AISI 630 Stainless Steel Round Bar 1.4542 H1150 ASTM A564 Polished

AISI 630 Stainless Steel Round Bar 1.4542 H1150 ASTM A564 Polished
AISI 630 Stainless Steel Round Bar 1.4542 H1150 ASTM A564 Polished AISI 630 Stainless Steel Round Bar 1.4542 H1150 ASTM A564 Polished AISI 630 Stainless Steel Round Bar 1.4542 H1150 ASTM A564 Polished

Large Image :  AISI 630 Stainless Steel Round Bar 1.4542 H1150 ASTM A564 Polished

Product Details:
Place of Origin: China
Brand Name: MITTEL TISCO BAO STEEL
Certification: SGS ISO MTC
Model Number: AISI 630 / 17-4PH / 1.4542
Payment & Shipping Terms:
Minimum Order Quantity: 100KGS
Price: 2.5 USD/KG
Packaging Details: Wooden Box
Delivery Time: 7 Days
Payment Terms: L/C, T/T
Supply Ability: 50000KGS

AISI 630 Stainless Steel Round Bar 1.4542 H1150 ASTM A564 Polished

Description
Type: Round Application: Construction,Industry,Mechineal,shipbuilding
Standard: DIN,ASTM,AISI,JIS Grade: AISI 630 / 17-4PH / 1.4542
Shape: Round Certification: ISO,BV,SGS
Dimensions: 5.5mm-500mm Surface: Bright,Polished,black
Technique: Cold Drawn&hot Rolled Length: Customers' Requirements,or As Required.,8m
Packing: Standard Seaworthy Package Price Term: CIF CFR FOB Ex-Work
High Light:

AISI 630 Stainless Steel Round Bar

,

ASTM A564 Stainless Steel Bar

,

bright Stainless Steel Bar Polished

AISI 630 / 17-4PH / 1.4542 H1150 Specification ASTM A564 Stainless Steel Round Bar

17-4 stainless is an age-hardening martensitic stainless combining high strength with the corrosion resistance of stainless steel. Hardening is achieved by a short-time, simple low-temperature treatment. Unlike conventional martensitic stainless steels, such as type 410, 17-4 is quite weldable. The strength, corrosion resistance and simplified fabrication can make 17-4 stainless a cost-effective replacement for high strength carbon steels as well as other stainless grades.
At the solution treating temperature, 1900°F, the metal is austenitic but undergoes transformation to a low-carbon martensitic structure during cooling to room temperature. This transformation is not complete until the temperature drops to 90°F. Subsequent heating to temperatures of 900-1150°F for one to four hours precipitation strengthens the alloy. This hardening treatment also tempers the martensitic structure, increasing ductility and toughness.



17-4 Stainless Steel Round Bar Specification

StandardsDesignation
ASTMA 276
LengthDiameter
2-6m1.0mm~250mm
TypeCertification
17-4 Stainless Steel Round BarISO 9001:2008




Below you will find a brief overview of a number of stainless steel bar specifications. If you do not see a specification listed, please contact us.

BSJISISDINASTM
Semi Free Cutting Steel15AM/8MSMn433H,SUM 41

13S25/
40C10S
18/40Mn15S12

1137,1140
Free Cutting SteelEN-1A
EN-1A L
SUM-23
SUM-24 L
11C10S25
——

9SMn30
9SMnPb30/
11SMnPb30

1212/
1213
12L14/
12L15



Stainless Steel Bar Specifications

ASTM A276

This specification encompasses cold-finished or hot-finished bars, including rounds, squares, and hexagons, and hot-rolled or extruded shapes, such as angles, tees, and channels in the more commonly used types of stainless steels.

ASTM A479

This specification includes cold and hot finished stainless steel bars, including rounds, squares, and hexagons, and hot-rolled or extruded shapes such as angles, tees, and channels.

ASTM A484

This specification includes wrought stainless steel bars, shapes, forgings, and billets or other semi-finished materials, except wire, for forging. The materials are available in four types of conditions.

ASTM A582

This specification includes cold or hot finished bars, which are suitable for machining processes. This specification includes rounds, squares, and hexagons, from common types of stainless free-machining steels.

ASTM B473

This specification includes nickel alloy bar & wire, which can be produced in a solution-annealed condition, stabilized-annealed condition, or annealed condition.

Our Grades :
AISI:
201, 202, 301, 302, 303, 304, 304H, 304L, 316, 316H, 316L, 309, 309S, 310, 310S, 316Ti, 317, 317L, 347, 321, 321H, 410, 416, 420, 430, 430F, 431, 440C, 630, 17-4PH, F51
DIN:
WNR1.4301, WNR1.4305, WNR1.4306, WNR1.4307, WNR1.4401, WNR1.4404, WNR1.4571, WNR1.4541, WNR1.4828, WNR1.4841, WNR1.4845, WNR1.4449, WNR1.4438, WNR1.4310, WNR1.4550, WNR1.4541, WNR1.4878, WNR1.4006, WNR1.4005, WNR1.4021, WNR1.4028, WNR1.4016, WNR1.4104, WNR1.4105, WNR1.4057, WNR1.4542, WNR1.4462



Useful information of 17-4 Stainless Steel Round Bar

17-4 Stainless Steel Round Bar Chemical Composition

Ni
Cr
Mo
Mn
Cu
Si
C
Cb+Ta
S
P
Fe

MIN
3.0
15.0
3.0
5 x C



MAX
5.0
17.5
0.50
1.0
5.0
1.0
0.07
0.45
0.03
0.04
Balance



17-4 Stainless Steel Round Bar Physical Properties

Temperature, °F
70
212
392
572
Coefficient of Thermal Expansion, in/in°F x 10-6
7.2
7.5
7.8
Thermal Conductivity
Btu • ft/ft2 • hr • °F
8.6
9.2
9.8
10.4
Modulus of Elasticity,
psi X 106
29.0
28.1
27.0
26.1



17-4 Stainless Steel Round Bar Mechanical Properties

Tensile Strength : Unit – ksi (MPa) , Minimum
Yeild Strength : 0.2 % Offset , Unit – ksi (MPa) , Minimum
Elongation : in 2″, Unit : % , Minimum
Hardness : Rockwell , Maximum


H 900*
H 925
H 1025
H 1075
H 1100
H 1150
H 1150-M
Ultimate Tensile Strength, ksi
200
190
170
165
150
145
125
0.2% Yield Strength, ksi
185
175
165
150
135
125
85
Elongation % in 2" or 4XD
14
14
15
16
17
19
22
Reduction of Area, %
50
54
56
58
58
60
68
Hardness, Brinell (Rockwell)
420 (C 44)
409 (C42)
352 (C 38)
341 (C 36)
332 (C 35)
311 (C 33)
277 (C 27)
Impact Charpy V-Notch, ft – lbs
15
25
35
40
45
50
100


AISI 630 Stainless Steel Round Bar 1.4542 H1150 ASTM A564 Polished 0AISI 630 Stainless Steel Round Bar 1.4542 H1150 ASTM A564 Polished 1
