Product Details:
|
Commodity: | Stainless Steel Strips & Coils | Thickness: | 0.01mm-8.0mm |
---|---|---|---|
Width: | 1.0 - 1219mm Customs As Request | Standard: | JIS, AISI, ASTM, GB, DIN, EN |
Type: | Coil & Strip | Brand Name: | Baosteel, Tisco, Lisco, Posco |
Surface Finish: | NO.1, 2B , BA , NO.4, 8k, HL | Inner Package: | Waterproof Paper |
Outer Package: | Ooden Box, Woven Bag With Bundles | Application: | Construction, Machine Building |
High Light: | 8.0mm 304 cold rolled stainless steel coil,1.4301 304 cold rolled stainless steel coil,TISCO ss 304 strips |
Type | 304 Stainless steel strip |
Size/thinckness | 0.1mm-8.0mm |
Widthness | 6 - 600mm |
Surface | 2B BA NO.4 NO.1 HL 8K.etc |
Brand name | TISCO,BAOSTEEL , LISCO , BXSS POSCO |
Standard | EN 10088-2 / ASTM A240 GB JIS G4305 |
Coil width tolerance | within 0.2mm |
Packing |
# shape wooden frame and waterproof paper |
MOQ | within 500 kgs |
Delivery time | 5 - 12 days based on the quantity |
When it comes to 304 grade stainless steel strips manufacturing, we get that you need a long term partner, not just a supplier. Whether you need the small samples or the metal strips solution from start to end, our promise is providing you with the highest quality stainless steel strips, in the shortest delivery time, and at the most competitive price with the highest quality.
As the precision stainless steel strips manufacturing expert, we do the tight tolerance, every work that it is challenging. You just provide us an coming idea, we help turn it into actual product for you!
304 stainless steel strip is the most widely used chromium-nickel stainless steel strip.
It has good corrosion resistance, heat resistance, low temperature strength and mechanical properties.
This strip has good hot workability such as stamping and bending without heat treatment. It is resistant to corrosion in the atmosphere.
It is suitable for food processing line, storage and transportation, plate heat exchangers, bellows, household products, auto parts, medical appliances, building materials, chemicals industry, food industry, agriculture, ship parts, etc.
304 stainless steel is a nationally recognized food grade stainless steel material.
The chemical components of grade 304 stainless steel strip is summarized in the following table:
Grade | Standard | C | Si | Mn | P | S | Cr | Ni | Mo |
304 | ASTM A240 | ≤0.07 | ≤0.75 | ≤2.00 | ≤0.045 | ≤0.030 | 18.00-20.00 | 8.00-11.00 | – |
Grade | Standard | Yield Strength Rp0.2 (N/mm²) |
Tensile Strength Rm (N/mm²) |
Elongation % |
Hardness (HV) |
Hardness (HRB) |
---|---|---|---|---|---|---|
201 | ASTM A240 | ≥ 275 | ≥ 520 | ≥ 35 | ≤ 260 | ≤ 101 |
202 | ASTM A240 | ≥ 275 | ≥ 520 | ≥ 40 | ≤ 218 | ≤ 95 |
301 | ASTM A240 | ≥ 205 | ≥ 520 | ≥ 40 | ≤ 200 | ≤ 90 |
304 | ASTM A240 | ≥ 205 | ≥ 515 | ≥ 40 | ≤ 210 | ≤ 92 |
304L | ASTM A240 | ≥ 205 | ≥ 520 | ≥ 40 | ≤ 200 | ≤ 90 |
316L | ASTM A240 | ≥ 177 | ≥ 480 | ≥ 40 | ≤ 200 | ≤ 90 |
316Ti | ASTM A240 | ≥ 205 | ≥ 520 | ≥ 40 | ≤ 200 | ≤ 90 |
317L | ASTM A240 | ≥ 205 | ≥ 515 | ≥ 40 | ≤ 218 | ≤ 95 |
309S | ASTM A240 | ≥ 205 | ≥ 515 | ≥ 40 | ≤ 218 | ≤ 95 |
310S | ASTM A240 | ≥ 205 | ≥ 520 | ≥ 40 | ≤ 200 | ≤ 90 |
Thickness(mm) | Width<125mm | 125mm≤Width<250mm | 250mm≤Width<600mm |
---|---|---|---|
≥0.03-0.10 | ±0.06T | ±0.10T | ±0.10T |
≥0.10-0.15 | ±0.01 | ±0.015 | ±0.020 |
≥0.15-0.20 | ±0.015 | ±0.020 | ±0.025 |
≥0.20-0.25 | ±0.015 | ±0.020 | ±0.025 |
≥0.25-0.30 | ±0.018 |
±0.025 | ±0.030 |
≥0.30-0.40 | ±0.020 | ±0.025 | ±0.030 |
≥0.40-0.50 | ±0.025 | ±0.030 | ±0.040 |
≥0.50-0.60 | ±0.030 | ±0.030 | ±0.040 |
≥0.60-0.80 | ±0.030 | ±0.040 | ±0.040 |
≥0.80-1.00 | ±0.030 | ±0.040 |
±0.050 |
Our company have professional team who can adopt developed packaging technology to assure no any damages of products during transportation.
