ASTM A249 Stainless Steel Welded SS304 Tube 33.4*2.77*6000mm For Heat Exchanger (Annealed With Pickling Type Surface)

ASTM A249 Stainless Steel Welded SS304 Tube 33.4*2.77*6000mm For Heat Exchanger  (Annealed With Pickling Type Surface)
ASTM A249 Stainless Steel Welded SS304 Tube 33.4*2.77*6000mm For Heat Exchanger  (Annealed With Pickling Type Surface) ASTM A249 Stainless Steel Welded SS304 Tube 33.4*2.77*6000mm For Heat Exchanger  (Annealed With Pickling Type Surface) ASTM A249 Stainless Steel Welded SS304 Tube 33.4*2.77*6000mm For Heat Exchanger  (Annealed With Pickling Type Surface)

Large Image :  ASTM A249 Stainless Steel Welded SS304 Tube 33.4*2.77*6000mm For Heat Exchanger (Annealed With Pickling Type Surface)

Product Details:
Place of Origin: China
Brand Name: TSING SHAN
Certification: ISO SGS MTC
Model Number: 304
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: 2.65-3.68 USD/KG
Packaging Details: Export Packing
Delivery Time: 7 Days
Payment Terms: L/C,T/T
Supply Ability: 50000KGS

ASTM A249 Stainless Steel Welded SS304 Tube 33.4*2.77*6000mm For Heat Exchanger (Annealed With Pickling Type Surface)

Description
Wallthicknessrange: 0.5mm To 3mm Sample: Available
Temperatureresistance: Up To 800°C Depending On Grade Third Party Inspection: BV,SGS,ASP
Model No: 200 300 400 Seires Surface Technique: Matte 2b, Hl, Sb, No.4, 8K, Color
Polish: Bright, Mirror Application: Construction, Automotive, Chemical Industry, Food Processing
Corrosion: Heat Resistant Quality: High
Packing: Ply-Wooden Case End Protector: Plastic Pipe Cap
Service: Customized Size & Surface Section Shape: Round, Square

ASTM A249 Stainless Steel Welded SS304 Tube 33.4*2.77*6000mm For Heat Exchanger  (Annealed With Pickling Type Surface)


Name 304/SS316  Stainless Steel Welded Tube
Standard ASTM, GB, JIS, DIN, EN, AISI
Material Grade TP304 TP304L TP316 TP316L TP347 TP347H TP321 TP321H TP310 TP310S
TP410 TP410S TP403
S31803/S32205 S32750 S32760
Outer Diameter 6mm -2800mm
Thickness 0.65mm - 60mm
Length 5.8-6.1 m or as customers' request
Tolerance Acording to the Standard.
Surface Pickling, sand blast,annealing,varnishing,oiled etc
Test UT, ET, HT, RT,etc, and others according to the standard,or as the requests of the customers
Certificate ISO9001-2008,ASME, PED,ABS,CCS,LR,DNV,TUV,ETC
Delivery Time 15-50Days, Depends on quantity


Importance of stainless steel pipe:
1.Corrosion resistance and high strength: stainless steel pipe has excellent corrosion resistance and high strength, can be used for a long time in a variety of harsh environments, reducing the frequency of maintenance and replacement
2.Safety and hygiene: stainless steel pipe inner wall is smooth, not easy to scale, not easy to breed bacteria and microorganisms, to ensure that the transported water quality is safe and hygienic, to avoid secondary pollution
3.Long service life: due to the good corrosion resistance and pressure resistance of stainless steel pipe, the service life is relatively long, which can reduce the frequency of pipe replacement and reduce the cost of maintenance and replacement
4.Energy saving and environmental protection: stainless steel pipe has a low thermal conductivity, which can reduce the loss of heat energy in the hot water transmission, thus reducing energy consumption


Chemical Composition:





Chemical Composition of Material
Material Composition 201 202 304 316
C ≤0.15 ≤0.15 ≤0.08 ≤0.08
Si ≤1.00 ≤1.00 ≤1.00 ≤1.00
Mn 5.5-7.5 7.5-10 ≤2.00 ≤2.00
P ≤0.06 ≤0.06 ≤0.045 ≤0.045
S ≤0.03 ≤0.03 ≤0.030 ≤0.030
Cr 16-18 17-19 18-20 16-18
N 3.5-5.5 4-6 8-10.5 10-14
Mo       2.0-3.0

Mechanical Property
Material Item    201 202 304 316
Tensile Strength ≥535 ≥520 ≥520 ≥520
Yield Strength ≥245 ≥205 ≥205 ≥205
Extension ≥30% ≥30% ≥35% ≥35%
Hardness (HV) <253 <253 <200 <200

ASTM A249 Stainless Steel Welded SS304 Tube 33.4*2.77*6000mm For Heat Exchanger  (Annealed With Pickling Type Surface)

ASTM A249 Stainless Steel Welded SS304 Tube 33.4*2.77*6000mm For Heat Exchanger  (Annealed With Pickling Type Surface)

ASTM A249 Stainless Steel Welded SS304 Tube 33.4*2.77*6000mm For Heat Exchanger  (Annealed With Pickling Type Surface)

ASTM A249 Stainless Steel Welded SS304 Tube 33.4*2.77*6000mm For Heat Exchanger  (Annealed With Pickling Type Surface)



FAQ :

Q1: What's your terms of payment?
A: 30%T/T as the upfront deposit, 70% before delivery, We will show you the photos and package before you pay the balance.
Q2: What's the terms of delivery?
A: EXW, FOB, CFR, CIF
Q3: What's the terms of packing?
A: Generally,we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers' requirement.
Q4: What's your delivery time?
A: For stocks, we could transport the goods to loading port within 7 work days after we received the deposit.For productionperiod,it usually takes about 15 days to 30 days after we received the deposit.
Q5: Could you produce according to the samples?
A: Yes, we can customer-made by your samples or technique drawings, we can build the mold and fixtures.
Q6: Could you provide the compliment samples?
A: Yes, we could provide the free samples on condition that it is available in stocks, however,the transportation fee is borne by buyer.
Q7: How could you guarantee your products quality?
A: Each piece of products is manufactured by certified workshops, inspected by us piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.
Q8:What are the advantages of your company?
A:(1): Prime quality and reasonable price.
(2): Wide excellent experiences with after-sale service.
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely.
(5): Trial order can be done in one week.
(6): Samples can be provided as your requirements.
