Product Details:
|
| Certification: | ISO,BV,SGS | Type: | Round |
|---|---|---|---|
| Application: | Construction,decoration,Industry,Mechineal,shipbuilding | Standard: | DIN,ASTM,AISI,JIS,EN |
| Grade: | UNS N08926 N08367 Alloy926 | Shape: | Round,Square |
| Dimensions: | 3mm-800mm | Surface: | Bright,Polished,black |
| Technique: | Cold Drawn&hot Rolled | Packing: | Standard Seaworthy Package |
| Price Term: | CIF CFR FOB Ex-Work | ||
| High Light: | Alloy926 Round Bar,Uns N08926 Alloy Bar,Corrosion Resistance Stainless Alloy Steel Bar |
||
| Material No. | 1.4529 |
|---|---|
| EN symbol (short) | X1NiCrMoCuN25-20-7 |
| AISI/SAE | — |
| UNS | N 08926 |
| AFNOR | — |
| B.S. | — |
| alloy | alloy 926 |
| Registered work's label | Cronifer® 1925hMo |
| Standards | VdTÜV 502, SEW 400 |
1.4529 (alloy 926) is an austenitic special steel with high molybdenum content and low carbon content.
Our product range in 1.4529 are tubes and pipes, fittings and flanges, accessories.
Chemical composition ¹ |
||||||||
| C ≤ % |
Si ≤ % |
Mn ≤ % |
P ≤ % |
S ≤ % |
Cr % |
Mo % |
Ni % |
V |
| 0,020 | 0,50 | 1,0 | 0,030 | 0,010 | 19,0-21,0 | 6,0-7,0 | 24,0-26,0 | |
| Nb | Ti | Al | Co | Cu % |
N ≤ % |
Fe | ||
| 0,5-1,5 | 0,15-0,25 | |||||||
| ¹ in accordance with Key to Steel 2001 | ||||||||
Special characteristics |
||
| Temperature range | Density kg/dm³ | Hardness (HB 30) |
|---|---|---|
| pressure bomb -10°C bis 400°C | 8,1 | ≤ 250 |
| extraordinarily high stability against pitting corrosion, stress corrosion and intergranular corrosion | ||
Welding filler |
| 2.4621, 2.4831, 2.4607, 2.4611 |
Main fields of application (depending on the specific conditions of use) |
| offshore, sea water desalination plants, sea water systems, chemical industry, production of sulphuric acid and phosphoric acid, sewage conditioning plants, mineral exploitation, flue gas desulphuration, components in conventional power stations, paper industry, pulp industry |
| (all aforementioned specifications serve as a general orientation and have to be reviewed depending on the specific conditions of use) |
6% Mo, high Ni, and N alloyed austenitic grade with extremely high resistance to both uniform and localized corrosion. Commonly used in applications to withstand chlorinated sea water also used in flue gas cleaning.
