Product Details:
|
| Type: | Heat Exchanger Plate | Application: | Transfer Parts |
|---|---|---|---|
| Width: | 500-2000mm | Length: | 1000-6000mm |
| Thickness: | 0.5-30mm | Packaging: | Plywood Box Packing |
| High Light: | hastelloy c276 plate,hastelloy sheet |
||
ASTM B575 C276 Nickel Hastelloy Plate C276 For Heat Exchangers
*Our production capacity covers more than 300 specification and size plates, the plates function equals to the famous , sondex etc brand PHE manufactures,;
*Plate Port diameter 29mm to Port diameter 328mm, plate width from 125mm to 995mm, height from 429mm to 2245mm,thickness from 0.5-1.0mm.
|
Plate materia |
Applicable fluids |
|
Stainless steel(SU304.316 ect) |
Clean water, river water, edible oil, mineral oil |
|
Stainless steel & Ti, Ti-Pd |
Sea water, salty water, salt compounds |
|
20Cr, 18Ni,SMO |
Dilute sulfuric acid, water solution of salt matter, Inorganic solution |
|
Nickel |
High temperature and high concentration of caustic soda |
|
Hastelloy |
Concentrated sulfuric acid, Hydrochloric acid, Phosphoric acid |
Gasket
We produce and supply many kinds of guasket for plate heat
exchanger,certified by ISO9001,
|
Rubber Type |
Fluorubber |
EPDM |
NBR |
|
Tensile Strength MPa |
≥13 |
≥16 |
≥17 |
|
Elongation % |
≥120 |
≥170 |
≥200 |
|
Shore A Hardness |
80±5 |
80±5 |
75±3 |
|
Tear Strength KN/M |
≤30 |
≤30 |
≤30 |
|
Compressive Deformation |
24h×23≤2.5 |
24h×23≤5 |
24h×23≤2.5 |
|
|
24h×180≤15 |
24h×150≤15 |
24h×125≤15 |
|
Ozone Resistance |
Excellent |
Excellent |
good |
|
Gasket Material |
Applicable Temperature |
Applicable Fluids |
|
NBR |
-15~+135 |
Water seawater, Mineral oil, Saline |
|
EPDM |
-25~+180 |
Hot water, vapor, acid, alkali |
|
F26 |
-55~+230 |
Acid, alkali, fluids |
|
FTP |
0~+160 |
concentrated acid, alkali, High temperature oil, vapor |
hastelloy c 276 plate
Hastelloy C276 1)a nickel-molybdenum-chromium alloy with excellent corrosion resistance in severe environments
Sheet/Plate : ASME SB-575 Round Bar : ASME SB-574 Pipe : ASME SB-622, ASME SB-619, ASME SB-775 Tube : ASME SB-622, ASME SB-516, ASME SB-626 Fittings : ASME SB-366 Forgings : ASME SB-564
