Product Details:
|
| Products: | Galvanized Steel Coil | Zinc Coating: | Z40-275 G/m2 |
|---|---|---|---|
| Coil ID: | 508mm / 610mm | Type: | Coil / Strips |
| Technique: | Hot Dipped Galvanized | Surface: | Regular Spangle / Zero Spangle |
| Width: | 1000mm 1250mm 1500mm | Service: | Slit Cutting |
| Coil Weight: | 5 - 10 Tons | Loading Port: | Shanghai, China |
| High Light: | minimized spangle Galvanized Steel Coils,Z100 Galvanized Steel Coils,Zinc Coating dx53d steel |
||
PRODUCTS SPECIFICAT
| Product name | Galvanized Steel Coil |
| Material | ASTM A653, DX51D, SGCC |
| Zinc Coating | 40-275g/m2 |
| Thickness | 0.2 - 3.0mm |
| Width | 600-1500 mm |
| Coil ID | 508/610mm |
| Coil weight | 3-8 tons |
| Surface Structure | Mini/Big Spangle / Zero Spangle |
| Surface Treatment | Anti-Finger printing ,Chromated, oiled/ non-oiled |
| Package | standard export package (Detailed picture is as follows) |
| Hardness | soft (normal), hard, full hard(G300-G550) |
| HS code | 721049 |
| Country of origin | China |
| Business type | Supplier and manufacturer |
Low carbon steel for cold forming (DX51D – DX54D)
Structural Steels (S220GD – S350GD)
S220GD,S250GD,S280GD,S320GD,S350GD
Use structural steel for high load-bearing capacity, with a yield strength of 220-350
Our company is one of the best galvanized steel coils supplier and manufacturer in China, Our galvanized steel coil production line has an annual production capacity of 300,000 tons and a manufacturing speed of 150m/min. We can manufacture and sell galvanized steel coils with a width of 800-1250mm and a coating weight of 60-300g/m3. We manufacture galvanized steel coils according to EN 10346, ASTM A653 standard. We have sufficient galvanized steel coil stock for fast delivery.
Hot Dipped Galvanized Steel Sheet in Coil (GI) is produced by passing the Full Hard sheet which has undergone the acid washing process and rolling process through the zinc pot, thereby applying zinc film to the surface. It has excellent corrosion resistance, paintability, and workability due to Zinc’s characteristics. Usually, hot-dipped galvanized steel sheet and galvanized steel coil process and specifications are basically the same.
