Product Details:
|
| Trade Term: | EXW,FOB,CIF,CFR | Classification: | CCS LR GL ABS |
|---|---|---|---|
| Application: | Shipbuilding, Offshore Engineering | Surface: | Hot Rolled |
| Size: | Customized | Class: | CCS BV LR GL ABS |
| Shape: | Flat Steel Plate | Packing: | Standard Seaworthy Packing |
| Grade: | AH32, AH36, DH32, DH36, EH32, EH36 | Technique: | Hot Rolled |
| Length: | 1000mm-20000mm | Advantage: | Time Delivery |
| High Light: | shipping plate,marine steel plate |
||
Quick Detail:
prime grade a36 ship steel plate
Grade:LR -A,LR-B,A36,AH36,DH36,EH36
SIZE:1500*6000;2200*10000MM
MILL:SHA GANG
Thickness:6-150mm
Description:
prime grade abs a36 ship steel plate
Agent for 8 mills:Wisco, Baosteel etc
offer with certificate
prime grade abs a36 ship steel plate
1. Steel Grade:
Material | Steel |
Thickness | 6-38mm |
Width | 1800-3200mm |
Length | 7000-12000mm |
Executive standard | ASTM, GB, JIS |
Grade | A,B,D, E ,AH32, AH36,DH32,DH36, EH32,EH36 |
Usage | Ship building, construction, light industry, household appliance, automobile |
Manufacturer process | Hot rolled |
Packing | Properly packed for ocean freight exportation in containers |
Notice | special design available is according to the requirement of customers |
2. Hardness and Mechanical Properties
Mechanical Properties | |||||||||
| | | | | Impact test | Cold Bend Test | |||
| Average AKV | b=2a | b=5a | ||||||
lengthways | crosswise | ||||||||
≥ | |||||||||
A | ≤50 | 235 | 400~490 | 22 | / | / | / | d=2a | / |
B | 0 | 27 | 20 | / | d=3a | ||||
D | -10 | ||||||||
E | -40 | ||||||||
AH32 | ≤50 | 315 | 440~590 | 22 | 0 | 31 | 22 | / | d=3a |
DH32 | -20 | ||||||||
EH32 | -40 | ||||||||
AH36 | ≤50 | 355 | 490~620 | 21 | 0 | 34 | 24 | / | d=3a |
DH36 | -20 | ||||||||
EH36 | -40 | ||||||||
Classification Society: ABS,BV,CCS,DNV,GL,KR,LR,NKK,RINA
Listed in the table are the data for reference. Technical delivery conditions are stipulated in the contract
3. Application
It has been widely used in ship building, construction, light industry, household appliance, automobile.
4. Shipment Information
MOQ: | 25 Metric Ton/Metric Tons |
Package: | bulk packing with steel belt or customer required |
Trade terms: | FOB, CFR, CIF |
Payment method: | L/C,D/A,D/P,T/T,Western Union |
Port of Loading: | Any port in China |
Delivery Time: | 15 days from ordering date |
If you have special requirement, Welcome to contact us.
Applications:
It has been widely used in ship building, construction, light industry, household appliance, automobile.
Specifications:
Item | A36 ship steel plate |
Standard | En10025-2-2004,EN10025-5-2004 |
Thickness | 4-150mm |
Width | 1200-2500mm |
Length | 6000-12000mm |
Surface | Black painted,PE coated,Galvanized,color coated,etc |
Package | Standard export seaworthy package,suit for all kinds of transport,or as required. |
Container | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) |
Size | 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) |
| 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) |
Bulk Size | Any size |
Price term | Ex-Work,FOB,CNF,CFR,CIF,etc |
grade | A,B,D, E ,AH32, AH36,DH32,DH36, EH32,EH36 |
Port | Shanghai |
Application | steel plate are widely used in shipping building,engineer construction, |
| mechanical manufacturing,the size of alloy and painting steel sheet can be made |
| according to clients required. |
Contact | skype: winfaststeel |
Competitive Advantage:
Good quality
Best price
Fast delivery time
