Product Details:
|
| Name: | Stainless Steel Flat Bars | Material: | 201 202 |
|---|---|---|---|
| Length: | 6-8m Or As Required | Surface: | Black / Bright / Hairline |
| High Light: | stainless flat bar stock,304 stainless steel flat bar |
||
Quick Detail:
Hot rolled/ Cold rolled Stainless Steel Flat Bars grade 304 304L 316L,SS flat bars
| name | stainless steel flat bar | size | 20x4 - 200x40 |
| material |
201 202 301 304 304L 309S 310S 316L 317L 321 410 420 430 904L duplex stainless steel S31803 2205 2507 |
surface | Black / bright / polished / hairline finished |
| length | 6-8m or as required | certificate | SGS BV |
Description:
About our stainless steel flat bars
|
Type |
201/202 Stainless steel flats/ Stainless Steel flat bars |
|
Standard |
ASME, ASTM, EN ,BS,GB,DIN, JIS etc |
|
Material |
201,202, 304,304L,316,316L309s,310S,410,410S,430 etc |
|
Certification |
ISO and SGS |
|
Application |
boiler, nuclear energy, Medical equipment, fertilizer etc Foodstuff, Gas, metallurgy, biology, electron, chemical, petroleum, |
|
width |
1000mm-2000mm |
|
thickness |
0.2mm-180mm |
|
Length |
1000mm-6000mm |
|
Packaging |
Standard export sea-worthy packing |
|
Delivery time |
About 7 days after the order |
|
Quality |
high |
|
Productivity |
1000 tons/month |
|
Payment terms |
T/T or L/C |
|
Note |
We can produce other standard as the customers’ requirement |
Applications
Stainless steel flat steel can be according to the structure of the different needs of different kinds of stress components, also can make members between the joints. Widely used in various building structure and engineering structure, such as the beam, Bridges, transmission tower, lifting transportation machinery, ships, industrial furnace, reaction tower, container frame and warehouse shelves, etc.
Specifications
| Material | Name | Elements | |||||||||
| C | Cr | Ni | Mn | P | S | Mo | Si | Cu | N | ||
| 201 | 1Cr17Mn6Ni5N | <0.15 | 16.0- 18.0 | 3.5-5.5 | 5.5-7.5 | <0.06 | <0.03 | ___ | <1.0 | ___ | <0.25 |
| 202 | 1Cr18Mn8Ni5N | <0.15 | 17.0-19.0 | 4.0-6.0 | 7.5-10.0 | <0.06 | <0.03 | ___ | <1.0 | ___ | <0.25 |
| 301 | 1Cr17Ni7 | <0.15 | 16.0-18.0 | 6.0-8.0 | <2.0 | <0.065 | <0.03 | ___ | <1.0 | ___ | ___ |
| 303 | Y1Cr17Ni7 | <0.15 | 17.0-19.0 | 8.0-10.0 | <2.0 | <0.20 | <0.03 | ___ | <1.0 | ___ | ___ |
|
304 |
0Cr18Ni9 | <0.07 | 17.0-19.0 | 8.0-10.0 | <2.0 | <0.035 | <0.03 | ___ | <1.0 | ___ | ___ |
| 304L | 00Cr19Ni10 | <0.03 | 18.0-20.0 | 8.0-10.0 | <2.0 | <0.035 | <0.03 | ___ | <1.0 | ___ | ___ |
| 309S | 0cr23Ni13 | <0.08 | 22.0-24.0 | 12.0-15.0 | <2.0 | <0.035 | <0.03 | ___ | <1.0 | ___ | ___ |
| 310S | 0Cr25Ni20 | <0.08 | 24.0-26.0 | 12.0-15.0 | <2.0 | <0.035 | <0.03 | ___ | <1.0 | ___ | ___ |
| 316 | 0Cr17Ni12Mo2 | <0.08 | 16.0-18.5 | 10.0-14.0 | <2.0 | <0.035 | <0.03 | 2.0-3.0 | <1.0 | ___ | ___ |
| 316L | 00Cr17Ni14Mo2 | <0.03 | 16.0-18.0 | 12.0-15.0 | <2.0 | <0.035 | <0.03 | 2.0-3.0 | <1.0 | ___ | ___ |
Competitive Advantage
