Duplex stainless steel plate grade S31803 / S32205

Duplex stainless steel plate grade S31803 / S32205
Duplex stainless steel plate grade S31803 / S32205 Duplex stainless steel plate grade S31803 / S32205 Duplex stainless steel plate grade S31803 / S32205

Large Image :  Duplex stainless steel plate grade S31803 / S32205

Product Details:
Place of Origin: CHINA
Brand Name: TISCO,BAO STEEL
Certification: SGS,BV,ISO
Model Number: S31803
Payment & Shipping Terms:
Minimum Order Quantity: 5 Tons
Price: 4850 USD/Ton
Packaging Details: Export packing
Delivery Time: 7 days
Payment Terms: T/T or L/C
Supply Ability: 6000 Tons every month

Duplex stainless steel plate grade S31803 / S32205

Description
High Light:

duplex stainless steel plate

,

super duplex steel

Quick Detail:
Astm A240 S31803 Duplex stainless Steel plate
Grade :S31803/S32205
Surface:NO.1 finished
Thickness:3-150mm
Size:1000*2000;1250*2500;1219*2438;1500*3000/6000mm
Mill:TISCO,BAO STEEL



Description:
s31803/s32205 duplex steel plate
grade:1.4462,s31803,s32205
thickness:2-150mm
width:1000-2000mm
s31803/s32205 duplex steel plate



 duplex plates/sheet

 standard details:

Duplex UNS S31803/UNS S32205, Duplex F51, Duplex SA182 Grade F-51, DIN 1.4462

Duplex A182-F51, Duplex SA182 Grade F-51 UNS S31803, UNS S32205, Din-1.4462

Duplex ASTM A182 Grade F60 / ASME SA182 Grade F60 NACE & Norsok Approved

Super Duplex 2507, Super Duplex SAF2507 Super Duplex SAF 2507 ASTM A182 Grade F53

Super Duplex F53, Super Duplex SA182 Grade F-53, Super Duplex S32750

Super Duplex UNS S32760 F55 ASTM A182 F-55 SA182 F55 DIN 1.4501 UNS 32760



ASTM / ASME SB 163 UNS 2200 ( NICKEL 200 )

ASTM / ASME SB 163 UNS 2201 (NICKEL 201 )

ASTM / ASME SB 163 / 165 UNS 4400 (MONEL 400 )

ASTM / ASME SB 464 UNS 8020 ( ALLOY 20 / 20 CB 3 )

ASTM / ASME SB 704/705 UNS 8825 INCONEL (825)

ASTM / ASME SB 167 / 517 UNS 6600 (INCONEL 600 )

ASTM / ASME SB 167 UNS 6601 ( INCONEL 601 )

ASTM / ASME SB 704 /705 UNS 6625 (INCONEL 625)

ASTM / ASME SB 619/622/626 UNS 10276 ( HASTELLOY C 276 )

Copper Alloy

ASTM / ASME SB 111 UNS NO. C 10100, 10200, 10300, 10800, 12000, 12200, 70600, 71500.

ASTM / ASME SB 466 UNS NO. C 70600 ( CU -NI- 90/10), C 71500 ( CU -NI- 70/30)




Characteristics and application

2B

The surface brightness and flatness of 2B is better than 2D.then through a special surface
treatment to improve its mechanical properties.2B could nearly satisfy comprehensive uses.

NO.3

Polished with abrasive belt of git#100#200,have better brightness with discontinuous
coarse stria,used as inner and external ornaments for building,electrical appliances and
kitchen utensils etc.

NO.4

Polished with abrasive belt of grit#150#180.have better brightness with discontinuous
coarse stria.but thinner than NO.3,are used as bathtub buildings inner and external
ornaments electrical appliances kitchen utensils and food processing equipment etc.

HL

Polished with abrasive belt of grit#150#320 on the NO.4 finish and has continuous streaks,
mainly used as buildings ornaments elevators, door of building, frontal plate etc.

BA

Cold rolled, bright annealed and skin-passed, the product have excellent brightness and
good reflexivity like mirror,
kitchen
apparatus, ornament etc.

8K

The product have excellent brightness and prefer reflexivity can be the mirror.





Applications:
Chemical processing, transport and storage, Oil and Gas exploration and processing equipment, Marine and other high chloride environments, Pulp and paper digesters, liquor tanks and paper machines.


Specifications:

Trade Name

UNS

6Moly Industry
Specifications

Chemical Composition

Min.
Tensile
 (KSI)

Min.
Yield
(KSI)

Elongation

SAF 2205

UNS
S31803

ASME SA-182 (F51),
SA-240,
SA-798, SA-790,
SA-815 ASTM A240,
A276, A479, A789,
A790,A815, A923, A928,
A988 SAE J405

C 0.30 max Cr 21.0-23.0
Mn 2.00
max Mo
2.50-3.50 N 0.08-0.20
Ni 4.50-6.50 P 0.030
max S 0.020
max Si 1.00 max

90

65

25

SAF 2205

UNS
S32205

ASTM A240, A240M,
A276, A479, A480,
A480M,
A798, A7901, A815,
A923, A928,
A988 SAE J40

C 0.30 max Cr 22.0-23.0
Mn 2.00
max Mo
3.00-3.50 N 0.14-0.20
Ni 4.50-6.50 P 0.030
max S 0.020
max Si 1.00 max

90

65

25




Duplex Heat Resistance

Although 2205 has good high temperature oxidation resistance, this grade - like other duplex stainless steels - suffers from embrittlement if held for even short times at temperatures above 300ºC. If embrittled, this can only be rectified by a full solution annealing treatment. Duplex stainless steels are almost never used above 300ºC.
