JISCO Galvalume SteeL Coil AZ150 AZ180 AZ100 AZ120 2.5mm Hot Dip Galvanized Carbon Steel

Large Image : JISCO Galvalume SteeL Coil AZ150 AZ180 AZ100 AZ120 2.5mm Hot Dip Galvanized Carbon Steel

Product Details:

Place of Origin:	China
Brand Name:	BAOSTEEL BENSTEEL HBIS
Certification:	SGS,BV,ISO
Model Number:	Galvalume Steel Coil

Payment & Shipping Terms:

Minimum Order Quantity:	5 tons
Price:	600 - 810 USD/Ton
Packaging Details:	Standard export packing or as per customer’s request.
Delivery Time:	5 days
Payment Terms:	L/C, T/T,Western Union
Supply Ability:	3000 TON per month

Contact Now

JISCO Galvalume SteeL Coil AZ150 AZ180 AZ100 AZ120 2.5mm Hot Dip Galvanized Carbon Steel

Description

Products:	Galvanized Steel Coil	Zinc Coating:	AZ60-275 G/m2
Coil ID:	508mm / 610mm	Type:	Coil / Strips
Technique:	Hot Dipped Galvanized	Surface:	Regular Spangle / Zero Spangle
Width:	1000mm 1250mm 1500mm	Service:	Slit Cutting
Coil Weight:	5 - 10 Tons	Loading Port:	Shanghai, China
Highlight:	galvalume steel coil az150 AZ180 , galvalume steel coil az150 AZ100 , 2.5mm hot dip galvanized carbon steel

JISCO Galvalume SteeL Coil AZ100 AZ120 AZ150 AZ180 Galvanized Steel Rolled 0.4 - 2.5mm

Galvalume steel is carbon steel coated with an aluminum-zinc alloy using a continuous hot-dip process, combining the corrosion protection and high-temperature resistance of aluminum with the formability and galvanic protection of zinc.

Applications for Galvalume Steel Products

Galvalume steel’s unique protective characteristics and economical price point make it ideal for:

Residential and Commercial Exterior Building Products
Roofing
Siding
Cabinetry

Galvalume Steel Sheet

Material Thickness: .015"-.135"
Max Coil: 45,000 lbs
ID: 20”-24”
Entry Width: 15.00”-74.00”
Exit Width: 5.00”-74.00”
Length: 6.00”-144”
Width/Length Tol: +/-.010"
Exit width: 4.00"-74.00”
Max coil weight: 50,000 lbs

Galvalume Steel Coil

Material Thickness: .010"-.500"
Min/Max Slit width: .375”-84”
Min/Max ID: 20”-30”
Max OD: 84”
Slit Width Tolerance: +/-.005"

galvalume steel sheet and coil service capabilities include slitting, shearing, blanking, degreasing and brushing,

galvalume steel sheet and coil product information and availability.

Structural Grades	C	Mn	P	S	Al	Si	Cu	Ni	Cr	Mo	V	Cb	Ti	N
30,33,36,40	0.25	0.9	0.035	0.04			0.2	0.2	0.15	0.06	0.008	0.008	0.025
36T2,45-80	0.25	1.35	0.035	0.04			0.2	0.2	0.15	0.06	0.008	0.008	0.025
45T2	.02- 0.08	.30- 1.0	.03- .07	0.025	.02- .08	0.6	0.2	0.2	0.15	0.06	0.008	0.008	0.025	.01- .03

HSLA Grades	C	Mn	P	S	Cu	Ni	Cr	Mo	V	Cb	Ti
45C1	0.22	1.35	0.04	0.04	0.2	0.2	0.15	0.06	0.005	0.005	0.005
45C2	0.15	1.35	0.04	0.04	0.2	0.2	0.15	0.06	0.005	0.005	0.005
50C1	0.23	1.35	0.04	0.04	0.2	0.2	0.15	0.06	0.005	0.005	0.005
50C2 & 55C2	0.15	1.35	0.04	0.04	0.2	0.2	0.15	0.06	0.005	0.005	0.005
55C1	0.25	1.35	0.04	0.04	0.2	0.2	0.15	0.06	0.005	0.005	0.005
60C1 & 65C1	0.26	1.5	0.04	0.04	0.2	0.2	0.15	0.06	0.005	0.005	0.005
60C2 & 65C2	0.15	1.5	0.04	0.04	0.2	0.2	0.15	0.06	0.005	0.005	0.005
70C1	0.26	1.65	0.04	0.04	0.2	0.2	0.15	0.16	0.005	0.005	0.005
70C2	0.15	1.65	0.04	0.04	0.2	0.2	0.15	0.16	0.005	0.005	0.005

Common Grades	C	Mn	P	S	Al	Cu	Ni	Cr	Mo	V	Cb	Ti
CSA	0.1	0.6	0.03	0.035		0.2	0.2	0.15	0.06	0.008	0.008	0.025
CSB	0.02-.15	0.6	0.03	0.035		0.2	0.2	0.15	0.06	0.008	0.008	0.025
CSC	0.08	0.6	0.1	0.035		0.2	0.2	0.15	0.06	0.008	0.008	0.025
BH	0.012	1.5	0.12	0.03		0.2	0.2	0.15	0.06	0.008	0.008	0.025
FSA	0.1	0.5	0.02	0.035		0.2	0.2	0.15	0.06	0.008	0.008	0.025
FSB	0.02-.15	0.5	0.02	0.03		0.2	0.2	0.15	0.06	0.008	0.008	0.025
DDS	0.06	0.5	0.02	0.025	.01	0.2	0.2	0.15	0.06	0.008	0.008	0.025
EDDS	0.02	0.4	0.02	0.02	.01*	0.2	0.2	0.15	0.06	0.1	0.1	0.15

JISCO Galvalume SteeL Coil AZ150 AZ180 AZ100 AZ120 2.5mm Hot Dip Galvanized Carbon Steel 0
