250mm 470mm Dia EN 10085 31crmov9 DIN 17211 Alloy Steel Forgings Round Bar

Name: 250mm 470mm Dia EN 10085 31crmov9 DIN 17211 Alloy Steel Forgings Round Bar
Brand: JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
SKU: 1.8519 31CrMoV9 QT
Price: 0.65 USD
Availability: InStock

All Products

Stainless Steel Sheet
(398)

Stainless Steel Plates
(342)

Stainless Steel Coils
(202)

Stainless Steel Flat Bar
(84)

Stainless Steel Round Bar
(390)

Stainless Steel Angle Bar
(63)

Steel Round Bar
(212)

Stainless Steel Welded Pipe
(141)

Stainless Steel U Channel
(56)

Stainless Steel Seamless Tube
(204)

Seamless Steel Pipe
(107)

Hastelloy Plate
(62)

Copper Products
(60)

Ship Steel Plate
(41)

Alloy Steel Plate
(84)

Carbon Steel Plate
(134)

Galvanized Steel Coils
(157)

Galvanized Steel Pipe
(15)

Best Products

DIN WNr 41Cr4 / 1.7035 40Cr Diametr 250-500mm Forged Steel Round Bar SCR440 Alloy Bar

Tool Steel Forged 1.6582 4337 34CrNiMo6 Hot Rolled QT Alloy Steel Round Bar OD 130MM

42CrMo4 Q+T Φ25x2500mm Cold Drawn Alloy Steel Bar 42CrMo4 Normalized Quenched

Certification

Customer Reviews

this is the second order l buy this company ,quality is very good ,same as europure quality .we will go on ccooperate with this company .

—— Andrew Greg - Turkey

200 ton Stainless steel sheet is arrived on 10th Oct 2014 , the quality is very good.,deliver time is very fast It's very lucky we find this factory

—— Mechile Kilar Chard - Brazial

We Have Cooperate With this Factory Many Years , Everything Goes Very Well.l Like This Factory ！

—— Tony Hilton - Poland

This is Our Thrid Time Buy from Mittel,Quality is Very Goods ,We Are Glad to Find This Reliable Factory

—— Natalya Ugay-Russia

Quality is very good and delivery time very fast ,we want to do long terms business with this company

—— Pongpol Pluemsati-Thailand

I'm Online Chat Now

250mm 470mm Dia EN 10085 31crmov9 DIN 17211 Alloy Steel Forgings Round Bar

Large Image : 250mm 470mm Dia EN 10085 31crmov9 DIN 17211 Alloy Steel Forgings Round Bar

Product Details:

Place of Origin:	China
Brand Name:	TSING SHAN
Certification:	ISO SGS MTC
Model Number:	1.8519 31CrMoV9 QT

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Price:	0.65-1.85 USD/KG
Packaging Details:	Export Packing
Delivery Time:	7 Days
Payment Terms:	L/C, T/T
Supply Ability:	50000KGS

Contact Now

250mm 470mm Dia EN 10085 31crmov9 DIN 17211 Alloy Steel Forgings Round Bar

Description

Mechanical Properties:	As Standard	Hs Code:	7312000
Transport Package:	Nude Packing Or As Requested	Heat Treatment:	Available
Strength:	High	Package:	Export Standard Package/as Request
Price Term:	EXW,FOB,CIF,CFR	Products Name:	Alloy Steel Round Bar
Secondary Or Not:	Non-secondary	Mtc:	EN10204 3.1
Corrosion Resistance:	Yes	Product:	Steel Round Bar
Density:	8.83 G/cm3	Technique:	Hot Rolled
Highlight:	DIN 17211 Round Bar , 31crmov9 Round Bar , 250mm Round Bar

250mm 470mm Dia EN 10085: 31crmov9 DIN 17211 Alloy Steel Forgings Round Bar

Detail Page

Product Name	31CrNoV9 33CrMoV12-9 34CrAlNi7-10 41CrAlMo7-10 1.8519 1.8522 1.8550 1.8509 alloy steel bar/rod
Material	31CrNoV9 33CrMoV12-9 34CrAlNi7-10 41CrAlMo7-10 1.8519 1.8522 1.8550 1.8509
Standard	AISI,ASTM,GB,DIN,EN,BS,JIS
Technique	Hot rolled,cold rolled
Surface	No.1,2B,BA
Diameter	3-480mm or as required
Length	3000mm,4000mm,5800mm,6000mm,12000mm or as required
Tolerance	±5%
MOQ	1TON
Trade Terms	EXW,FOB,CFR,CIF
Payment Terms	30% TT for deposit,70% TT/70% LC at sight balance before shipment.
Delivery time	Shipped in 7-15 days after payment.
Package	Standard sea-worthy package or as required.

Product Description

Description
Item	1.8519 alloy steel bar 31CrMoV9 steel bar factory price
Steel grade	31CrMoV9
Standard	EN 10085: 2001
Material	alloy steel
Surface	black or according to customer's request
Type	hot rolled,cold rolled

Chemical composition % of steel 31CrMoV9 (1.8519): EN 10085-2001

C	Si	Mn	P	S	Cr	Mo	V
0.27 - 0.34	max 0.4	0.4 - 0.7	max 0.025	max 0.035	2.3 - 2.7	0.15 - 0.25	0.1 - 0.2

Mechanical properties of steel 31CrMoV9 (1.8519)

Nominal thickness (mm):	16 - 40	40 - 100	100 - 160	160 - 250
Rm - Tensile strength (MPa) (+QT)	1100-1300	1000-1200	900-1100	850-1050

Nominal thickness(mm):	16 - 40	40 - 100	100 - 160	160 - 250
Rp0.2 0.2% proof strength (MPa) (+QT)	900	800	700	650

KV - Impact energy (J) (+QT)

+20°
25-40

Nominal thickness (mm):	16 - 40	40 - 100	100 - 160	160 - 250
A - Min. elongation at fracture (%) (+QT)	9	10	11	12

Brinell hardness (HB): (+A)

248

COLD WORK TOOL STEEL
Grade	AISI /ASTM	DIN (W.Nr)	JIS	EN/ BS	GB
DC53	higher than D2		SKD11	XW-5	Cr8Mo2Vsi
D2	D2	1.2379	SKD11	BD2	CR12MO1V1
Cr12MoV					CR12MOV
D3	D3	1.2080	SKD1	BD3	CR12
O1	O1	1.2510	SKS3		9CRWMN
HMD5		HMD5			7CrSiMnMoV
5CrNiMo	L6	55NiCrMoV6	SKT4		5CrNiMo
52100	52100	1.3505		EN31	GCR15
HOT WORK TOOL STEEL
H13	H13	1.2344/1.2342	SKD61/DAC	8407	4CR5MOSIV1
FDAC		1.2347	FDAC		FDAC
H11	H11	1.2343	SKD6		H11
3Cr2W8V	H21	1.2581/ X30WCrV93	SKD5	BH21	3CR2W8V
PLASTIC MOULD STEEL
P20	P20	1.2311	HPM7/PX88	618	3CR2MO
718	P20+NI	1.2738	PX4/PX5	718	3CR2NIMO
S136	420	1.2083	S-STAR	S136	4CR13
NAK80	P21 /P20+S	1.2312	NAK80		15NI3MN
HIGH SPEED STEEL
M2	M2		SKH51		W6MO5CR4V2
M42	M42	S2-10-1-8	SKH59		W2MO9CR4VCO8

ALLOY STRUCTURE STEEL
Grade	AISI /ASTM	DIN (W.Nr)	JIS	EN/ BS	GB
5120	5120	1.7027 /21Cr4	SCr420		20Cr
530M40 /5140	530M40 /5140	1.7035 /41Cr4	SCr440		40Cr
5145	5145		Scr445		45CR4
4118	4118	1.7243 /18CrMo4	SCM418 / SCM420		20CrMo
4135	4130	1.7218 /25CrMo4	SCM430	708A25/ 708M25	30CrMo
4140	4140	1.7225 /42CrMo4	SCM440	EN19/ 709M40	42CrMo
4340	4340	1.6582/ 34CrNiMo6	SNCM 439/ SNCM8	EN24/ 817M40	40CrNi2Mo
8620	8620	1.6523/ 21NiCrMo2	SNCM220	805M20	20CrNiMo
CARBON STEEL
20	1020	C22. CK22	S20C	EN3B /070M20	20
35	1035	C35.CK35	S35C		35
45	1045	C45.CK45	S45C	EN8D/C45E	45
50	1050	CK53	S50C	EN9/070M55	50
Q355		S355J /ST52		EN14	Q355
30Mn	1030.1033		S30C		30Mn
30Mn2	1330	30Mn5	SMn433h		30Mn2
STAINLESS STEEL
steel grades: 304, 304L, 316, 316L, 321, 410 430, 431, 2205, 2304, 2507. F53, F55

250mm 470mm Dia EN 10085 31crmov9 DIN 17211 Alloy Steel Forgings Round Bar 0

250mm 470mm Dia EN 10085 31crmov9 DIN 17211 Alloy Steel Forgings Round Bar 1

250mm 470mm Dia EN 10085 31crmov9 DIN 17211 Alloy Steel Forgings Round Bar 2

Q: Are you trading company or manufacturer ?

A: We are factory and trading company

Q: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
