Product Details:
|
| Surface: | 1D | Thickness: | 3-10mm |
|---|---|---|---|
| Width: | 1000,1219,1500mm | Lengh: | 2000,2438,3000 |
| Standard: | ASTM, AISI, DIN, EN, GB, JIS | Type: | Plate, Sheet Plate Coil |
| High Light: | stainless steel metal sheet,stainless steel panels |
||
| Specifications | ASTM A240 / ASME SA240 |
|---|---|
| Dimensions | ASTM, ASME and API |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc. |
| Surface | 2B, 2D, BA, NO.4, NO.8, 8K, Mirror,Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm,etc. |
| Finish | Black,Bright Polished,Rough Turned,No.4 Finish,Matt Finish,BA Finish |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc. |
| Grade | C | Mn | Si | S | P | Cr | Ni | Ti |
| SS 409L | 0.03 max | 1.00 max | 1.00 max | 0.030 max | 0.040 max | 10.50-11.70 | 1.5 max | - |
| Element | Density | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Hardness |
| SS 409L | 7.8 g/cm3 | MPa – 380 | MPa – 170 | 20 % | Rockwell B (HR B)- 88 / Brinell (HB)- 0.5t |
