MS Plate 50X2500X3000MM ASTM SA516 SA516 G70 Hot Rolled Mild Carbon Steel Plate

MS Plate 50X2500X3000MM  ASTM SA516 SA516 G70 Hot Rolled Mild Carbon Steel Plate
MS Plate 50X2500X3000MM  ASTM SA516 SA516 G70 Hot Rolled Mild Carbon Steel Plate MS Plate 50X2500X3000MM  ASTM SA516 SA516 G70 Hot Rolled Mild Carbon Steel Plate MS Plate 50X2500X3000MM  ASTM SA516 SA516 G70 Hot Rolled Mild Carbon Steel Plate

Large Image :  MS Plate 50X2500X3000MM ASTM SA516 SA516 G70 Hot Rolled Mild Carbon Steel Plate

Product Details:
Place of Origin: China
Brand Name: TSING SHAN
Certification: ISO SGS MTC
Model Number: ASTM SA516 SA516 G70
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: 0.65 USD/KG
Packaging Details: Export Packing
Delivery Time: 7 Days
Payment Terms: L/C, T/T
Supply Ability: 50000KGS

MS Plate 50X2500X3000MM ASTM SA516 SA516 G70 Hot Rolled Mild Carbon Steel Plate

Description
Application: Container Plate,construction,Boiler Plate Technique: Hot Rolled
Surface Treatment: Black Standard: ASTM,AISI
Length: 1000-12000mm Type: Steel Plate
Width: 1000mm-2000mm Grade: Alloy Steel Plate
Surface: Black Price Term: CIF CFR FOB EX-WORK
Highlight:

MS Plate 50X2500X3000MM

,

3000MM Mild Carbon Steel Plate

MS Plate 50X2500X3000MM ASTM SA516 SA516 G70 Hot Rolled Mild Carbon Steel Plate



Specification :

Width:1000mm-4500mm
Thickness:5mm-150mm
Length:3000mm-18000mm
Supply Condition :As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested :-52° C
Tempering:Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F.
Applications :Excellent choice for service in lower than ambient temperature applications, has excellent notch toughness and is used in both pressure vessels and industrial boilers.
Process of Manufacturing :Hot-Rolled (HR)

Equivalent Standard :

British Standard European Norm ASTM/ASME DIN
BS1501-224-490A/B EN10028 P355GH A/SA516 - Grade 70 -

Chemical Composition :

C Si Mn P S Al Cr Cu Ni Mo Nb Ti V
0.10/ 0.22 0.6 1/ 1.5 0.025 0.025 0.02 0.3 0.3 0.3 0.08 0.01 0.03 0.02

Mechanical Properties :

Tensile strength MPa (ksi) Yield strength MPa (ksi) Elongation min, % 200 mm (8 in) Elongation min, % 50 mm (2 in)
485-620 (70-90) 260 (38) 17 21



MS Plate 50X2500X3000MM  ASTM SA516 SA516 G70 Hot Rolled Mild Carbon Steel Plate 0MS Plate 50X2500X3000MM  ASTM SA516 SA516 G70 Hot Rolled Mild Carbon Steel Plate 1



 Q: Are you trading company or manufacturer ?
A: We are professional manufacturer with rich experience, and our company also is a very professional a trade company for steel products.We can also provide a wide range of steel products.

Q: Will you delivery the goods on time?
A: Yes,we promise to provide best quality products and delivery on time.Honesty is our company's tenet.

Q: Do you provide samples ?
A: Yes we can provide samples. Please contact us for more details.

Q: Do you accept the third party inspection?
A: Yes absolutely we accept.

Q: How could you guarantee your products?
A: Each piece of products is manufactured by certified workshops, inspected by Jurong company piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.

Q: How can I get your quotation as soon as possible?
A: The email and fax will be checked within 24 hours,meanwhile,the Skype,Wechat and WhatsApp will be online in 24 hours.Please send us your requirement and order information,specification(Steel grade,size,quantity,destination port),we will work out a best price soon.
