317l Stainless Steel Sheet Alloy 317L Metal Sheet 0.5mm-3mm 317l Stainless Steel Properties

Large Image : 317l Stainless Steel Sheet Alloy 317L Metal Sheet 0.5mm-3mm 317l Stainless Steel Properties

Product Details:

Place of Origin:	China(mainland)
Brand Name:	TISCO
Certification:	SGS,BV
Model Number:	201 202 304 304L 309S 310S 316 316L 317L 321 400Series .etc

Payment & Shipping Terms:

Minimum Order Quantity:	1 Ton
Price:	5.85 USD/KG
Packaging Details:	standard export seaworthy packing or as required
Delivery Time:	5-10 days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	15000Tons

Contact Now

317l Stainless Steel Sheet Alloy 317L Metal Sheet 0.5mm-3mm 317l Stainless Steel Properties

Description

Type:	Cold Rolled / Hot Rolled	Thickness:	0.6 - 3.0mm
Width:	1000mm - 1500mm	Grade:	201 304 304L 316L 321 310S 316L 317L 904L.etc
Length:	2000mm 2438mm Or As Required	Surface:	2B BA NO.4 Mirror 8K Gold Mirror
Stock:	In Stock
Highlight:	stainless steel metal sheet , stainless steel plate

Hot Rolled SS Sheet low temperature strength 1.0mm - 2.5mm Thickness

Quick Detail:

Size: 1000x2000mm 1219x2438mm 1500 x 3048mm
Thickness: 0.5 - 3.0mm
Tolerance: +-0-5%
Brand: TISCO BAOSTEEL.etc

Name	317L stainless steel sheet	Brand Name	TISCO BAOSTEEL
size	1219x2438mm 1000x2000mm Or as required	surface	2B BA NO.1 NO.4 HL 8K PVC
thickness	0.5-3.0mm	Certificate	SGS, BV

Description:

BAOSTEEL Brand 317L Stainless Steel Sheet 2B Finished 1.0mm - 2.5mm 1500 Width
stainless steel sheet / stainless steel plate / stainless steel coils / stainless steel strip / stainless steel
317L stainless steel sheet / 317L stainless steel / stainless steel sheet / Inox 1.4438

Products	Stainless Steel Sheet
Specification	1m 1.219m 1.5m or as your requirement
Surface	2B NO.1 BA Hairline 4K 6K 8K No.3 No.4
Type	Sheet/Plate
Thickness	0.3-100mm
Brand	TISCO JISCO LISCO and so on
Application	Foodstuff,gas,biology,metallurgy,electron,chemical,petroleum,boiler,nuclear energy,equipment fertilizeretc and so on
Parking	interlayer paper kraft paper wooden packing or as your requirement
Payment	Small quantity (within total $20000.00) T/T at sight, 30% in advance , 70% after receiving the B/L Large quantity : L/C at sight
container size	20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)
Delivery Time	10 days after received the deposit of T/T or L/C
Note	We can produce other standard as the customers’s requirement

About 317L material

317 l (00 cr19ni13mo3, UNS S31726) alloy is based on molybdenum austenitic stainless steel. It with conventional chrome - nickel austenitic stainless steel, such as, compared to 304 alloy has the stronger ability of resistance to chemical corrosion. In addition, compared with the conventional stainless steel, 317 l alloy has higher ductility, resistance to stress corrosion performance, compressive strength and resistance to high temperature performance. It is a low carbon level or L level, this level has during the welding and heat treatment process the sensitization effect of resistance.
Relative 316 l, 317 l steel has excellent water resistance and resistance to SCC, used for Chemical ships, Chemical products, such as Reactor should be high corrosion-resistant Chemical equipment.
SUS317L mechanical properties: YS (Mpa) 176 or higher, TS (Mpa) 480 or higher, EL (%) of 40 or higher, Hv 200 or less
SUS317L chemical composition: carbon (C) 0.030 or less, manganese (Mn) of 2.00 or less, nickel (Ni) 11.0 ~ 15.0, silicon (Si) of 1.00 or less, phosphorus (P) of 0.045 or less, sulfur (S) of 0.030 or less, chromium (Cr) 18.0 ~ 20.0, molybdenum (Mo) 3.0 ~ 4.0

Chemical Details

	C	Si	Mn	P	S	Ni	Cr	Mo
309	≤0.08	≤1.00	≤2.00	≤0.045	≥0.03	12.0-15.0	22.0-24.0	---
304	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	8.0-11.0	18.0-20.0	---
316	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	10.0-14.0	16.0-18.0	2.0-3.0
316L	≤0.03	≤1.00	≤2.00	≤0.045	≤0.03	10.0-14.0	16.0-18.0	2.0-3.0
317L	≤0.03	≤0.75	≤2.00	≤0.04	≤0.03	11.0-15.0	18.0-20.0	3.0-4.0
310S	≤0.08	≤0.75	≤2.00	≤0.045	≤0.03	19.0-22.0	24.0-26.0	---

Competitive Advantage:

1, high quality

2, fast deliver

3, storage company and keeps about 8000 ton products in stock.

4, the best price.

5,have a stainless steel products process center and we can do all kind of stainless steel process treatment.

6, near Shanghai port, the traffice is very convenient.
