31crmov09 Q+T 1.8519 Alloy Steel Round Bar Rod 30-500mm Hot Rolled And Forged Nitriding Steel Rod

Large Image : 31crmov09 Q+T 1.8519 Alloy Steel Round Bar Rod 30-500mm Hot Rolled And Forged Nitriding Steel Rod

Product Details:

Place of Origin:	China
Brand Name:	TSING SHAN
Certification:	ISO SGS MTC
Model Number:	31CrMoV09

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Price:	1.05-2.45 USD/KG
Packaging Details:	Export Packing
Delivery Time:	7 Days
Payment Terms:	L/C, T/T
Supply Ability:	50000KGS

Contact Now

31crmov09 Q+T 1.8519 Alloy Steel Round Bar Rod 30-500mm Hot Rolled And Forged Nitriding Steel Rod

Description

Technique:	Hot Rolled	Hardness:	HRC 20-25
Thickness:	1.2 - 50 Mm	Origin:	China
Size Range:	20~200mm	Condition:	Heat Treatments
Package:	Export Standard Package/as Request	Alloy Or Not:	Is Alloy
Tolerance:	Standard	Stock:	Yes
Shape:	Round	Physical Properties:	Specific Gravity 7.85
Elongation:	15-20%	Products Name:	Alloy Steel Round Bar
Highlight:	alloy steel round bar rod , 30mm alloy steel round bar rod , 500mm alloy steel round bar rod

Steel Round Bar 31CrMoV09 Q+T 1.8519 Alloy Rod 30-500mm Hot Rolled and Forged Nitriding Steel Rod

Main Grade we can supply for forged steel bars

Steel series	Representative steel type
Carbon Steel series	AISI 1020,1045,A36,S355JR,S355JO
Petroleum machinery series	AISI4150,AISI4140,AISI4130,
Petroleum machinery series	30CrMo,4145H
Tool mold series	1.2714,5CrMnMo,5CrNiMoV,
Tool mold series	1.2738,1.2311,1.2312 1.2714 H13
Bearing series	52100,GCr15,SUJ2
Marine series	4140,42CrMo,SCM440,
Marine series	709M40
Car series	SAE8620,20CrNiMo,
Car series	SNCM220
Heavy-duty transmission series	40CrNiMo,SNCM439,
Heavy-duty transmission series	SAE4340,EN24
Mining machinery series	655M13,826M40,
Mining machinery series	25CrMo
Wind power gear series	18CrNiMo7-6, 17CrNiMo6, 1.6582,1.6587,SAE8620
Wind power spindle series	34CrNiMo6,817M40
Nitriding series	20MnCr5,38CrMoAl,
Nitriding series	31CrMoV9
Pressure vessel series	15CrMo,13CrMo4-4
Metallurgical roll series	21CrMoV511,W1.7225,
Metallurgical roll series	EN19,709M40

31CrMoV9 Hot rolled and Forged steel round is under JIS G4053-2003 standard. It is a king of pinion steel. 31CrMoV9features good performance for heat treatment. The cutting process is good after do the normalizing treatment. Good quenching, can do quenching depth. 31CrMoV9 have the good processability under high temperature.

31CrMoV9 Hot rolled and Forged steel round bar Common size:
Common diameter for hot rolled steel bar: 16mm to 80mm
Common diameter for forged steel bar: 80mm to 1200mm

31CrMoV9 Package: standard seaworthy packing or as customer required

31CrMoV9 Hot rolled and Forged steel round bar Tolerance:
Diameter tolerance: 0~5mm, Length tolerance:0~20mm
straightness: 3mm/1000mm

31CrMoV9 Hot rolled and Forged steel round bar Delivery condition:
Hot forged +Normalized+rough turned Q/T:Quench+ Temper Annealing

EAF ARC FURNACE + LF REFINING+ VD + FORGING (DOUBLE) + FIXED LENGTH + SEP1921C/c TESTING

31CrMoV9 Hot rolled and Forged steel round barChemical composition

Grade	C	Si	Mn	P	S	Cr	Ni	V	Mo
31CrMoV9	0,27 ~ 0,34	0.4	0.4~0.7	≤0.030	≤0.035	2.3~2.7	~	~	0.15~0.25

31CrMoV9 Hot rolled and Forged steel round bar Mechanical property

Tensile strength	Yield strength	Elongation	Impact value	Grade
σb (MPa) Min	σb (MPa) Min	δ5 (%)Min	Akv (J)Min	Grade
1100~1300	800	10	30	31CrMoV9

Forged Steel Size we can supply:

Forged Steel Round Bar	Φ85mm~1200mm
Forged Square steel Bar:	150×150-800×800mm
Forged Flat Blocks:	(150mm-800mm)*(200mm-800mm)
Forged Shaft and Forged Ring	According to Customer's drawing

Inspecting:
UT according toSEP1921 C/c, D/d, E/e, A388 or GB/T 6402,
Spectral Tested, Microstructure Tested,Hardness Test,Macrostructure Test,

.Delivery Condition:
Forged+black surface
Forged+rough machined
Forged+rough turned+QT/annealed/normalized
Surface condition: Black; Peeled; Polished; Machined; Grinded; Turned; Milled
7.Manufacture:EAF+LF+VD(Annealed,normalized,Quenched+Tempered,peeled,rough turned).
8.Heat Treatment: Normalized / Annealed / Quenched / tempered (optional)
