Product Details:
|
| Application: | Construction,Kitchenware,Decoration,chemical,Industry | Width: | 1000-2000mm,20mm-1250mm |
|---|---|---|---|
| Type: | Plate,Coil,stainless Steel Sheet | Standard: | ASTM,JIS,AISI,EN |
| Length: | Customer's Request,1000-6000mm Or Customer's Requirement | Surface: | BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D |
| Thickness: | 0.2-60mm | Edge: | Slit Edge,Mill Edge,Mill Edge/ Slitting Edge Stainless Steel |
| Technique: | Cold Rolled Hot Rolled | Price Term: | CIF CFR FOB EX-WORK |
| High Light: | Normal Hardness Plates Sheets Strips Coils,EN 10204 3.2 Stainless Steel Sheet,DIN 17750 Stainless Steel Sheet |
||
Alloy 75 (UNS N06075, Nimonic 75) is a 80/20 nickel-chromium alloy with controlled additions of titanium and carbon. Nimonic 75 has good mechanical properties and oxidation resistance at high temperatures. Alloy 75 is most commonly used for sheet metal fabrications which require oxidation and scaling resistance together with medium strength at high operating temperatures. Alloy 75 (Nimonic 75) is also used in gas turbine engines, for components of industrial furnaces, for heat treating equipment and fixtures, and in nuclear engineering.
| Chemical Composition Limits | ||||||||
| Weight% | Ni | Cr | Ti | C | Si | Cu | Fe | Mn |
| Alloy 75 Nimonic 75 |
Bal | 18.9 - 21.0 | 0.2 / 0.6 | 0.08 / 0.15 | 1.0 max | 0.5 max | 5.0 max | 1.0 max |
| Material | Test Temp °F | Ultimate Tensile Strength (ksi) | 0.2 % Yield Strength (ksi) | Elongation in 2" |
| Alloy 75 Sheet 1925°F Anneal | Room | 114.4 | 59.4 | 31 |
| Alloy 75 Sheet 1925°F Anneal | 1000 | 105.6 | 51.9 | 27 |
| Alloy 75 Sheet 1925°F Anneal | 1200 | 69.3 | 40.0 | 32 |
| Alloy 75 Sheet 1925°F Anneal | 1400 | 41.4 | 22.0 | 75 |
| Alloy 75 Sheet 1925°F Anneal | 1600 | 20.2 | 9.9 | 90 |
| Alloy 75 Sheet 1925°F Anneal | 1800 | 9.7 | 4.4 | 91 |
Availability
Alloy 75 (Nimonic 75) is available in Bar, Round Bar, Flat Bar, Plate, Strip, Sheet, Wire, Tube, Rod, Forging Stock and Extruded Section. For all stock availability contact Sales for further availability.
Specifications
| Rod, Bar, Wire and Forging Stock | BS HR 5, BS HR 504, DIN 17752, AECMA PrEN2306, AECMA PrEN2307, AECMA PrEN2306, AECMA Pr EN2307, AECMA PrEN2402, ISO 9723, ISO 9724, ISO 9725, MSRR 7004 |
| Plate, Sheet, Strip | BS HR 203, DIN 17750, AECMA PrEN2293, AECMA PrEN2302, AECMA PrEN2411, ISO 6208, MSRR 7104 |
| Pipe and Tube | BS HR 403, DIN 17751, AECMA PrEN2294, ISO 6207 |
| Other | DIN 17742, AECMA PrEN2308, Werkstoff Nr 2.4630, W. Nr 2.4951, UNS N06075, Nimonic 75 (tradename), MSRR 7104 and MSRR 7004, AFNOR NC 20T |
| Grade | C | Mn | Si | Cu | Fe | Ni | Cr | Ti |
| Nimonic 75 | 0.08-0.15 | 1.0 max | 1.0 max | 0.5 max | 5.0 max | Bal | 18.0-21.0 | 0.2-0.6 |
| Grade | Al | B | C | Cr | Co | Cu | Fe | Mn | Ni | P | Si | S |
| Nimonic 80A | 1 – 1.8 | 0.008 max | 0.1 max | 18 – 21 | 0.2 max | 0.2 max | 3 max | 1 max | Balance | 0.045 max | 1 max | 0.015 max |
Mechanical Properties of Nimonic 75 / 80A Sheet / Bar
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nimonic 75 | 8.37g/cm3 | 1340 – 1380 | Psi – 104,000 | Psi – 40,000 | 42 % |
| Grade | Condition | Ultimate Tensile Strength MPA | Yield Strength MPA | Elongation on 4D (min) | Hardness min |
| Nimonic 80A | Solution Annealed & Precipatation Treated (aged) | 994 | 616 | 20 | 300 HV |
