SA387 Gr11 Boiler Alloy Steel Plate 2000mm Width Hot Rolled Thick Sheet

Large Image : SA387 Gr11 Boiler Alloy Steel Plate 2000mm Width Hot Rolled Thick Sheet

Product Details:

Place of Origin:	China
Brand Name:	MITTEL
Certification:	ISO MTC SGS
Model Number:	ASTM A387

Payment & Shipping Terms:

Minimum Order Quantity:	500KGS
Price:	1.2 USD/KG
Packaging Details:	Wodden Pallet
Delivery Time:	7 Days
Payment Terms:	L/C, T/T
Supply Ability:	5000Ton

Contact Now

SA387 Gr11 Boiler Alloy Steel Plate 2000mm Width Hot Rolled Thick Sheet

Description

Application:	Boiler Plate	Technique:	Hot Rolled
Type:	Steel Plate	Width:	600mm-1250mm,2000-2300mm
Special Use:	Alloy Structual Steel	Grade:	Alloy Steel Plate
Thickness:	2-100mm	Material:	Alloy Structual Steel
Price Term:	CIF CFR FOB EX-WORK
Highlight:	Alloy Steel Boiler Plate , 600mm Alloy Steel Plate , Hot Rolled Alloy Steel Plate Sheet

SA387 Gr11 Boiler Alloy Steel Plate 2000mm Width Hot Rolled Thick Sheet

ASTM A387 GRADE 11 Class 2

As a pressure vessel grade steel for use in elevated temperature service, is used in a variety of industries and is highly effective, particularly in the oil, gas and petrochemical industry, where liquids and gases are often stored at higher temperatures.

The higher levels of chromium also provide excellent corrosion and oxidation resistance, which is a must in sour gas applications. Please refer to our technical specifications below for ASTM A387 Grade 11 Class 2...

Equivalents

BS	EN	ASTM/ASME	DIN
621 B	–––	A387-11-2	–––

Specifications for ASTM A387 Grade 11 Alloy Steel Plates

Chromium & Molybdenum content (according to the ASME specification)

Designation	Nominal Chromium Content (%)	Nominal Molybdenum Content (%)
A387 Grade 11	1.25%	0.50%

Tensile Requirements for ASTM A387 Grade 11 Alloy Steel Plates Class 1 Plates

Designation:	Requirement:	Grade 11
A387 Grade 11	Tensile strength, ksi [MPa]	75 to 100 [515 to 690]
	Yield strength, min, ksi [MPa]/(0.2% offset)	43 [310]
	Elongation in 8 in. [200mm], min %	18
	Elongation in 2 in. [50mm], min, %	22
	Reduction of area, min %	–––

Chemical Requirements for ASTM A387 Grade 11 Alloy Steel Plates

Element		Chemical Composition (%)
		A387 Grade 11
Carbon:	Heat Analysis:	0.05 - 0.17
	Product Analysis:	0.04 - 0.17
Manganese:	Heat Analysis:	0.40 - 0.65
	Product Analysis:	0.35 - 0.73
Phosphorus:	Heat Analysis:	0.035
	Product Analysis:	0.035
Sulphur (max):	Heat Analysis:	0.035
	Product Analysis:	0.035
Silicon:	Heat Analysis:	0.50 - 0.80
	Product Analysis:	0.44 - 0.86
Chromium:	Heat Analysis:	1.00 - 1.50
	Product Analysis:	0.94 - 1.56
Molybdenum:	Heat Analysis:	0.45 - 0.65
	Product Analysis:	0.45 - 0.70

SA387 Gr11 Boiler Alloy Steel Plate 2000mm Width Hot Rolled Thick Sheet 0

SA387 Gr11 Boiler Alloy Steel Plate 2000mm Width Hot Rolled Thick Sheet 3
