2B 1D Surface Duplex Stainless Steel Plate UNS S32750 Mile Edge Duplex Plates

2B 1D Surface Duplex Stainless Steel Plate UNS S32750 Mile Edge Duplex Plates
2B 1D Surface Duplex Stainless Steel Plate UNS S32750 Mile Edge Duplex Plates 2B 1D Surface Duplex Stainless Steel Plate UNS S32750 Mile Edge Duplex Plates 2B 1D Surface Duplex Stainless Steel Plate UNS S32750 Mile Edge Duplex Plates 2B 1D Surface Duplex Stainless Steel Plate UNS S32750 Mile Edge Duplex Plates

Large Image :  2B 1D Surface Duplex Stainless Steel Plate UNS S32750 Mile Edge Duplex Plates

Product Details:
Place of Origin: China(mainland)
Brand Name: AUTO KUMPO / TISCO / BAOSTEEL
Certification: SGS,BV
Model Number: S32750
Payment & Shipping Terms:
Minimum Order Quantity: 2 Ton
Price: 4000-6500 USD/Ton
Packaging Details: standard export seaworthy packing or as required
Delivery Time: 5-10 days according to the quantity
Payment Terms: L/C, T/T, Western Union
Supply Ability: 15000Tons

2B 1D Surface Duplex Stainless Steel Plate UNS S32750 Mile Edge Duplex Plates

Description
Company Type: Storage Company Processing Technology: Cold Rolled
Grade: S31803 S32205 2507 S32750 Surface: 2B BA NO.4 Mirror 8K
Standard: ASTM AISI GB DIN JIS EN Certificate: SGS/BV
High Light:

duplex stainless steel plate

,

super duplex steel

2B 1D Surface Duplex Stainless Steel Plate UNS S32750 Mile Edge Duplex Plates





Quick Detail

S32750 stainless steel plate



Name

S32750 duplex steel plate

Brand

AUTO KUMPO/TISCO/BAOSTEEL



size

1219mm 1500mm 1800mm or as required



surface

2B, BA, HL, 8K mirror, PVC coated

thickness

0.6-30mm

Certificate

SGS, BV



                     We can produce un-standard size duplex stainless steel plate as customer required



Description



Alloy 2507 (UNS S32750) is a super duplex stainless steel with 25% chromium, 4% molybdenum, and 7% nickel designed for demanding applications which require exceptional strength and corrosion resistance, such as chemical process, petrochemical, and seawater equipment. The steel has excellent resistance to chloride stress corrosion cracking, high thermal conductivity, and a low coefficient of thermal expansion. The high chromium, molybdenum, and nitrogen levels provide excellent resistance to pitting, crevice, and general corrosion.


Standards
ASTM/ASME .......... A240 - UNS S32750
EURONORM............ 1.4410 - X2 Cr Ni MoN 25.7.4
AFNOR.................... Z3 CN 25.06 Az



Applications

  • Oil and gas industry equipment
  • Offshore platforms, heat exchangers, process and service water systems, fire-fighting systems, injection and ballast water systems
  • Chemical process industries, heat exchangers, vessels, and piping
  • Desalination plants, high pressure RO-plant and seawater piping
  • Mechanical and structural components, high strength, corrosion-resistant parts
  • Power industry FGD systems, utility and industrial scrubber systems, absorber towers, ducting, and piping

Specifications



Alloy 2507 is a super duplex stainless steel with 25% chromium, 4% molybdenum, and 7% nickel designed for demanding applications which require exceptional strength and corrosion resistance, such as chemical process, petrochemical, and seawater equipment. The steel has excellent resistance to chloride stress corrosion cracking, high thermal conductivity and a low coefficient of thermal expansion. The high chromium, molybdenum, and nitrogen levels provide excellent resistance to pitting, crevice, and general corrosion.

The impact strength is also high. Alloy 2507 is not recommended for applications which require long exposures to temperatures above 570°F because of the risk of a reduction in toughness.



Chemical Analysis


Typical values (Weight %)

C Cr Ni Mo N Others
0.020 25 7 4.0 .27 S=0.001
PREN = [Cr%] + 3.3 [Mo%] + 16 [N%] ≥ 40



Mechanical Properties

0.2% Offset Yield Strength 0.2%, ksi 80 min.
Ultimate Tensile Strength, ksi 116 min.
0.1% Offset Yield Strength 0.2%, ksi 91 min.
Elongation in 2 inches, % 15 min.
Hardness Rockwell C 32 max.
Impact Energy, ft.-lbs. 74 min.



Advantage of our company

  • 1. Expertise: 10 years of manufacture: we know how to properly handle  every step of production.
  • 2. Competitive price: We produce resin and paint by ourself, which greatly reduce our cost!
  • 3. Materials: All color Steel Sheets are made of high-quality raw materials.
  • 4.Certificate: Our products are certified by TUV, ISO9001:2008,ISO14001:2004 etc.
  • 5. Productivity: We have three large-scale production line, to guarantee all your orders will be finished in earlist time



If you have required of our products, please leave your message to us
