SAE5140 Steel Round Bar Specification Φ18.3x2500mm Cold Drawn Alloy Steel 1.7035/1.7045 HRC 28-32

SAE5140 Steel Round Bar  Specification Φ18.3x2500mm Cold Drawn Alloy Steel 1.7035/1.7045  HRC 28-32
SAE5140 Steel Round Bar  Specification Φ18.3x2500mm Cold Drawn Alloy Steel 1.7035/1.7045  HRC 28-32 SAE5140 Steel Round Bar  Specification Φ18.3x2500mm Cold Drawn Alloy Steel 1.7035/1.7045  HRC 28-32 SAE5140 Steel Round Bar  Specification Φ18.3x2500mm Cold Drawn Alloy Steel 1.7035/1.7045  HRC 28-32

Large Image :  SAE5140 Steel Round Bar Specification Φ18.3x2500mm Cold Drawn Alloy Steel 1.7035/1.7045 HRC 28-32

Product Details:
Place of Origin: China
Brand Name: TSING SHAN
Certification: ISO MTC SGS
Model Number: 40Cr 1.7035/1.7045
Payment & Shipping Terms:
Minimum Order Quantity: 1 Ton
Price: 650-950 USD/TON
Packaging Details: Wooden Pallet
Delivery Time: 7 Days
Payment Terms: L/C, Western Union, T/T
Supply Ability: 500Tons

SAE5140 Steel Round Bar Specification Φ18.3x2500mm Cold Drawn Alloy Steel 1.7035/1.7045 HRC 28-32

Description
Steel Grade: Alloy Steel Alloy Or Not: Is Alloy
Technique: Hot Rolled,Cold Drawn Type: Alloy Steel Bar
Standard: ASTM,DIN Shape: Round
Product Name: 40Cr 1.7035/1.7045 Qt Alloy Steel Round Bars Heat Treatment: Normalized +Annealed +Quenched + Tempered
Highlight:

SAE5140 Steel Round Bar

,

HRC 28-32 Steel Round Bar

,

Φ18.3x2500mm Steel Round Bar

40Cr Steel Round Bar Specification Φ18.3x2500mm Cold Drawn Alloy Steel 1.7035/1.7045 HRC 28-32



General Information
Product Name Grinding Rods
HS Code 72283090
Size Range Length: 1000-6000mm, Diameter: 30-200mm
Specification 45#, 50Mn, 60Mn, 65Mn, B2, B3, B4, B6, BL, BG
Surface Hardness 45-60HRC
Impact Value 12J/cm2
Dropping Test 10,000-20,000 times
Packaging Bundles, Bags, Steel drums, Containers
Size
Diameter (mm) Length (mm)
30-200 1000-6000
Chemical Composition (%)
Steel Specification C Mn Si Cr S P
40Cr 0.37-0.44 0.50-0.80 0.17-0.37 0.80-1.15 0.035 0.035
42CrMo 0.38-0.45 0.50-0.80 0.17-0.37 0.90-1.25 0.035 0.035
60Mn 0.57-0.65 0.70-1.00 0.17-0.37 0.25 0.035 0.035
65Mn 0.62-0.72 0.90-1.20 0.17-0.37 0.25 0.035 0.035
B2 0.72-0.85 0.70-0.90 0.17-0.36 0.40-0.60 0.035 0.035
B3 0.52-0.65 0.40-1.00 1.33-1.85 0.78-1.20 0.030 0.030
BU 0.95-1.05 0.95-1.05 0.15-0.35 0.45-0.55 0.035 0.035
BL 0.55-0.75 0.65-0.85 0.15-0.35 0.70-1.20 0.035 0.035
BG 0.90-1.05 0.35-0.95 0.15-0.35 1.0-1.70 0.035 0.035
Physical Features
Steel Specification Impact Value (J/cm2) Surface Hardness (HRC) Diameter (mm) Length (mm)
40Cr 12 45-60 25-140 1500-6000
42CrMo
60Mn
65Mn
B2
B3
BU
BL
BG

SAE5140 Steel Round Bar  Specification Φ18.3x2500mm Cold Drawn Alloy Steel 1.7035/1.7045  HRC 28-32 0SAE5140 Steel Round Bar  Specification Φ18.3x2500mm Cold Drawn Alloy Steel 1.7035/1.7045  HRC 28-32 1

FAQ

Q: How about the MOQ? If my first order qty is small, will you accept?
A: We would like to do our best to support your trial order qty, so even 1 pc or 1 kg is ok to start cooperation; because we have confidence to move on second order with your esteemed company.

Q: What is your payment terms ?
A: Commonly two payment term for new customers: 1) 30% T/T as deposit , 70% balance against B/L copy; 2) 100% Irrevocable L/C at sight;If you need any other terms, pls feel free to contact us too, we will try our best.

Q: How long is your delivery time?
A: Our daily inventory is more than 8000 tons, so for common product size, just need 5 days from stocks; if the special size from new production, delivery 7 days.

Q: How about the samples ? is it free or extra fees?
A: Yes, we would like to supply the samples before order; if the samples from stock, it will be free; if the samples from new production, we will charge some reasonable cost, but this amount will be deducted from your first order invoice.

Q: How to control and guarantee your shipment quality?
A: 1) All our factories are ISO9001, CE certified facility; 2) World famous origin mills as TISCO, Baosteel. 3) Ex factory inspection by our own laboratory. 4) SGS/BV Third party inspection before delivery.
