name: Bao Steel
Certification: ISO,SGS,BV
Model Number: Astm A653 CSB
Payment & Shipping Terms:
Minimum Order Quantity: 10 TON
Price: 700 USD/Ton
Packaging Details: export packing
Delivery Time: 10 days
Payment Terms: L/C, T/T
Supply Ability: 500 tons

Z275 Hot dip Galvanized Steel Coils , Skin Pass , Astm A653 CSB Galvanized Steel Sheet

Description
Grade: A653 CSB Width: 1000-2000mm
Length: 2000-6000mm Spangle: Zero Spangle, Regular Spangle
Technique: Cold Rolled Surface Treatment: Chromated And Oiled
High Light:

hot dipped galvanized steel coils

,

galvanised steel coil

galvanized steel coils are produced by immersing steel in a zinc bath. An appropriate galvanizing process requires a pretreatment process during which the steel passes through different baths which prepare the surface for zinc coating. In this stage, chemicals are used to clean the surface of the steel. After the chemical treatment, the steel coils pass through a bath of melted zinc at temperatures around 460 ° C. The resulting uniform coating is finished through a process of skin-passing to provide smooth and shiny appearance of the finished product. To store for a longer period, the hotdip galvanized coils can be delivered with a final oil coating, according to the customers demand.





product name galvanized steel coils
thickness 0.135mm-4.0mm
width 600mm-1500mm762mm,914mm,1000mm,1200mm,1219mm,1250mm
zinc coating 40g,60g, 80g, 90,100g, 120g, 140g,180g, 200g, 250g, 275g and so on.
standard ASTM, AISI, DIN, GB
material

SGCC,DC51D,DX51D,DX52D,,SGCD,Q195,Q235,SGHC,DX54D, S350 GD,

S450 GD,S550 GD

spangle zero spangle, regular spangle or normal spangle
surface treatment chromated and oiled, chromated and non-oiled
packing export standard.
payment T/T, L/C or DP
min order 25 tons (one 20ft FCL)
coil weight 3-8ton or as client requirement.
quality soft or hard quality



STEEL GRADE CHEMICAL COMPOSITION % MECHANIC PROPERTY C.B OF COATING COATING
C Si Mn S P T.S Y.S E.L
x103 x103 x102 x103 x103 Mpa Mpa % d=0 180° G/M²
JIS G3302 SGCC 12 30 41 31 21 480 300 13 OK Z60-150
JIS G3302 SGCH 12 10 21 18 8 680 650   OK Z60-150
ASTM A653 CS.B 20 30 60 35 30 386 205~380 20 OK Z80-275
DX51D+Z 29 21 18 1.8 11 355 245 38 OK Z80-275
G550 20 6 73 5 17 715 654 8 OK Z80-275





Our advantage:



  1. ISO System;

  2. SGS and BV Audited company;

  3. Management Systems-Internal Software;

  4. Shipment of goods-more than 50 countries;

  5. We have the most convenient transport and prompt delivery;

  6. We offer competitive price with best service;

  7. We have high technical production line with top quality products;

  8. We have won high reputation based on best quality products;

Z275 Hot dip Galvanized Steel Coils , Skin Pass , Astm A653 CSB Galvanized Steel Sheet 0Z275 Hot dip Galvanized Steel Coils , Skin Pass , Astm A653 CSB Galvanized Steel Sheet 1
