EN 10084-2008 DIN 1.7131 200mm Alloy Steel Round Bar 16mncr5H Steel SAE 51204

Large Image : EN 10084-2008 DIN 1.7131 200mm Alloy Steel Round Bar 16mncr5H Steel SAE 51204

Product Details:

Place of Origin:	China
Brand Name:	Lai Steel
Certification:	SGS ISO
Model Number:	16MnCr5

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Price:	0.65-0.95USD/KG
Packaging Details:	Export Packing
Delivery Time:	7-10 Days
Payment Terms:	L/C, T/T
Supply Ability:	50000KGS

Contact Now

EN 10084-2008 DIN 1.7131 200mm Alloy Steel Round Bar 16mncr5H Steel SAE 51204

Description

OD:	6-400MM	Length:	5800 6000mm 9000mm
Surface:	Black	Standard:	GB ASTM
DIN Standard:	EN 10084 : 2008	Condition:	End Quenchh Test Quenching
Highlight:	16mncr5H Steel Round Bar , SAE 51204 Steel Round Bar , 200mm Steel Round Bar

EN 10084-2008 DIN 1.7131 200mm Alloy Steel Round Bar 16mncr5H Steel SAE 51204

Grade :	16MnCr5
Number:	1.7131
Standard:	EN 10084 : 2008 Case hardening steels. Technical delivery conditions EN 10132 - 2 : 2000 Cold rolled narrow steel strip for heat treatment. Technical delivery conditions. Case hardening steels
Classification:	Case hardening steels
Equivalent grades:	Go here

16MnCr5 EN 10084-1998, Number: 1.7131	Comparison of steel grades
	JUS	Č.4320
	DIN	16MnCr 5; ZF 6
	BS	590M17,
	GOST	18HG
	AISI	SAE 5115, SAE 51204
	UNI	16MnCr5
	NF	16MC5

Chemical composition (cast analysis)

Chemical elements	C	Si max.	Mn	P max.	S	Cr
%, by mass	0,14-0,19	0,40	1,00-1,30	0,035	≤ 0,035	0,80 – 1,10
Permissible deviation	± 0,02	+ 0,03	± 0,05	+ 0,005	+ 0,005	± 0,05

Hardness limits for steel

Hardness HRC at a distance from quenched end of test piece (in milimetres) of
mm		1,5	3	5	7	9	11	13	15	20	25	30	35	40	45	50
+H	max.	47	46	44	41	39	37	35	33	31	30	29	28	27	-	-
+H	min.	39	36	31	28	24	21	-	-	-	-	-	-	-	-	-
+HH	max.	47	46	44	41	39	37	35	33	31	30	29	28	27	-	-
+HH	min.	42	39	35	32	29	26	24	22	20	-	-	-	-	-	-
+HL	max.	44	43	40	37	34	32	30	28	26	25	24	23	22	-	-
+HL	min.	39	36	31	28	24	21	-	-	-	-	-	-	-	-	-

Hardness requirements for products delivered in the conditions ’’treated to improve shearabilita’’ (+S), ’’anneled to maximum hardness requirements’’ (+A), ’’treated to hardness range’’ (+TH) or ’’treated to ferrite-pearlite structure and hardness range’’ (+FP)

Brinell hardness in the condition
+S max.	+A max.	+TH			+FP
		min.		max.	min.	max.
*	207	156	207		140	187

Non-metallic inclusions Requirements for microscopic degree of purity when tested in accordance with DIN 50 602 (method K) (valid for oxidic non-metallic inclusions)

D (mm) Bars Diameter d (mm)	K Total characteristic value K (oxides) for the individual cast
140 < d 200	K 4 ≤ 50
100 < d ≤ 140	K 4 ≤ 45
70 < d ≤ 100	K 4 ≤ 40
35 < d ≤ 70	K 4 ≤ 35
17 < d ≤ 35	K 3 ≤ 40
8 < d ≤ 17	K 3 ≤ 30
d ≤ 8	K 2≤ 35

Conditions for heat treating test bars and treatment of the steels

End quenchh test Quenching, 0C	Carbunnzing temperature, 0C	Core-hardening temperature, 0C	Case-hardening temperature, 0C	Tempering, 0C
870	880 to 980	860 to 900	780 to 820	150 to 200

EN 10084-2008 DIN 1.7131 200mm Alloy Steel Round Bar 16mncr5H Steel SAE 51204 0
