Product Details:
|
| Company Type: | Agent Of TISCO | Processing Technology: | Hot Rolled |
|---|---|---|---|
| Grade: | 201 304 304L 316L 321 310S 317L 347H 430 904L.etc | Surface: | 2B BA NO.4 NO.1 Mirror 8K |
| Standard: | GB JIS ASTM AISI EN DIN | Tolerance: | 0%-5% |
| Thickness: | 3.0-120mm | ||
| High Light: | stainless steel sheets and plates,stainless steel plate thickness |
||
Stainless Steel Metal Plate Grade 347H , SS 347H Plate NO.1 Finished HR Plate
Quick Detail
TISCO 304 stainless steel plate
size: 1500 x 3000mm 1500 x 6000mm thickness: 3.0mm - 120mm
Brand: TISCO BAOSTEEL ZPSS JISCO.etc
5000 tons in stock
347H stainless steel plate
|
PRODUCTS |
304 stainless steel plate |
Brand |
TISCO BAOSTEEL JISCO |
|
|
1500x3000mm |
|
original: NO.1 |
|
thickness |
3.0-120mm |
Certificate |
SGS, BV |
Description
|
Grade |
200 Series,300 Series,400 Series |
|
Standard |
JIS, ASTM, GB, AISI,DIN |
|
Length |
1000mm-6000 mm or as your requirements |
|
Thickness |
0.3mm-100mm or as your requirements |
|
Width |
500mm-3000mm |
|
Place of Origin |
Guangdong ,China (Mainland) |
|
Brand Name |
LISCO TISCO |
|
Model Number |
201,304,304L,316,316L,321,347H,2205 and so on |
|
Type |
Plate |
|
Application |
Building industry, Chemical industry, Food industry and other fields |
|
Certification |
ISO SGS |
|
Technical process |
cold rolled or hot rolled |
|
Surface |
2B,BA,brush,HL,NO.1,NO.4,etc |
We can produce other size stainless steel plate as customer required. we can also cut our products into any size.
Applications
Austenitic stainless hot strong steel 347 h, with good corrosion resistance, weldability and thermal performance. 347 h stainless steel used in large boiler superheater, reheater, steam pipe, petroleum and chemical heat exchanger pipe fittings.
Specifications
Stainless Steel Plate Grade 347H, SS 347H Plate/ NO.1 Finished HR SS plate
Size: 1500x3000mm 1500x6000mm other we have coils in stock, we can cut it for any length as customer required.
Chemical Compostion
|
C |
Si |
Mn |
P |
S |
Cr |
Ni |
Nb |
Ti |
|
0.04~0.10 |
<=0.75 |
<=2.00 |
<=0.045 |
<=0.03 |
17.00-19.00 |
9.0-13.0 |
(8C~1.00) |
/ |
| Tensile strength (Mpa) | Yield strength (Mpa) | Elongation percentage (%) | hardness HB | hardness HRB |
| 520 | 205-210 | 40% | 187 | HV200 |
Density(g/cm3) : 7.98
