Product Details:
|
| Company Type: | Storage And Trading | Processing Technology: | Hot Rolled |
|---|---|---|---|
| Grade: | 201 304 304L 316L 321 310S 317L 409L 430 904L.etc | Surface: | 2B BA NO.4 NO.1 Mirror 8K |
| Standard: | GB JIS ASTM AISI EN DIN | Port: | Shanghai |
| Thickness: | 3.0-120mm | ||
| High Light: | stainless steel sheets and plates,stainless steel plate thickness |
||
Mile Edge 409L Stainless Steel Sheet and Plate , NO.1 NO.4 Surface 409L SS Plate
Quick Detail
409L stainless steel plate
|
Description
Mile Edge BAOSTEEL 409L Stainless Steel Plate, NO.1 NO.4 Surface 409L SS plate
About our 409L stainless steel plate
| Material | 409 L |
| Size | width:1500-1800 mm length: 3000-6000mm thickness: 3.0 -120mm |
| Surface | original surface is NO.1, we can make surface treatment like: 2B BA NO.4 mirror and pvc coat |
| Brand | TISCO JISCO BAOSTEEL POSCO.etc |
| packing |
standard export seaworthy packing or as customer required. |
Main material of our products: grade 201 301 304 304L 309S 310S 310H 316L 317L 321 409L 420 430 436 904L duplex stainless steel .etc
Main producs: stainless steel sheet/plate coil, stainless steel pipe, stainless steel bars.etc
Surface and Applications
|
Surface finish |
Characteristics and application |
|
No.2B |
The surface brightness and flatness of no2B is better than no2D. then through a special surface treatment to improve its mechanical properties,No2B could nearly satisfy comprehensive uses. |
|
No.3 |
Polished with abrasive belt of git#100-#200, have better brightness with discontinuous coarse stria, used as inner and external ornaments for building, electrical appliances and kitchen utensils etc. |
|
No.4 |
Polished with abrasive belt of grit #150-#180,have better brightness with discontinuous coarse stria, but thinner than No3, are used as bathtub buildings inner and external ornaments electrical appliances kitchen utensils and food processing equipment etc. |
|
HL |
Polished with abrasive belt of grit #150-#320 on the NO.4 finish and has continuous streaks, mainly used as buildings ornaments elevators, door of building, frontal plate etc. |
|
BA |
Cold rolled, bright annealed and skin-passed, the product have excellent brightness and good reflexivity like mirror, kitchen apparatus, ornament etc. |
|
8K |
The product have excellent brightness and prefer reflexivity can to be the mirror |
Specifications
Mile Edge BAOSTEEL 409L Stainless Steel Plate, NO.1 NO.4 Surface 409L SS plate
size: 3.0 - 100mm x 1500mm x 6000mm or as required
Chemical Compostion of 409 L
|
C |
Si |
Mn |
P |
S |
Cr |
Ni |
Nb |
|
<=0.03 |
1.00 |
1.00 |
0.04 |
0.03 |
10.5-11.7 |
0.5 |
0.75 |
|
Mechanical properties |
|||||||
|
|
Heat Treatment |
Yield strength(N/mm2) |
Tensile strength |
Elongation (%) |
Hardness |
||
|
HB |
HRB |
HV |
|||||
|
409l |
S |
≥205 |
≥400 |
≥25 |
≤187 |
≤80 |
≤175 |
National grade of 409L : ASTM 409L / S40903 / ISO X2CrTi12 / EN X2CrTi12/1.4512 / JIS SUH409L
Density(g/cm3) : 7.85
Advantage of us:
|
1, high quality and competitive price 2, have 15000 ton stainless steel products stock 3, fast deliver 4, more than 12 years export experience 5,Near Shanghai Port, the traffice is very good. 6,special in stainless steel products |
