S40975 Hot Rolled Stainless Steel Plate Data Sheet Chemical Composition 40.0mm

S40975 Hot Rolled Stainless Steel Plate Data Sheet Chemical Composition 40.0mm
S40975 Hot Rolled Stainless Steel Plate Data Sheet Chemical Composition 40.0mm S40975 Hot Rolled Stainless Steel Plate Data Sheet Chemical Composition 40.0mm S40975 Hot Rolled Stainless Steel Plate Data Sheet Chemical Composition 40.0mm

Large Image :  S40975 Hot Rolled Stainless Steel Plate Data Sheet Chemical Composition 40.0mm

Product Details:
Place of Origin: China
Brand Name: DELTA
Certification: ISO 9001 SGS MTC
Model Number: 409Ni S40975
Payment & Shipping Terms:
Minimum Order Quantity: 100 kgs
Price: 1760 USD/Ton
Packaging Details: good packing for export
Delivery Time: 7 - 10 days
Payment Terms: L/C, Western Union, T/T
Supply Ability: 30 Ton / Month
Contact Now

S40975 Hot Rolled Stainless Steel Plate Data Sheet Chemical Composition 40.0mm

Description
Products: Stainless Steel Plate Grade: 409Ni S40975
Thickness: 3.0 - 40.0mm Standard Size: 1500*6000mm
Standard: ASTM A240/240M-15 Other Grade: 304 316L 310S 321 410 420 430.etc
Highlight:

S40975 Hot Rolled Stainless Steel Plate

,

Stainless Steel Plate 40.0mm

,

polishing Forged Stainless Steel Plate

ASTM A240 S40975 409Ni NO.1 Finished Hot Rolled Stainless Steel Plate S40975 Data sheet Chemical Composition

MATERIAL SPECIFICATION DATA SHEET - UNS S40975

MATERIAL CATEGORY - 11Cr-Ni-Ti Ferrite type

PRODUCT DESCRIPTION
The alloy is usually produced by AOD / VOD /VIM followed by electroslag refining (ESR) / VAR if necessary for special purpose.
Bars and, where applicable, forgings are subjected to ultrasonic examination based on the different levels according to the buyers' requirements.
Bars are usually supplied black/bright in the annealed condition.
Final heat treatment - solution treatment / QT

MATERIAL SPECIFICATIONS - ASTM A959 (2004), A276, A312, A632, A176, A580
AVAILABILITY
Round bar / flat bar / steel strip / square bar / ring / plate / valve body
Bright - peeled + polishing, centerless grinding
Forged - ring, tube, pipe casing, discs, shaft



CHEMICAL COMPOSITION (WEIGHT %)

C (％): ≤ 0.030
Si (％): ≤ 1.00
Mn (％): ≤ 1.00
P (％)≤: 0.040
S (％)≤: 0.030
Cr (％): 10.5 ~ 11.7
Ni (％): 0.50 ~ 1.00
Mo (％): -
Ti (％): 6 X (C+N) ~ 0.75
Others (%): N ≤0.03




MECHANICAL PROPERTIES FINAL HEAT TREATMENT

Form: heavy plate, sheet, strip
Tensile strength, σb/MPa: 415
Yield strength, σ0.2/MPa: 275
Elongation, δ (％): 20
Reduction of area, ф (％): -
Hardness (HBW): 197
Hardness | HRB: 92
Cold bending property: 180D
HEAT TREATMENT PRACTICE
Heat treatment is only suitable for specific grades of stainless steel. When heat treating a stainless the hardening temperatures, including rate of heating, cooling and soaking times will vary due to several factors such as the shape and size of each component. Other considerations during the heat treatment process include the type of furnace, quenching medium and work piece transfer facilities. Please consult with the heat treatment provider for whole guidance on heat treatment of stainless steel grades. We are delighted to help to work with you the special heat treatment based on your special requirements.
TYPICAL APPLICATIONS
Chemical equipment
Mechanical parts used in the condition of corrosion resistance
Bolt and nut
Pressure vessel
PRODUCT PROFILE & DIMENSIONS
Round bar / Wire rod (Diameter): 5.5mm to 450mm
Square bar / Flat bar: 3mm to 1000mm
Plate / Sheet steel / Steel strip: 0.1mm to 1000mm
Width: 8mm to 1000mm
Length: random length or based on the customer's special requirement.
Forged steel shape: stepped shafts with flanks / discs /tubes /slugs /donuts /cubes /other different shapes based on OEM.



S40975 Hot Rolled Stainless Steel Plate Data Sheet Chemical Composition 40.0mm 0S40975 Hot Rolled Stainless Steel Plate Data Sheet Chemical Composition 40.0mm 1S40975 Hot Rolled Stainless Steel Plate Data Sheet Chemical Composition 40.0mm 2
