Product Details:
|
| Packing: | Standard Seaworthy Package | Advantage: | Time Delivery |
|---|---|---|---|
| Shape: | Plate | Type: | Hot Rolled |
| Classification Society: | BV GL DNV CCS | Hs Code: | 27040010 |
| Surface: | Hot Rolled | Processing: | Provide Steel Process Servive |
| Surface Treatment: | Coated | Standard: | ASTM, GB, JIS, EN |
| Technique: | Hot Rolled | Use: | Ship Building |
| Length: | 6000-12000mm | Grade: | A, B, D, E, AH32, AH36, DH32, DH36, EH32, EH36 |
Shipbuilding Steel Plate:
Features: corrosion resistant, heat resistant, high elongation, etc.
Application: mainly used in shipbuilding, construction, and containers, etc.
Shipbuilding Steel Plate |
|
Standard |
CCS,ABS,GL,BV,DNV,NK,LR,KR,RINA |
| Grade | A/B/D/E,A32/D32/E32/F32,A36/D36/E36/F36,A40/D40/E40/F40,A131A/B/D/E/AH32 /DH32/EH32/AH36/DH36/EH36/AH40/DH40/EH40,NVA420/D420/E420,NVA460 /D460/E460,NVA500/D500/E500,NVA550/D550/E550…. |
| Thickness | 2-300mm (2-100mm usually used) |
| Width | 1000-3000mm (1000-2200mm usually used) |
| Length | 1000-12000mm or as your request |
| Surface | Clean, finishing,blasting and painting according to customer requirement |
| Delivery States |
Hot-rolled, Controlled rolling, Normalizing, Annealing, Tempering, Quenching, N+T, Q+T,and other delivery states are available as required |
| Certificate | API,ISO,SGS,BV,CE etc |
| Quality | MTC will be provided with goods, third part inspection is acceptable, for example BV,SGS. |
| Package | Standard export seaworthy package,suit for all kinds of transport, or as required. |
| Container Size |
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) |
| 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) | |
| Trade term | Ex-Work,FOB,CNF,CFR,CIF,etc |
| Application | Widely used in a variety of architectural and engineering structures,such as 1.) metal constructions such as buildings,bridges,ships; 2.) transmission tower, reaction tower; 3.) lifting transportation machinery; |
Due to the harsh working environment of the ship, the hull shell is subject to chemical corrosion of seawater, electrochemical corrosion and corrosion of marine organisms and microorganisms; the hull is subjected to large wind and wave impacts and alternating loads; the shape of the ship is complicated by processing methods, etc. Steel for hull structure is strictly required. First of all, good toughness is the most critical requirement. In addition, high strength, good corrosion resistance, weldability, forming properties and surface quality are required.
Shipbuilding Steels Our hot rolled shipbuilding steel is produced in accordance with the relevant Classification Society, examples of which include Lloyds Register and Det Norske Veritas.
Our steel products include steel shipbuilding plate, fabricated steel sections and floor plate for decking. We can also supply bulb flats for plate stiffening, structural steel angles and inverted angles.
Our plates are supplied under the ASTM/ASME specification (ASTM A131 / ASME SA 131) which is the standard specification for Structural Steel for Ships. We offer higher strength shipbuilding steels as standard .High strength steels offer significant cost advantages by reducing the weight of the structure in comparison to the steel used.
The plates are suitable for use in the construction of container ships and large cargo freighters as well as commercial shipping lines such as luxury cruise ships and ferries. Supply options include heavy plates, surface treated plates and pre-fabricated sections. In most cases, the steel can also be supplied as hot rolled coils or cut into lengths (sheets).
These high yield materials are commonly used in the construction of hulls and superstructures for large shipping vessels. The grades are exclusively for shipbuilding use as set out in the standard.
Normal steel grade: A B D E
High strength steel grade: AH32 DH32 EH32 FH32 AH36 DH36 EH36 FH36
Ultra High strength steel grade: AH40 DH40 EH40 FH40
Marine and offshore vessel used steel plate: NV360 NV410 NV460 NV490 NV510 LR360/360FG LR410/410FG LR460FG/490FG/510FG
Classification society: (ASTM A-131)ABS CCS LR GL DNV RINA BV NK KR
| Grade | C | Si | Mn | P | S | Als | Ti | Cu | Cr | Ni | Mo | Nb | V |
| AH32 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 | ≤0.02 | ≤0.35 | ≤0.20 | ≤0.40 | ≤0.08 | 0.02~0.05 | 0.05~0.10 |
| DH32 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 | ≤0.02 | ≤0.35 | ≤0.20 | ≤0.40 | ≤0.08 | 0.02~0.05 | 0.05~0.10 |
| EH32 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 | ≤0.02 | ≤0.35 | ≤0.20 | ≤0.40 | ≤0.08 | 0.02~0.05 | 0.05~0.10 |
| FH32 | ≤0.16 | 0.1~0.5 | 0.9~1.6 | ≤0.025 | ≤0.025 | ≥0.015 | ≤0.02 | ≤0.35 | ≤0.20 | ≤0.80 | ≤0.08 | 0.02~0.05 | 0.05~0.10 |
| AH36 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 | ≤0.02 | ≤0.35 | ≤0.20 | ≤0.40 | ≤0.08 | 0.02~0.05 | 0.05~0.10 |
| DH36 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 | ≤0.02 | ≤0.35 | ≤0.20 | ≤0.40 | ≤0.08 | 0.02~0.05 | 0.05~0.10 |
| EH36 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 | ≤0.02 | ≤0.35 | ≤0.20 | ≤0.40 | ≤0.08 | 0.02~0.05 | 0.05~0.10 |
| FH36 | ≤0.16 | 0.1~0.5 | 0.9~1.6 | ≤0.025 | ≤0.025 | ≥0.015 | ≤0.02 | ≤0.35 | ≤0.20 | ≤0.80 | ≤0.08 | 0.02~0.05 | 0.05~0.10 |
| AH40 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 | ≤0.02 | ≤0.35 | ≤0.20 | ≤0.40 | ≤0.08 | 0.02~0.05 | 0.05~0.10 |
| DH40 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 | ≤0.02 | ≤0.35 | ≤0.20 | ≤0.40 | ≤0.08 | 0.02~0.05 | 0.05~0.10 |
| EH40 | ≤0.18 | ≤0.50 | 0.9~1.6 | ≤0.035 | ≤0.035 | ≥0.015 | ≤0.02 | ≤0.35 | ≤0.20 | ≤0.40 | ≤0.08 | 0.02~0.05 | 0.05~0.10 |
| FH40 | ≤0.16 | 0.1~0.5 | 0.9~1.6 | ≤0.025 | ≤0.025 | ≥0.015 | ≤0.02 | ≤0.35 | ≤0.20 | ≤0.80 | ≤0.08 | 0.02~0.05 | 0.05~0.10 |
Shipbuilding Steel Plate Mechanical Properties
| Grade | Thickness(mm) max | Yieldpoint(Mpa) min | Tensile Strength(Mpa) | Elongation(%)min | V-impact test | cold bend test | |||
| Temperature(ºC) | Average AKV | b=2a 180° | b=5a 120° | ||||||
| lengthways Min | crosswise Min | ||||||||
| A | 50 | 235 | 400~520 | 22 | - | - | - | - | d=2a |
| B | 50 | 235 | 400~520 | 22 | 0 | 27 | 20 | - | d=3a |
| D | 50 | 235 | 400~520 | 22 | -10 | 27 | 20 | - | d=3a |
| E | 50 | 235 | 400~520 | 22 | -40 | 27 | 20 | - | d=3a |
| AH32 | 50 | 315 | 440~570 | 22 | 0 | 31 | 22 | - | d=3a |
| DH32 | 50 | 315 | 440~570 | 22 | -20 | 31 | 22 | - | d=3a |
| EH32 | 50 | 315 | 440~570 | 22 | -40 | 31 | 22 | - | d=3a |
| FH32 | 50 | 315 | 440~570 | 22 | -60 | 31 | 22 | - | d=3a |
| AH36 | 50 | 355 | 490~620 | 21 | 0 | 34 | 24 | - | d=3a |
| DH36 | 50 | 355 | 490~620 | 21 | -20 | 34 | 24 | - | d=3a |
| EH36 | 50 | 355 | 490~620 | 21 | -40 | 34 | 24 | - | d=3a |
| FH36 | 50 | 355 | 490~620 | 21 | -60 | 34 | 24 | - | d=3a |
| AH40 | 50 | 390 | 510~660 | 20 | 0 | 41 | 27 | - | - |
| DH40 | 50 | 390 | 510~660 | 20 | -20 | 41 | 27 | - | - |
| EH40 | 50 | 390 | 510~660 | 20 | -40 | 41 | 27 | - | - |
| FH40 | 50 | 390 | 510~660 | 20 | -60 | 41 | 27 | - | - |
Shipbuilding Plate Available Dimensions
| Item | Thickness (mm) | Width (mm) | Length/coil diameter(mm) |
| Shipbuilding plate | 6~50 | 1300~3000 | 3000~15000 |
| Shipbuilding coil | 6~20 | 1500~2000 | 760+20~760-70 |
Q: What is your terms of payment?
A: 30% TT in advance and balance paid before loading.
Q: Could you provide sample?
A: Yes, we are honored to offer you samples for quality check.
Q: How is the quality of your products?
A: Our products are manufactured strictly according to national and international standard, and we take a test before delivered out. If you want see our quality certifications and all kinds of testing report, please just ask us for it.
Q: How long does it take for samples and mass production?
A: Usually it will take3-5 days for ready molds, 15-20days for new molds and samples after confirmation, 25-30 days for mass production.
