Product Details:
|
| Company Type: | Agent Of TISCO | Processing Technology: | Cold Rolled |
|---|---|---|---|
| Surface: | 2B BA NO,1 NO.4 HL Mirror 8K | Surface: | 2B BA NO.4 Mirror 8K |
| Standard: | ASTM AISI GB DIN JIS EN | Certificate: | SGS/BV |
| Highlight: | duplex stainless steel plate,super duplex steel |
||
S31803 Duplex Steel Plate 2B NO.1 NO.4 + PE Finished 0.6mm - 14mm Thickness
Duplex UNS S31803 / UNS S32205 | 1.4462
| 1. Commodity: Stainless steel coil/plate/sheet 2. Surface: NO. 1/2B/BA 3. Width: 600mm~2000mm 4. Thickness: 0.6mm~14mm 5. Material: S31803, 2205, 1.4362 6. Packing: Standard exporting package We focus on im&ex trade in stainless steel coils, plates and sheets as well as processing and stock. We have over 20 thousand tons stock materials. If you feel interested and have any questions, please feel free to contact us! |
S31803 / S32205 Properties
Chemical Analysis (% max or range)
| C | Mn | P | S | Si | Cr | Ni | Mo | N |
| 0.03 | 2.00 | 0.03 | 0.02 | 1.00 | 21.0-23.0 | 4.5-6.5 | 2.5-3.5 | 0.08-0.20 |
Mechanical
| Tensile | Yield | Elongation | Hardness |
| MPa min | MPa min | % min | Brinell max |
| 620 | 450 | 25 | 293 |
S31803 / S32205 Duplex Stainless Steel
| Thickness (mm) | Plate Sizes (mm) | ||
| 5 | 12000 x 2000 | ||
| 6 | 12000 x 2000 | 12000 x 2500 | 12000 x 3000 |
| 8 | 12000 x 2000 | 12000 x 2500 | 12000 x 3000 |
| 10 | 12000 x 2000 | 12000 x 2500 | 12000 x 3000 |
| 12 | 12000 x 2000 | 12000 x 2500 | 12000 x 3000 |
| 15 | 12000 x 2000 | 12000 x 2500 | 12000 x 3000 |
| 20 | 12000 x 2000 | 12000 x 2500 | 12000 x 3000 |
| 25 | 12000 x 2000 | 12000 x 2500 | 12000 x 3000 |
| 30 | 6000 x 2000 | 5000 x 2500 | |
| 35 | 6000 x 2000 | 5000 x 2500 | |
| 40 | 6000 x 2000 | 5000 x 2500 | |
| 45 | 6000 x 2000 | 5000 x 2500 | |
| 50 | 6000 x 2000 | 5000 x 2500 | |
Application field
We can also supplt other material duplex stainless steel as customer required
