TP304 Stainless Steel Welded Tube With Mirror Polish Surface A554 Outside180grits

Large Image : TP304 Stainless Steel Welded Tube With Mirror Polish Surface A554 Outside180grits

Product Details:

Place of Origin:	Wuxi city, Jiangsu province
Brand Name:	BAO STEEL, TISCO, LISCO, ZPSS
Certification:	CE, ISO, BV, SGS
Model Number:	201, 202, 304, 316, 316L

Payment & Shipping Terms:

Minimum Order Quantity:	1 tons
Price:	USD1200-USD2400 per ton
Packaging Details:	Standard seaworthy packaging by protect film.
Delivery Time:	5 days
Payment Terms:	L/C, T/T, Western Union, Paypal
Supply Ability:	3000 tons per month

Contact Now

TP304 Stainless Steel Welded Tube With Mirror Polish Surface A554 Outside180grits

Description

Commodity:	Stainelss Steel Welded Pipe	Outer Diameter:	10mm-120mm
Wall Thickness:	0.25mm-3mm	Material:	201, 202, 304, 316, 316L
Quality:	No.1	Surface:	Bright
Highlight:	stainless steel pipe welding standards , stainless steel welded tube

Stainless Steel Pipe Fitting / Stainelss Steel Welded pipe at factory price

Type	Stainless Steel Pipe Fitting / Stainelss Steel Welded pipe at factory price
Material:	201, 202, 304, 304L, 316, 316L, 201, 430
Standard:	ASTM A554, A312
Length:	30mm ~ 6 meter or any custom made
MOQ:	10 to 1000pcs or more quantity
Payment Terms	T/T, L/C At Sight
Port	FOB Shanghai port
Supply Ability	300 Tons per Month or any sizes stock are available for customer need fast delivery
Delivery Time	7~40 days depends on order quantity
Packing	Each for Poly bag, Carton, Bundle, Steel crate, Wooden crate , Wooden case or customer request.
Surface Polish	Mill Finish, Brush Polish, 320Grit, 400Grit, 600Grit, Mirror Polish, Hair Line Polish and Chrome Plated.
Application	Building material, ornamental tubing, Ship Hardware, Swimming Pool, Grab Bar, ety Products, Exhaust, Kitchen and Bathroom Shelf, Handrail, Ladder.
Note	OEM and ODM is welcome !

Thickness: 0.7-2.8mm

Length: 6m, but customized length available

Finish: Hairline, mirror, bright, satin

Material: ASTM 201, 202, 304, 316

Color: Champagne, rose gold, rose red, coffee gold, black gold, brown, black, red copper, antique copper, brass, titanium, grey, violet, bronze, sapphire, jade green etc.

Chemical Composition
	C	Si	Mn	P≤	P≤	Cr	Mo	Ni	Other
201 mid copper	≤0.15	≤1.00	7.5-10.5	0.06	0.03	13-15	-	0.8-1.5	Cu>0.8
201 high copper	≤0.15	≤1.00	7.5-10.5	0.06	0.03	13-15	-	0.8-1.5	Cu>1.4
304	≤0.08	≤1.00	≤2.00	0.045	0.03	18-20	-	8-10.5	-
304L	≤0.03	≤1.00	≤2.00	0.045	0.03	18-20	-	8-10.5	-
316	≤0.08	≤1.00	≤2.00	0.045	0.03	16-18	2-3	10-14	-
316L	≤0.03	≤1.00	≤2.00	0.045	0.03	16-18	2-3	12-15	-
430	≤0.12	≤0.75	≤1.00	0.04	0.03	16-18	-	≤0.6	°

Finished Treatment

TP304 Stainless Steel Welded Tube With Mirror Polish Surface A554 Outside180grits 0

Stainless Steel Pipe Type

TP304 Stainless Steel Welded Tube With Mirror Polish Surface A554 Outside180grits 1

Diameter of Stainless Steel Pipes

TP304 Stainless Steel Welded Tube With Mirror Polish Surface A554 Outside180grits 2

Parameter

Nominal Diameter(mm)		Outside Diameter(mm)	Nominal Wall Thickness (mm)
N.B	NPS	Outside Diameter(mm)	SCH5S	SCH10S	SCH40S
8	1/4″	13.72		1.65	2.24
10	3/8″	17.15		1.65	2.31
15	1/2″	21.34	1.65	2.11	2.77
20	3/4″	26.67	1.65	2.11	2.87
25	1″	33.4	1.65	2.77	3.38
32	1-1/4″	42.16	1.65	2.77	3.56
40	1-1/2″	48.26	1.65	2.77	3.68
50	2″	60.33	1.65	2.77	3.91
65	2-1/2″	73.03	2.11	3.05	5.16
80	3″	88.9	2.11	3.05	5.49
90	3-1/2″	101.6	2.11	3.05	5.74
100	4″	114.3	2.11	3.05	6.02
125	5″	141.3	2.77	3.4	6.55
150	6″	168.28	2.77	3.4	7.11
200	8″	219.08	2.77	3.76	8.18

Product Applications

•Petroleum, Chemical enterprise, super heater of boiler, heat exchanger

•High temperature resistant transmission fluid pipe in power station

•Ship with pressure pipe

•The exhaust purification device

•Construction and ornament

TP304 Stainless Steel Welded Tube With Mirror Polish Surface A554 Outside180grits 3
