High Resistance Carbon Alloy Steel Plate Custom Cutting 5140 Width 1500mm

High Resistance Carbon Alloy Steel Plate Custom Cutting 5140 Width 1500mm
High Resistance Carbon Alloy Steel Plate Custom Cutting 5140 Width 1500mm High Resistance Carbon Alloy Steel Plate Custom Cutting 5140 Width 1500mm High Resistance Carbon Alloy Steel Plate Custom Cutting 5140 Width 1500mm High Resistance Carbon Alloy Steel Plate Custom Cutting 5140 Width 1500mm

Large Image :  High Resistance Carbon Alloy Steel Plate Custom Cutting 5140 Width 1500mm

Product Details:
Place of Origin: China(mainland)
Brand Name: BAOSTEEL ANSTEEL SHOUSTEEL
Certification: ISO SGS
Model Number: 40Cr / 5140 / SCr440 / 41Cr4
Payment & Shipping Terms:
Minimum Order Quantity: 5 ton
Price: 600-800 USD/Ton
Packaging Details: standard export seaworthy packing or as required
Delivery Time: 5-8 working days
Supply Ability: 500 ton/month

High Resistance Carbon Alloy Steel Plate Custom Cutting 5140 Width 1500mm

Description
Name: Alloy Steel Plate Technique: Cold Rolled / Hot Rolled
Width: 1500-2500mm Length: 6000-13000mm
Thickness: 3-120mm Application: Coiled Spring And Leaf Spring
High Light:

High Resistance carbon Alloy Stainless plate

,

1500mm carbon Alloy Steel plate

,

5140 Alloy Cutting Steel Plate

BS EN 41Cr4 Alloy Steel Plate Custom Cutting 5140 Alloy Steel Width 1500mm 2000mm 2200mm



Products Name Steel Plate
Type Carbon Steel Plate, Alloy Steel Plate, Special Steel Plate
Thickness Range 3.0 - 150mm
Width Range 1000 - 2500mm as request
Length Range Within 12m
Brand BAOSTEEL, XINGCHENG,HBIS,BENSTEEL,TANGSHAN,HANSTEEL
Conpany Type Factory and storage
MOQ 1 Ton
Grade as following
Standard ASTM GB JIS EN


Grade of our steel plate (ASTM Grade as Guide)



Structural Steel A283,A36,ABS Grade A, Grade B, Grade ADH36, Grade DH36, and Grade EH36,A514 T-1,A572 GR 50:
HSLA Structural Steel A588,A656 GR80,A690
Pressure vessel Steel A285 GR C, A515 GR 70,A516 GR 70,SA537
Abrasion resistant steel AR360,AR400,AR450,AR500
Alloy Steel 5130,5140,5150,4130,4140



EN10083-3 41Cr4 steel and 41CrS4 steel belong to a hardening alloy steel for quenching and tempering. As a top five alloy steel supplier and exporter in China, BBN steel company will produce and export high quality 41Cr4 alloy steel round bar, 41CrS4 steel plate

EN10083-3 41CR4 STEEL VS 41CRS4 ALLOY STEEL

EN10083-3 41Cr4 steel vs 41CrS4 alloy steel
Grade: 41Cr4,41CrS4
Standard: en 10083-3: 2006
41Cr4 material number: 1.7035
41CrS4 material number: 1.7039
Category: alloy steel for quenching and tempering
EN10083-3 41Cr4 steel and 41CrS4 steel belong to a hardening alloy steel for quenching and tempering. As a top five alloy steel supplier and exporter in China, BBN steel company will produce and export high quality 41Cr4 alloy steel round bar, 41CrS4 steel flat, 41CrS4 steel sheet and 41Cr4 hot rolled plate with direct factory price. The main difference between 41Cr4 and 41CrS4 steel is the carbon and sulfur content in chemical requirement.

EN10083-3 41Cr4 and 41CrS4 steel technical data


Chemical composition(%)


Material
C Si max Mn P max. S max Cr
41Cr4 0.38- 0.45 0.40 0.60- 0.90 0.025 0.035 max 0.90-1.20
41CrS4 0.38- 0.45 0.40 0.60- 0.90 0.025 0.020-0.040 0.90-1.20



Mechanical properties at room temperature




Grade
t ≤ 8mm 8mm < t ≤ 20mm 20mm < t ≤ 60mm
Re min Rm A min Re min Rm A min Re min Rm A min
MPa MPa % MPa MPa % MPa MPa %
41Cr4 800 1000-1200 11 660 900 - 1100 12 560 800 - 950 14
41CrS4 800 1000-1200 11 660 900 - 1100 12 560 800 - 950 14

Note: Re: upper yield strength
Rm: tensile strength
A: percentage elongation after fracture.

41Cr4 and 41CrS4 alloy steel plate specifications
Plate steel/flat bar: Size: Thickness: 0.1mm-800mm Width: 10mm to 1500mm
Round bar: Diameter: 1mm-2000mm
Square bar: Size: 50mm * 50mm-600mm *600mm
Cold-rolled sheet: Thickness: 2-5mm Width:1000mm Length: 2000mm
Hot-rolled sheet: Thickness:6-80mm Width: 210-610mm
Length: as customer requirement.
Manufacturing: forging/hot rolling/ extrusion of steel



FAQ
1. Q:Are you a factory or trading company?
A: We are a factory with more than 10 years' experience.
2. Q:What is the MOQ.?
A: We have products in stock. For the products we don't have in stock, the MOQ is negotiable, which will take your demand as our first priority.
3. Q: How about the quality control?
A: We have our own quality control system and we have also done SGS test. If necessary, we can support other third party inspection.
4. Q: What's your advantage?
A: We specialize in the production of special steel and constantly improve our production technology.
5. Q: What service do you offer?
A: Customized service and best after-sales service for each customer, please feel free to contact us!
