Product Details:
|
| Width: | 600mm-1250mm | Standard: | ASTM,AISI |
|---|---|---|---|
| Grade: | SECC | Zinc Coating: | 30-275g/m2 |
| Application: | Roofing,Decor,commercial Use | Type: | Steel Coil |
| Surface Treatment: | Coated,Galvanized | Spangle: | Minimized |
| Surface: | Galvanized Coated,chromated And Oiled | ||
| High Light: | Electro Galvanized Steel Coils Sheet,0.4MM Galvanized Steel Coils Sheet,Galvanized Steel Coils 1250mm |
||
| product name | Galvanized steel sheets/Galvalume steel sheet |
| Thickness | 0.13mm-5.0mm |
| Width | 600mm-1500mm,762mm,914mm,1000mm,1200mm,1219mm,1250mm |
| zinc coating | 40g,60g, 80g, 90,100g, 120g, 140g,180g, 200g, 250g, 275g and so on. |
| Standard | ASTM, AISI, DIN, GB |
| Material | SECC |
| Spangle | zero spangle,regular spangle or normal spangle |
| surface treatment | chromated and oiled, chromated and non-oiled |
| Packing | export standard. |
| Payment | T/T, L/C or DP |
| min order | 25 tons (one 20ft FCL) |
Available range of SECC electro-galvanized steel sheets for appliances:
Item |
Nominal | |
| Thickness | 0.3-3.5 | |
| Width | 800-1830 | |
| Length | Steel plate | 1000-6000 |
| Steel strip | Coil inside diameter 508,610 | |
SECC electro-galvanized coating range and recommended nominal coating weight:
Coating from |
Coating type | |
| Pure zinc coating (single-side) g/m² | Zinc-nickel alloy coating (single-side) g/m² | |
| Uniform thickness | 3~90 | 10~40 |
| Different thickness | 3~90, the maximum difference value between both sides is 40. | 10~40, the maximum difference value between both sides is 20. |
| Single side | 10~110 | 10~40 |
| Note: The weight of 50g/m²of pure zinc coating is equal to about 7.1um, and the weight of 50g/m² of zinc-nickel alloy coating is equal to about 6.8um. | ||
| Coating form | Coating type | |
| Pure zinc coating (single-side) g/m² | Zinc-nickel alloy coating (single-side) g/m² | |
| Uniform thickness | 10/10, 20/20, 30/30, 40/40, 50/50, 70/70, 90/90 | 10/10, 20/20, 30/30, 40/40 |
| Difference thickness | 10/30, 20/40, 30/50, 40/60, 50/70, 60/90 | 10/20, 15/25, 25/30, 30/40 |
| Single side | 10/0, 20/0, 30/0, 40/0, 50/0, 60/0, 70/0, 80/0, 90/0, 100/0, 110/0 | 10, 15, 20, 25, 30, 40 |
