Product Details:
|
| Steel Grade: | Alloy Steel | Alloy Or Not: | Is Alloy |
|---|---|---|---|
| Technique: | Hot Rolled,Forged,Cold Drawn | Application: | Structural Steel Bar |
| Type: | Alloy Steel Bar | Standard: | ASTM,DIN,AISI,JIS |
| Special Use: | Mold Steel | Shape: | Round,Square |
| Surface: | Black Or Bright | Surface Treatment: | Black/Peeling/Polishing/Machined |
| Diameter: | 12mm-650mm |
| Country | Europe | China | USA |
| Standard | DIN | GB | AISI |
| Grade | 16MnCr5/1.7131 | 16CrMnH | 5115 |
| Grade | C≤ | Si≤ | Mn≤ | P≤ | S≤ | Cr |
| 16MnCr5 | 0.14-0.19 | 0.4 | 1-1.3 | 0.025 | 0.035 | 0.8-1.1 |
| 5115 | 0.13-0.18 | 0.15-0.35 | 0.7-0.9 | 0.035 | 0.04 | 0.7-0.9 |
| Size | Round | Dia 6-1000mm |
| Plate/Flat/Block | Thickness 6mm-500mm |
|
| Width 20mm-1000mm |
||
| Heat treatment | Normalized ; Annealed ; Quenched ; Tempered | |
| Surface condition | Black; Peeled; Polished; Machined; Grinded; Turned; Milled | |
| Delivery condition | Forged; Hot rolled; Cold drawn | |
| Test | Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc. | |
| Payment terms | T/T;L/C;/Money gram/ Paypal | |
| Trade terms | FOB; CIF; C&F; etc.. | |
| Delivery time | 30-45 days | |
| Application | 16MnCr5 is widly used for a variety of applications in the used to the gearings in rotating machinery. Typical applications such as valve bodies, pumps and fittings, the high load of wheel, bolts, double-headed bolts, gears, internal combustion engine. Electric locomotives, machine tools, tractors, steel rolling equipment, boring machine, railway vehicle, and mining machinery transmission shaft on the steel ball, roller and shaft sleeve, etc. | |
6: Delivery condition
For hot forged bar, usually the delivery condition is hot forged, annealed rough turned/Black surface.
For hot rolled bar, usually the delivery condition is hot rolled, annealed, Black surface.
For hot forged plate, usually the delivery condition is hot forged, annealed, milled surface
For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.
