SUH409L UNS S40910 Hot Rolled Stainless Steel Plate 1D Finished 3.5mm 409L

Large Image : SUH409L UNS S40910 Hot Rolled Stainless Steel Plate 1D Finished 3.5mm 409L

Product Details:

Place of Origin:	China
Brand Name:	TISCO,BAO STEEL
Certification:	ISO
Model Number:	409L

Payment & Shipping Terms:

Minimum Order Quantity:	2 Tons
Price:	USD 1250-1800/Ton
Packaging Details:	export packing
Delivery Time:	10 days after receive the deposit
Payment Terms:	L/C, T/T
Supply Ability:	2000tons per month

Contact Now

SUH409L UNS S40910 Hot Rolled Stainless Steel Plate 1D Finished 3.5mm 409L

Description

Surface:	2B 1D	Thickness:	3-10mm
Width:	1000,1219,1500mm	Lengh:	2000,2438,3000
Standard:	ASTM, AISI, DIN, EN, GB, JIS	Type:	Plate, Sheet Plate Coil
Feature:	Corrosion Resistance High Temperature	Commodity:	Stainless Steel Plate 409L
Port:	Shanghai	Application:	Food Industry, Chemical Industry, Construction, Etc.
Panel Thickness:	8 Mm	Durability:	Long-lasting
Quality:	Prime Grade	Weight:	Lightweight
Raw Material:	Plate Rolling	Material:	Stainless Steel
Finishing:	Powder Coated	Certifications:	ISO, ASTM, EN
Highlight:	Hot Rolled 3.5mm Stainless Steel Plate , 1D Finished Stainless Steel Plate , 409L Stainless Steel Plate

SUH409L UNS S40910 Stainless Steel Plate 1D Finished 3.5mm Hot Rolled 409L Plate

SPECIFICATION

Specifications	ASTM A240 / ASME SA240
Dimensions	ASTM, ASME and API
Standard	JIS, AISI, ASTM, GB, DIN, EN, etc.
Surface	2B, 2D, BA, NO.4, NO.8, 8K, Mirror,Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching
Width	1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm,etc.
Finish	Black,Bright Polished,Rough Turned,No.4 Finish,Matt Finish,BA Finish
Length	2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc.

CHEMICAL COMPOSITION OF STAINLESS STEEL 409L PLATES

Grade	C	Mn	Si	S	P	Cr	Ni	Ti
SS 409L	0.03 max	1.00 max	1.00 max	0.030 max	0.040 max	10.50-11.70	1.5 max	-

MECHANICAL PROPERTIES OF ASTM A240 STAINLESS STEEL 409L SHEETS

Element	Density	Tensile Strength	Yield Strength (0.2%Offset)	Elongation	Hardness
SS 409L	7.8 g/cm3	MPa – 380	MPa – 170	20 %	Rockwell B (HR B)- 88 / Brinell (HB)- 0.5t

Stainless steel plate surface description

Finish Designation	Method and degree of finish
No.1	After hot rolling, heat treatment, pickling or other equivalent treatment is applied.
No.2D	Annealing and pickling are performed after cold rolling; material is soft with surface of silver-white luster; used for general applications and deep drawing.
No.2B	After 2D finish, skin pass rolling is performed to obtain a more suitable luster; the surface becomes very exquisite; used for general applications.
No.3	Intermediate 100-120 grit finish; used for applications in which surface polishing is performed after shaping.
No.4	General 150-180 grit finish; used for restaurants and kitchen equipment and tools.
#240	240 grit finish; used when a finer finish than No. 4 is required; typically for restaurants and kitchen equipment and tools.
#320	320 grit finish polished product.
HL	This finish is performed by continuous linear polishing using an abrasive of appropriate grain size; mainly used for architectural applications.
BA	Achieved by performing bright annealing after cold rolling and then skin pass rolling to obtain even greater reflectance; provides excellent corrosion resistance; used for household appliances, kitchen equipment, and automobiles.
8K	Through multiple grinding, it achieves very high brightness and smoothness, like a mirror.

SUH409L UNS S40910 Hot Rolled Stainless Steel Plate 1D Finished 3.5mm 409L 0

SUH409L UNS S40910 Hot Rolled Stainless Steel Plate 1D Finished 3.5mm 409L 1

Q1. What are your company's main products ?
A1: Our main products are stainless steel plate/sheet, coil, round/square pipe, bar, channel, etc.

Q2. Where is your factory ?
A2: Our company's processing center is located in Jiangsu, Wuxi, China.
Which is well equipped with kinds of machines, such as laser cutting machine,mirror polishing machine and so on.
We can provide a wide range of personalized services according to the customers' needs.

Q3:How to confirm the Product Quality before placing orders?
A3:You can get free samples for some products,you only need to pay the shipping cost or arrange a courier to us and take the samples. The third-party will be accepted.

Q4. What are the advantages of your company ?
A4: We have many professionals, technical personnel, more competitive prices and best after-dales service than other stainless steel companies.

Q5. How many coutries you already exported ?
A5: Exported to more than 50 countries mainly from America, Russia, UK, Kuwait, Egypt,Turkey, Jordan, India, etc.

Q6:What is your delivery time?

A6: For stocks, we could transport the goods to loading port within 7 days after we received your deposit

For production period, it usually takes about 15 days-30 days after receiving the deposit.

Q7. Can you provide sample ?
A7: Small samples in store and can provide the samples for free.
Customized samples will take about 5-7days.
