Nitriding Steel Round Bar D 470 mm Material 1.8519 31crmov9 Qt Forged Steel Soild Rod

Large Image : Nitriding Steel Round Bar D 470 mm Material 1.8519 31crmov9 Qt Forged Steel Soild Rod

Product Details:

Place of Origin:	China
Brand Name:	TSING SHAN
Certification:	ISO SGS MTC
Model Number:	1.8519 31CrMoV9 QT

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Price:	0.65-1.85 USD/KG
Packaging Details:	Export Packing
Delivery Time:	7 Days
Payment Terms:	L/C, T/T
Supply Ability:	50000KGS

Contact Now

Nitriding Steel Round Bar D 470 mm Material 1.8519 31crmov9 Qt Forged Steel Soild Rod

Description

Mechanical Properties:	As Standard	Hs Code:	7312000
Transport Package:	Nude Packing Or As Requested	Heat Treatment:	Available
Strength:	High	Package:	Export Standard Package/as Request
Price Term:	EXW,FOB,CIF,CFR	Products Name:	Alloy Steel Round Bar
Secondary Or Not:	Non-secondary	Mtc:	EN10204 3.1
Corrosion Resistance:	Yes	Product:	Steel Round Bar
Density:	8.83 G/cm3	Technique:	Hot Rolled
Highlight:	nitriding steel round bar , forged steel soild rod , 470mm steel round bar

Nitriding Steel Round Bar D 470 mm Material 1.8519 31CrMoV9 QT Forged Steel Soild Rod

Detail Page

Product Name	31CrNoV9 33CrMoV12-9 34CrAlNi7-10 41CrAlMo7-10 1.8519 1.8522 1.8550 1.8509 alloy steel bar/rod
Material	31CrNoV9 33CrMoV12-9 34CrAlNi7-10 41CrAlMo7-10 1.8519 1.8522 1.8550 1.8509
Standard	AISI,ASTM,GB,DIN,EN,BS,JIS
Technique	Hot rolled,cold rolled
Surface	No.1,2B,BA
Diameter	3-480mm or as required
Length	3000mm,4000mm,5800mm,6000mm,12000mm or as required
Tolerance	±5%
MOQ	1TON
Trade Terms	EXW,FOB,CFR,CIF
Payment Terms	30% TT for deposit,70% TT/70% LC at sight balance before shipment.
Delivery time	Shipped in 7-15 days after payment.
Package	Standard sea-worthy package or as required.

Product Description

Description
Item	1.8519 alloy steel bar 31CrMoV9 steel bar factory price
Steel grade	31CrMoV9
Standard	EN 10085: 2001
Material	alloy steel
Surface	black or according to customer's request
Type	hot rolled,cold rolled

Chemical composition % of steel 31CrMoV9 (1.8519): EN 10085-2001

C	Si	Mn	P	S	Cr	Mo	V
0.27 - 0.34	max 0.4	0.4 - 0.7	max 0.025	max 0.035	2.3 - 2.7	0.15 - 0.25	0.1 - 0.2

Mechanical properties of steel 31CrMoV9 (1.8519)

Nominal thickness (mm):	16 - 40	40 - 100	100 - 160	160 - 250
Rm - Tensile strength (MPa) (+QT)	1100-1300	1000-1200	900-1100	850-1050

Nominal thickness(mm):	16 - 40	40 - 100	100 - 160	160 - 250
Rp0.2 0.2% proof strength (MPa) (+QT)	900	800	700	650

KV - Impact energy (J) (+QT)

+20°
25-40

Nominal thickness (mm):	16 - 40	40 - 100	100 - 160	160 - 250
A - Min. elongation at fracture (%) (+QT)	9	10	11	12

Brinell hardness (HB): (+A)

248

Nitriding Steel Round Bar D 470 mm Material 1.8519 31crmov9 Qt Forged Steel Soild Rod 0
